NDA-24298 CHAPTER 4 Page 917 Issue 1 ASYDN : Assignment of System Data in Network Data Memory 1162-169 Not used 170b 0~b3Not used b 4 Timing Start 0/1 = Not Required/Required b 5~b7Not used 171-303 Not used 304b 0 Individual Speed Calling Data Save 0/1 = Out/In Service (This data is valid when SYS1, INDEX 90, b 1 = 1) b1 Call Forwarding Data Save 0/1 = Out/In Service (This data is valid when SYS1, INDEX 90, b 1 = 1) b2Not used b 3 Name Display Data Save 0/1 = Out/In Service (This data is valid when SYS1,...
Page 952
CHAPTER 4 NDA-24298 Page 918 Issue 1 ASYDN : Assignment of System Data in Network Data Memory 1322 00 Not used 511 00Not used 512 00 Not used 513 00 Not used 514 01b 0Local Data Memory (LDM) usage. Assign data “1” (the memory block is used) for the corresponding memory block. Note: Necessary data for the programming commands for NDM. When the Network Data Memory is not enough, change the value from 03H → 07H → 0FH → 1FH. Usually 01H is assigned. b1 b2 b3 b4 b5 b6 b7 515-532 Not used 533FPC that...
Page 953
NDA-24298 CHAPTER 4 Page 919 Issue 1 ASYDN : Assignment of System Data in Network Data Memory 18000b 0 ALGNN/ALGSN command tenant UGN (User Group Num- ber) table development of Network Data Memory (NDM) 0/1 = Separate/Common b 1 ASPAN command tenant table development of Network Data Memory (NDM) 0/1 = Separate/Common b 2 ANPDN command tenant table development of Network Data Memory (NDM) 0/1 = Separate/Common b 3 APCNN command tenant data table development of Network Data Memory (NDM) 0/1 =...
Page 954
CHAPTER 4 NDA-24298 Page 920 Issue 1 ASYDN : Assignment of System Data in Network Data Memory Example: When a call terminates on a Dterm from station number 5000/Telephone number 123456789, the Dterm displays as follows depending on the data settings: 18040b 0~b2Not used. b 3The number of digit for Internal Zone Paging group ID 0/1 = 2 digits/3 digits b 4~b7Not used. 805-863 Not used. 8640b 0~b2Not used. b 3Multiple ACDP 0/1 = Out of service/In service 0b 4~b7Not used. 865-869 Not used. 870b 0FLF Fusion...
Page 955
NDA-24298 CHAPTER 4 Page 921 Issue 1 AFMU : Assignment of FPC, MG and UNIT for Network Data Memory AFMU: Assignment of FPC, MG and UNIT for Network Data Memory 1. General This command allocates the Network ID (NID) that is the unique location number in the Fusion Network. 2. Precautions 1. NID allocation is required for the Fusion network only. 2. For detailed information, see the NEAX2400 IPX Fusion Network System Manual. 3. Data Entry Instructions FUSION POINT CODE (FPC) 1-253UNIT NUMBER (U) 0-3MODULE...
Page 956
CHAPTER 4 NDA-24298 Page 922 Issue 1 AFMU : Assignment of FPC, MG and UNIT for Network Data Memory 4. Data Sheet FUSION POINT CODE (FPC) 1-253MODULE GROUP NUMBER (MG) 0-7UNIT NUMBER (U) 0-3REMARKS
Page 957
NDA-24298 CHAPTER 4 Page 923 Issue 1 ALRTN : Assignment of Logical Route for Network Data Memory ALRTN: Assignment of Logical Route for Network Data Memory 1. General This command allocates the Logical Route Number that is the unique number of the external trunk route in the Fusion network. 2. Precautions 1. Logical Route Number allocation is required for the Fusion network only. 2. When assigning the data by this command, the Route Class Data (ARTD) and Trunk Application Data (ARTI) for Physical Route...
Page 958
CHAPTER 4 NDA-24298 Page 924 Issue 1 ALRTN : Assignment of Logical Route for Network Data Memory 4. Data Sheet LOGICAL ROUTE NUMBER (LGRT) 1-899FUSION POINT CODE (FPC) 1-253EXTERNAL ROUTE NUMBER (RT) 1-255REMARKS
Page 959
NDA-24298 CHAPTER 4 Page 925 Issue 1 ANPDN : Assignment of Numbering Plan Data for Network Data Memory ANPDN: Assignment of Numbering Plan Data for Network Data Memory 1. General This command assigns the minimum number of digits needed to determine the service (Telephone Number) that is required by the first digit received (pre-translation). The data assigned with this command is written in the Network Data Memory (NDM) of the Network Control Node (NCN), updating the NDM at each Local Node (LN). 2....
Page 960
CHAPTER 4 NDA-24298 Page 926 Issue 1 ANPDN : Assignment of Numbering Plan Data for Network Data Memory 4. Data Sheet TENANT NUMBER (TN)1st DIGIT (1st DC)CONNECTION STATUS INDEX (CI) N/H/BNUMBER OF NECESSARY DIGITS (NND)BUSY LAMP FIELD REMARKS 1NNormal H Hooking BBusy 2NNormal H Hooking BBusy 3NNormal H Hooking BBusy 4NNormal H Hooking BBusy 5NNormal H Hooking BBusy 6NNormal H Hooking BBusy 7NNormal H Hooking BBusy 8NNormal H Hooking BBusy 9NNormal H Hooking BBusy 0NNormal H Hooking BBusy *NNormal H...
