Stiga PARK 4WD PRO 23 PRO 20 PRO 16 PRO SVAN Instructions Manual

61
ENGLISHEN
2.4.2 Implement lifter, hydraulic (5:M)(Pro20, Pro23, Pro Svan)
The hydraulic implement lifter only works when
the engine is running and the clutch pedal and
parking brake pedal are not depressed. The imple-
ment lifter is controlled using the lever (5:M).
The lever has the following four positions:
Floating position . Move the lever to its
front position, where it locks. The imple-
ment is now lowered to its floating posi-
tion.
In the floating position, the implement
always rests...

62
ENGLISHEN
2.4.9 Ignition lock/headlight (4,5:I)
The ignition lock is used for starting and stopping
the engine. The ignition lock is also the switch for
the headlight. Do not leave the machine with the key
in position 2 or 3. There is a fire risk,
fuel can run into the engine through the
carburettor, and there is a risk of the
battery being discharged and damaged.
Four positions:
1. Stop position  – the engine is short-
circuited. The key can be removed.
2. Operating position  – headlight...

63
ENGLISHEN
2.4.17 Engine casing (7:U)In order to access the fuel cock, battery
and engine, the machine has an engine
casing that can be opened. The engine cas-
ing is locked with a rubber strap.
The engine casing is opened as follows:
1. Undo the rubber strap (7:V) at the front edge of  the casing.
2. Carefully lift the engine casing back.
Close in the reverse order.
The machine may not be operated un-
less the engine casing is closed and
locked. Risk of burns and crushing in-
juries.
2.4.18 Qui...

64
ENGLISHEN
Petrol is highly inflammable. Always
store fuel in containers that are made
especially for this purpose.
Only fill or top up with petrol outdoors,
and never smoke when filling or top-
ping up. Fill up with fuel before starting
the engine. Never remove the filler cap
or fill with petrol while the engine is
running or still warm.
Never completely fill the petrol tank. Leave an
empty space (= at least the entire filler tube plus 1
- 2 cm at the top of the tank) to allow the petrol to...

65
ENGLISHEN
4.  Do not keep your foot on the drive pedal (3:F).
5. Put the throttle control at full throttle. Starting cold engine – pull the choke control out
fully.
Starting warm engine – the choke control
should be pressed in.
6.  Depress the clutch-brake pedal (3:B) fully.
7.  Turn the ignition key and start the engine.
8 Once the engine has started, push the choke  control in gradually if it has been used.
9. When starting from cold, do not make the ma- chine work under load immediately, but...

66
ENGLISHEN
At each basic service and intermediate service car-
ried out at an authorised workshop, the service log
is stamped. A service log presenting these services
is a valuable document that improves the ma-
chine’s second-hand value.
5.2 PREPARATIONAll service and all maintenance must be carried out
on a stationary machine with the engine switched
off.Prevent the machine from rolling by al-
ways applying the parking brake.
Stop the engine.
Prevent unintentional starting of the
engine by...

67
ENGLISHEN
5.6 TRANSMISSION, OIL FILTERThe oil and the filter in the hydraulic power trans-
mission must be checked/adjusted or replaced at
intervals according to the table below.
Oil type: Synthetic oil 5W-50.
Oil volume at change: approx. 4.2 litres.
5.6.1 Check – adjustment
1. Place the machine on a flat surface.
2. Read off the oil level in the reservoir. See fig. 20. The level should be level with the line.
3. If necessary, top up with more oil.
5.6.2 Draining
1. Operate the machine at varying...

68
ENGLISHEN
5.9 BATTERY
If acid comes into contact with the eyes
or skin, this can cause serious injuries.
If any part of the body has come into
contact with acid, rinse immediately
with copious amounts of water and seek
medical assistance as soon as possible.
The battery is a valve-regulated battery with 12 V
nominal voltage. The battery fluid does not need to
and cannot be checked or topped up. The only
maintenance that is required is charging, for exam-
ple after extended storage.
The battery...

69
ENGLISHEN
Compressed air or petroleum-based solvents such
as kerosene may not be used for cleaning the paper
filter insert. This will damage the filter.
5.10.2 Air filter (Pro Svan)
Clean the air filter every 3 months or after every 50
hours of operation, whichever comes first.
Clean the paper filter insert once a year or after
every 200 hours of operation, whichever comes
first.
Note! Both filters should be cleaned more often if
the machine operates on dusty ground.
1.  Remove the protective...
