Stiga PARK COMPACT Instructions Manual

41
ENGLISHGB
GENERAL
This symbol indicates WARNING. Per-
sonal injury and/or damage to property
may result if the instructions are not
followed carefully.
You must read these instructions for
use and the accompanying pamphlet
“SAFETY INSTRUCTIONS” careful-
ly, before starting up the machine.
SYMBOLS
The following symbols appear on the machine.
They are there to remind you of the care and atten-
tion required in use.
This is what the symbols mean:
Warning!
Read the instruction manual and the safety...

42
ENGLISHGB
3. Pedal fully depressed – for-
ward drive disengaged. Service
brake fully activated.
3. PARKING BRAKE
An inhibitor that can lock the brake pedal in the de-
pressed position.
Depress the brake pedal fully. Raise the
inhibitor and then release the brake pedal.
The parking brake is released by pressing the brake
pedal. The spring-loaded inhibitor slides to one
side.
Make sure that the parking brake is released when
operating the machine.
4. DRIVE PEDAL (Compact HST)
A pedal that...

43
ENGLISHGB
or at high speeds. The transmission could be dam-
aged.
AREAS OF USE
The machine may only be used for the following
tasks using the genuine STIGA accessories stated.
1. Mowing
With cutting deck 13-2939 (92M).
2. Snow clearance
With snow blade 13-0918. Snow chains 13-
0936 (16”) and frame weights 13-0923 recom-
mended.
3. Grass and leaf transport
With dump cart 13-1979 (Standard).
The maximum vertical load on the towing hitch
must not exceed 100 N.
The maximum over-run load on the towing...

44
ENGLISHGB
ensure it is correct. The machine should be
standing on level ground.
Read off the oil level in the reservoir (fig. 9). It
should be between the MAX and MIN marks. If
necessary, top up with more oil. Use oil SAE 10W-
40 (20W-50).
SAFETY SYSTEM
This machine is equipped with a safety system that
consists of:
- a switch on the transmission (only Compact).
- a switch on the break pedal (only
Compact HST).
- a switch in the seat/seat bracket.
- a switch at the power take-off engagement...

45
ENGLISHGB
Reduce the speed on slopes and when
making sharp turns to prevent the ma-
chine from tipping over or you losing
control of the machine.
Do not turn the steering wheel to full
lock when driving in top gear and at full
throttle. The machine can easily topple
over.
Keep hands and fingers well away from
articulated steering joint and seat
bracket. Risk of crushing injuries. Nev-
er operate the machine without the en-
gine casing.
SERVICE AND MAINTENANCE
SERVICE PROGRAM
In order to keep...

46
ENGLISHGB
Do not fill with too much oil. This can cause the
engine to overheat.
After filling up the oil, start the engine and idle for
30 seconds. Stop the engine. Wait for 30 seconds
and then check the oil level.
Check to see if there is any oil leakage. If neces-
sary, fill up the oil up to the “FULL” mark.
AIR FILTER - ENGINE
Change the pre-filter once a year or every 25 hours
of operation.
Clean the paper filter insert once a year or after
every 100 hours of operation, whichever comes...

47
ENGLISHGB
LUBRICATION
The machine’s articulated steering joint has four
grease nipples that should be lubricated with uni-
versal grease after every 25 hours of operation (fig.
13).
Note: The fourth grease nipple is not shown on the
picture. It is located on the underside, on the flexi-
ble axle’s front bearing.
Lubricate the steering chain with chain spray a
couple of times each season.
The front wheel hub has grease nipples that should
be lubricated after every 50 hours of operation.
Apply...

48
FRANÇAISFR
GÉNÉRALITÉS
Ce symbole est un AVERTISSEMENT.
Risque de blessure ou de dégât matériel
en cas de non-respect des instructions.
Avant de démarrer la machine, lire at-
tentivement les instructions ainsi que
les consignes contenues dans le fascicule
« RÈGLES DE SÉCURITÉ » ci-joint.
SYMBOLES
Les symboles suivants figurent sur la machine. Ils
attirent votre attention sur les dangers d’utilisation
et les mesures à respecter.
Explication des symboles :
Attention!
Lire le mode d’emploi et le...

49
FRANÇAISFR
1. Pédale relâchée – frein de ser-
vice non activé.
2. Pédale enfoncée jusqu’à mi-
course – marche avant désen-
clenchée. Le frein de service
n’est pas activé.
3. Pédale enfoncée à fond – mar-
che avant désenclenchée. Le
frein de service est totalement
activé.
3. FREIN DE STATIONNEMENT
Inhibiteur permettant de bloquer la pédale de frein
dans la position enfoncée.
Enfoncer à fond la pédale de frein. Lever
l’inhibiteur puis libérer la pédale de frein.
Pour débloquer le frein de...

50
FRANÇAISFR
9. LEVIER DE DÉBRAYAGE
(Compact HST)
Levier permettant de débrayer la transmission va-
riable, ce qui permet de bouger la machine à la
main, moteur éteint. Deux positions sont possibles
:
1. Levier vers l’arrière – la trans-
mission est activée pour un fonc-
tionnement normal.
2. Levier vers l’avant – débraya-
ge de la transmission. La machi-
ne peut être déplacée
manuellement.
Ne pas remorquer la machine sur de longues dis-
tances ou à des vitesses élevées pour éviter d’en-
dommager la...
