NEAX2400 IPX Feature Programming ManualPage 478NDA-24297, Issue 1
M-15 Maintenance Printout
Programming (cont’d)
System Data 1, Index 86, Bit 4. Fault Information automatic printout of System Messages? 0/1: No/
Yes.
System Data 1, Index 86, Bit 7. Are simplified or detailed System Messages required? 0/1: Simplified/
Detailed.
System Data 1, Index 117-123. Each index represents an I/O port. Program the following Bits:
0, 1, & 2.
001: Printer*
010: MAT
Bit 7: Password Function 0/1:-/In Service.
STEP...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 479
Maintenance Administration Terminal (MAT) M-18
M-18  Maintenance Administration Terminal (MAT)
General Description
This feature provides a man-machine interface, using a personal computer, to accomplish such items as on-line
system programming of station and trunk data, traffic information, fault condition analysis, and testing of operating
programs.
Operating Procedure
Refer to the NEAX2400 IPX Office Data Specification.
Service...

NEAX2400 IPX Feature Programming ManualPage 480NDA-24297, Issue 1
M-18 Maintenance Administration Terminal (MAT)
Service Conditions (cont’d)
b.) The maximum digits of the USER NAME is 16, and those of the ID CODE is 8.
c.) Lock Out information is output with the information of the USER NAME, date, time, and IOC
port used as System Message.
d.) A maximum of 128 System Messages can be stored. However, if other failure messages are
output, the stored number for Audit Trail to Track the Mat Usage service...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 481
Message Reminder M-19
M-19 Message Reminder
General Description
This feature allows a single-line telephone to leave a MESSAGE REMINDER at the called Dtermset.
Operating Procedure
To send a message from a single-line telephone
1. Dial the desired internal Dtermstation; receive ringback tone or busy tone.
2. Press switch hook; receive special dial tone.
3. Dial the MESSAGE REMINDER access code; receive service set tone.
4. At the called D...

NEAX2400 IPX Feature Programming ManualPage 482NDA-24297, Issue 1
M-19 Message Reminder
Service Conditions (cont’d)
11. When the call is in the UCD queue, the MESSAGE REMINDER service is not provided.
12. A maximum of 32 digits can be saved at the called party.
13. To memorize the telephone number of the calling station, assign SYS1, index 641, b0=1 by the ASYDN
command.
Programming
STEP 1:ASYD- System Data 1, Index 17, Bit 0.
Single-line stations able to use VOICE CALL [V-2D] and MESSAGE REMINDER...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 483
Message Reminder - DtermM-19D
M-19D  Message Reminder - Dterm
General Description
ThisfeatureallowsaDtermto leave a MESSAGE REMINDER at another Dterm.
Operating Procedure
To send a message from a Dterm
1. Dial the desired Dtermstation, receive ringback tone or busy tone.
2. Press the MSG key; the LCD displays:
Service set tone is heard.
3. At the called D
term, the MSG LED will light to indicate a message has been set.
To review the...

NEAX2400 IPX Feature Programming ManualPage 484NDA-24297, Issue 1
M-19D Message Reminder - Dterm
Service Conditions (cont’d)
5. Messages can be displayed only when the station is on-hook. A message may be cleared by displaying the
message and pressing the“*”or“#”key on the called Dterms key pad.
6. A message is cleared when it is obtained via the MSG key.
7. Messages cannot be cleared by the message sender.
8. A second message sent by the same calling D
termis registered as a second unique message. The...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 485
Message Reminder - DtermM-19D
Programming (cont’d)
STEP 3:ANPD- Reserve a number level for feature access. Assign for Normal (N), Hooking (H), and Busy
(B). Assign NND in accordance with predetermined Numbering Plan.
STEP 4:ASPA- Assign an access code to Message Reminder; assign SRV = SSCA (Service Code Appendix),
SIDA = 42; assign Hooking (H), and Busy (B).
For Dterms
STEP 5:ASYD- System Data 1, Index 80, Bit 1. Message Reminder Cancel...

NEAX2400 IPX Feature Programming ManualPage 486NDA-24297, Issue 1
M-20D Multiple Line Operation - Dterm
M-20D  Multiple Line Operation - Dterm
General Description
This feature allows for the appearance of multiple lines on the programmable line/feature keys of the Dtermset.
Operating Procedure
No manual operation is required.
Service Conditions
1. Three kinds of lines can appear on Dterms:
MY Line (ML): This line is associated with the extension number assigned to the port on the
interface circuit.
Prime...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 487
Multiple Line Operation - DtermM-20D
Programming (cont’d)
KYN: Key Number (1-40)
KYI: Service Index
0: Key Not Used
1: Feature Key
2: Multi-line Key
KD: Not assigned for Feature Key
TN STN: Tenant Number and Station Number of Multi-line
RG: Ringing Assignment per Multi-line Appearance
0: No Ringing
1: Ringing in Day Mode Only
2: Ringing in Night Mode Only
3: Ringing in Day and Night Mode
