How to Remove the Ink CartridgeRemove the old ink cartridge before installing a new ink cartridge.
1. Press and hold the power button for one second or more to turn off the unit’s power.
2. Open the imprinter door.
3. Move the carriage to the ink cartridge exchange position.
Notice
•Adjust the position following the label on the imprinter.
4. Pinch the ink cartridge adjustment lever ( A) and lift it.
Operating Manual71
Consumables and Optional Accessories 1

5.Remove the ink cartridge ( A).
• For details about installing a new ink cartridge, refer to step  5 and after in  "Installing the Imprinter Unit
and Ink Cartridge" (page 67).
72Operating Manual
Consumables and Optional Accessories1

PrintingAdjusting the imprinter printing position
1. Move the carriage to the desired printing position, and align the indicator ( A) with the "
" mark ( B).
• The "
" mark indicates the printing position. Printing is not available in any other position.
Printing Position
Printing
Printing can be set from the Image Capture Plus software and the TWAIN and ISIS drivers. For details, refer
to the Image Capture Plus, TWAIN, or ISIS help.
Operating Manual73
Consumables and Optional Accessories...

TroubleshootingIf a problem occurs while the scanner is being used, check the following items and check the scanner status
in User Utility. If the unit still malfunctions, turn it OFF, unplug the power cord and call for service.SymptomPossible CauseRemedyThe LED (Green) does not
light when the unit’s power is
turned ON.
The power cord is not plugged in.Insert the power plug firmly.
The computer does not
recognize the scanner.
The scanner is not functioning
correctly.
The scanner is not connected to the...

SymptomPossible CauseRemedy
Double feeding occurs
frequently or the scanner
stops loading while scanning.
The paper feed roller, separation
roller, double feed prevention roller,
drive rollers, or free rollers are dirty.Clean the paper feed roller,
separation roller, double feed
prevention roller, drive rollers, and
free rollers. (page 56)The sensors or reflectors are dirty.Clean all of the sensors and the
reflectors. (page 54)The paper feed roller, separation
roller, or double feed prevention roller...

SymptomPossible CauseRemedy
Scanned image is skewed.
The document guides are not
adjusted to the size of the document
to be scanned, or the document to be
scanned is set slanted on the feed
tray.
Adjust the document guides properly
to the size of the document to be
scanned. (page 26)
Right and left sides of the document
to be scanned are not the same in
height, because of curling or folding.Flatten the document (page 24) and
load it again after reducing the pages.The scanned document is
blank.The wrong...

Error Messages (KV-S5076H only)Error codes corresponding to the scanner status are displayed on the LCD.
Also, when the scanner is connected to a computer, simple messages are displayed on the LCD.
For details about the error codes and messages, check in User Utility.Error CodeCauseRemedyU11
U12
U13The paper has jammed in the feed tray
area.Open the ADF door, and remove the paper.The sensors are dirty.Clean the sensors. *1U14
U16The paper has jammed in the exit tray area.Open the ADF door, and remove the...

Shading Adjustment
About shading adjustment The shading adjustment function corrects variations in the lamp intensity and pixel sensor sensitivity, and
reduces unevenness in density in scanned images. It can be carried out by means of the  User Utility using the
special shading paper, which is provided with this scanner.
When shading adjustment is required Perform shading adjustment when the density and brightness of sections of scanned images is considerably
uneven, or when image quality does not...

Deleting Installed SoftwareIf you want to remove the software that is installed on your computer, follow the procedure below to uninstall
them.
1. In [Control Panel], open [Uninstall a program].
• In Windows XP, select [Add or Remove Programs].
2. Select the item that you want to uninstall.
• The software is displayed with the program names below:SoftwareProgram NameDevice driverPanasonic Document Scanner Device Driver X.XX *1TWAINKV-S5076H KV-S5046H TWAIN DriverISISKV-S5076H KV-S5046H ISIS DriverImage...

Repacking InstructionsIt is highly recommended that you keep the original carton and  ALL packing materials. If you need to transport
or ship the scanner, please follow these instructions.
Note
•Improper repacking of the scanner may result in a service charge to repair the scanner.
• Please use the original carton and all of the original packing materials.
• The scanner should be handled in the correct (horizontal) position.
Required Materials
• Original scanner carton and packing materials
• Shipping...
