Panasonic Projector Pt Rw330u Operating Instructions

Chapter 4 Settings — [NETWORK] menu
ENGLISH - 91
[NETWORK STATUS]
Display the status of the projector network.
1) Press as to select [NETWORK STATUS].
2) Press the  button.
 fThe [NETWORK ST
ATUS] screen is displayed.
Network connections
The projector has a network function, and the following operations are a\
vailable from the computer using the web control.
 fSetting and adjustment of the projector
 fDisplay of the projector status
 fSending of E-mail messages when there is a problem with the...

Chapter 4 Settings — [NETWORK] menu
92 - ENGLISH
Connecting to a twisted-pair-cable transmitter
The projector has a function that can receive Ethernet signals from a tw\
isted-pair-cable transmitter together with video and audio signals via a\

LAN cable.
Connect a LAN cable to the  terminal of the projector. (x pages 16, 21)
 r Example of network connections via a twisted-pair-cable transmitter
&RPSXWHU
3URMHFWRU
/$1FDEOHVWUDLJKW /$1FDEOHVWUDLJKW
/$1FDEOH
VWUDLJKW...

Chapter 4 Settings — [NETWORK] menu
ENGLISH - 93
Accessing from the web browser
1) Start up the web browser on the computer.
2) Enter the IP address set on the projector into the URL entry field of the web browser.
3) Enter the user name and the password.
 fThe factory default setting of the user name is user1 (user rights)/admin1 (administrator rights) and the password is panasonic (lower
case).
4) Click OK.
 fThe [Projector status] page is displayed.
Note
 fIf you use a web browser to control the...

Chapter 4 Settings — [NETWORK] menu
94 - ENGLISH
Descriptions of items
1
2
3
4
5
6
1 Page tab
Switches pages by clicking it.
2
 [Status]
The status of the projector is displayed by clicking this item.
3
 [Projector control]
The [Projector control] page is displayed by clicking this item. 4
 [Detailed set up]
The [Detailed set up] page is displayed by clicking this item.
5
 [Change password]
The [Change password] page is displayed by clicking this item.
6
 [CRESTRON RoomView]
Th

e control page of...

Chapter 4 Settings — [NETWORK] menu
ENGLISH - 95
Error information page
When [Error (Detail)] is displayed in the self-diagnosis display of the [Projector status] screen, click it to display the error details.
 fThe projector may go into the standby status to protect the projector de\
pending on the contents of the error.
>2.@2SHUDWLQJSURSHUO\
>)$,/(@$SUREOHPRFFXUUHG
>:$51,1*@:DUQLQJ
 rProblem occurrence [FAILED] items
Parameter
Description
[MAIN CPU BUS] There is a problem with the...

Chapter 4 Settings — [NETWORK] menu
96 - ENGLISH
[Access error] page
Click [Status] → [Access error].
The error log on the WEB server is displayed such as access to the pages\
 that do not exist or access with unauthorized user names or
passwords.
[Mail error] page
Click [Status]  → [Mail error].
Displays email error information if the system fails to send periodic em\
ails.
Note
 f [Access error]/[Mail error] will display the recent few hundred accesses/requests. May be unable to display all...

Chapter 4 Settings — [NETWORK] menu
ENGLISH - 97
[Advanced control] page
Click [Projector control] → [Advanced control].
1
2
1 [POSITION]
Operates items related to angle of view. 2 [PICTURE]
Operates items related to image quality.
[Network config] page
Click [Detailed set up]
→ [Network config].
 f Click [Network config] to display the [CAUTION!] screen.
 fClick the [Next] button to display the current settings.
 fThe following setting change screen is displayed by clicking the [Change\
] button.
1
2...

Chapter 4 Settings — [NETWORK] menu
98 - ENGLISH
[Ping test] page
You can check whether the network is connected to the E-mail server, POP server, DNS server, etc.
Click [Detailed set up] → [Ping test].
1
2
3 4
1 [Input IP address]
Enter the IP  address of the server to be tested.
2
 [Submit]
Executes the connection test. 3
 Example of display when the connection has succeeded
4
 Example of display when the connection has failed
[Adjust clock] page
Click [Detailed set up]  → [Adjust clock].
1
2
3
45
6
7...

Chapter 4 Settings — [NETWORK] menu
ENGLISH - 99
[E-mail set up] page
When there is a problem, an email can be sent to preset email addresses (up to two addresses).
Click [Detailed set up] → [E-mail set up].
1
2
3
4
5
6
1 [ENABLE]
Select [Enable] to use the E-mail function.
2
 [SMTP SER

VER NAME]
Enter the IP address or the server name of the E-mail server
(SMTP). To enter the server name, the setup of the DNS server
is required.
3
 [MAIL FROM]
Enter the E-mail address of the projector

. (Up to 63...

Chapter 4 Settings — [NETWORK] menu
100 - ENGLISH
11
10
9
9 [E-MAIL ADDRESS 2]
Enter the E-mail address to be sent when two E-mail addresses
are to be used.
Leave it blank when two E-mail addresses are not to be used.
10
 Settings of the conditions to send E-mail
Select the conditions to send E-mail to the second E-mail
address.
[MAIL CONTENTS]:
Select either [NORMAL] or [SIMPLE].
[ERROR]:
An E-mail message is sent when an error occurred in the self-
diagnosis. [INT

AKE AIR TEMPERATURE]:
An E-mail...
