Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 81
[INITIALIZE]
Return various setting values to their factory default settings.
1) Press as to select [INITIALIZE].
2) Press the button.
fThe [SECURITY
PASSWORD] screen is displayed.
3) Enter a security password and press the button.
fThe [INITIALIZE]
screen is displayed.
4) Press as to select an item to initialize.
[ALL USER DATA] Returns all setting items including [ENTRY SIGNAL], [NETWORK SETUP], [E-mail set up], and [USER
LOGO] to factory...](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-80.png "Page 81
Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 81
[INITIALIZE]
Return various setting values to their factory default settings.
1) Press as to select [INITIALIZE].
2) Press the button.
fThe [SECURITY
PASSWORD] screen is displayed.
3) Enter a security password and press the button.
fThe [INITIALIZE]
screen is displayed.
4) Press as to select an item to initialize.
[ALL USER DATA] Returns all setting items including [ENTRY SIGNAL], [NETWORK SETUP], [E-mail set up], and [USER
LOGO] to factory...")
Chapter 4 Settings — [PROJECTOR SETUP] menu ENGLISH - 81 [INITIALIZE] Return various setting values to their factory default settings. 1) Press as to select [INITIALIZE]. 2) Press the button. fThe [SECURITY PASSWORD] screen is displayed. 3) Enter a security password and press the button. fThe [INITIALIZE] screen is displayed. 4) Press as to select an item to initialize. [ALL USER DATA] Returns all setting items including [ENTRY SIGNAL], [NETWORK SETUP], [E-mail set up], and [USER LOGO] to factory...
Page 82
![Page 82
Chapter 4 Settings — [TEST PATTERN] menu
82 - ENGLISH
[TEST PATTERN] menu
On the menu screen, select [TEST PATTERN] from the main menu.
Refer to “Navigating through the menu” (
x
page 41) for the operation of the menu screen.
fPress
qw to switch.
[TEST PATTERN]
Display the test pattern built-in to the projector.
Settings of position, size, and other factors will not be reflected in test patterns. Make sure to display the input signal before performing various
adjustments.
1) Press qw to switch [TEST...](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-81.png "Page 82
Chapter 4 Settings — [TEST PATTERN] menu
82 - ENGLISH
[TEST PATTERN] menu
On the menu screen, select [TEST PATTERN] from the main menu.
Refer to “Navigating through the menu” (
x
page 41) for the operation of the menu screen.
fPress
qw to switch.
[TEST PATTERN]
Display the test pattern built-in to the projector.
Settings of position, size, and other factors will not be reflected in test patterns. Make sure to display the input signal before performing various
adjustments.
1) Press qw to switch [TEST...")
Chapter 4 Settings — [TEST PATTERN] menu 82 - ENGLISH [TEST PATTERN] menu On the menu screen, select [TEST PATTERN] from the main menu. Refer to “Navigating through the menu” ( x page 41) for the operation of the menu screen. fPress qw to switch. [TEST PATTERN] Display the test pattern built-in to the projector. Settings of position, size, and other factors will not be reflected in test patterns. Make sure to display the input signal before performing various adjustments. 1) Press qw to switch [TEST...
Page 83
![Page 83
Chapter 4 Settings — [SIGNAL LIST] menu
ENGLISH - 83
[SIGNAL LIST] menu
On the menu screen, select [SIGNAL LIST] from the main menu.
Refer to “Navigating through the menu” (
x
page 41) for the operation of the menu screen.
rRegistered signal details
f A name can be set for each sub memory (
x page 67).
fMemory number:
$
:KHQWKHVLJQDORIWKHDGGUHVVQXPEHU $$// LVUHJLVWHUHG 6XEPHPRU\QXPEHU
Registering a signal to the list
After a new signal is input and the button on the...](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-82.png "Page 83
Chapter 4 Settings — [SIGNAL LIST] menu
ENGLISH - 83
[SIGNAL LIST] menu
On the menu screen, select [SIGNAL LIST] from the main menu.
Refer to “Navigating through the menu” (
x
page 41) for the operation of the menu screen.
rRegistered signal details
f A name can be set for each sub memory (
x page 67).
fMemory number:
$
:KHQWKHVLJQDORIWKHDGGUHVVQXPEHU $$// LVUHJLVWHUHG 6XEPHPRU\QXPEHU
Registering a signal to the list
After a new signal is input and the button on the...")
Chapter 4 Settings — [SIGNAL LIST] menu ENGLISH - 83 [SIGNAL LIST] menu On the menu screen, select [SIGNAL LIST] from the main menu. Refer to “Navigating through the menu” ( x page 41) for the operation of the menu screen. rRegistered signal details f A name can be set for each sub memory ( x page 67). fMemory number: $ :KHQWKHVLJQDORIWKHDGGUHVVQXPEHU $$// LVUHJLVWHUHG 6XEPHPRU\QXPEHU Registering a signal to the list After a new signal is input and the button on the...
Page 84
![Page 84
Chapter 4 Settings — [SIGNAL LIST] menu
84 - ENGLISH
Deleting the registered data
Registered signals can be deleted.
1) Press asqw to select the signal to delete.
2) Press the button.
fThe [ENTR
Y SIGNAL DELETE] screen is displayed.
fTo cancel the deletion, press the button or the button to\
return to the
[REGISTERED SIGNAL
LIST] screen.
3) Press the button.
fThe selected signal will be deleted.](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-83.png "Page 84
Chapter 4 Settings — [SIGNAL LIST] menu
84 - ENGLISH
Deleting the registered data
Registered signals can be deleted.
1) Press asqw to select the signal to delete.
2) Press the button.
fThe [ENTR
Y SIGNAL DELETE] screen is displayed.
fTo cancel the deletion, press the button or the button to\
return to the
[REGISTERED SIGNAL
LIST] screen.
3) Press the button.
fThe selected signal will be deleted.")
Chapter 4 Settings — [SIGNAL LIST] menu 84 - ENGLISH Deleting the registered data Registered signals can be deleted. 1) Press asqw to select the signal to delete. 2) Press the button. fThe [ENTR Y SIGNAL DELETE] screen is displayed. fTo cancel the deletion, press the button or the button to\ return to the [REGISTERED SIGNAL LIST] screen. 3) Press the button. fThe selected signal will be deleted.
Page 85
![Page 85
Chapter 4 Settings — [SECURITY] menu
ENGLISH - 85
[SECURITY] menu
On the menu screen, select [SECURITY] from the main menu, and select the\
item from the
sub-menu.
Refer to “Navigating through the menu” (x
page 41) for the operation of the menu screen.
fWhen the projector is used for the first time
Initial password: Press
awsqawsq in order, and press the button.
fAfter selecting the item, press
asqw to set.
Attention
fWhen you select the [SECURITY] from the main menu and press the button,...](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-84.png "Page 85
Chapter 4 Settings — [SECURITY] menu
ENGLISH - 85
[SECURITY] menu
On the menu screen, select [SECURITY] from the main menu, and select the\
item from the
sub-menu.
Refer to “Navigating through the menu” (x
page 41) for the operation of the menu screen.
fWhen the projector is used for the first time
Initial password: Press
awsqawsq in order, and press the button.
fAfter selecting the item, press
asqw to set.
Attention
fWhen you select the [SECURITY] from the main menu and press the button,...")
Chapter 4 Settings — [SECURITY] menu ENGLISH - 85 [SECURITY] menu On the menu screen, select [SECURITY] from the main menu, and select the\ item from the sub-menu. Refer to “Navigating through the menu” (x page 41) for the operation of the menu screen. fWhen the projector is used for the first time Initial password: Press awsqawsq in order, and press the button. fAfter selecting the item, press asqw to set. Attention fWhen you select the [SECURITY] from the main menu and press the button,...
Page 86
![Page 86
Chapter 4 Settings — [SECURITY] menu
86 - ENGLISH
[TEXT DISPLAY]
Overlap the security message (text) over the projecting image.
1) Press as to select [TEXT DISPLAY].
2) Press qw to switch [TEXT DISPLAY].
fThe items will switch each time you press the button.
[OFF]
Hides the security message.
[ON] Displays the security message.
Note
fIf a closed caption signal of the selected mode is input, the security m\
essage is not displayed.
[TEXT CHANGE]
Change the text displayed when [TEXT DISPLAY] is set to...](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-85.png "Page 86
Chapter 4 Settings — [SECURITY] menu
86 - ENGLISH
[TEXT DISPLAY]
Overlap the security message (text) over the projecting image.
1) Press as to select [TEXT DISPLAY].
2) Press qw to switch [TEXT DISPLAY].
fThe items will switch each time you press the button.
[OFF]
Hides the security message.
[ON] Displays the security message.
Note
fIf a closed caption signal of the selected mode is input, the security m\
essage is not displayed.
[TEXT CHANGE]
Change the text displayed when [TEXT DISPLAY] is set to...")
Chapter 4 Settings — [SECURITY] menu 86 - ENGLISH [TEXT DISPLAY] Overlap the security message (text) over the projecting image. 1) Press as to select [TEXT DISPLAY]. 2) Press qw to switch [TEXT DISPLAY]. fThe items will switch each time you press the button. [OFF] Hides the security message. [ON] Displays the security message. Note fIf a closed caption signal of the selected mode is input, the security m\ essage is not displayed. [TEXT CHANGE] Change the text displayed when [TEXT DISPLAY] is set to...
Page 87
![Page 87
Chapter 4 Settings — [SECURITY] menu
ENGLISH - 87
[CONTROL DEVICE SETUP]
Enable/disable the button operations on the control panel and the remote\
control.
1) Press as to select [CONTROL DEVICE SETUP].
2) Press the button.
fThe [CONTROL
DEVICE SETUP] screen is displayed.
3) Press as to select [CONTROL PANEL] or [REMOTE CONTROL].
4) Press the button.
fThe [CONTROL
PANEL] screen or the [REMOTE CONTROL] screen is displayed.
5) Press as to select [ENABLE] or [DISABLE].
fYou can set the limitation on...](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-86.png "Page 87
Chapter 4 Settings — [SECURITY] menu
ENGLISH - 87
[CONTROL DEVICE SETUP]
Enable/disable the button operations on the control panel and the remote\
control.
1) Press as to select [CONTROL DEVICE SETUP].
2) Press the button.
fThe [CONTROL
DEVICE SETUP] screen is displayed.
3) Press as to select [CONTROL PANEL] or [REMOTE CONTROL].
4) Press the button.
fThe [CONTROL
PANEL] screen or the [REMOTE CONTROL] screen is displayed.
5) Press as to select [ENABLE] or [DISABLE].
fYou can set the limitation on...")
Chapter 4 Settings — [SECURITY] menu ENGLISH - 87 [CONTROL DEVICE SETUP] Enable/disable the button operations on the control panel and the remote\ control. 1) Press as to select [CONTROL DEVICE SETUP]. 2) Press the button. fThe [CONTROL DEVICE SETUP] screen is displayed. 3) Press as to select [CONTROL PANEL] or [REMOTE CONTROL]. 4) Press the button. fThe [CONTROL PANEL] screen or the [REMOTE CONTROL] screen is displayed. 5) Press as to select [ENABLE] or [DISABLE]. fYou can set the limitation on...
Page 88
![Page 88
Chapter 4 Settings — [NETWORK] menu
88 - ENGLISH
[NETWORK] menu
On the menu screen, select [NETWORK] from the main menu, and select the \
item from the
sub-menu.
Refer to “Navigating through the menu” (x
page 41) for the operation of the menu screen.
fAfter selecting the item, press
asqw to set.
[DIGITAL LINK MODE]
Switch the communication method of the terminal of the projector.
1) Press as to select [DIGITAL LINK MODE].
2) Press qw to switch [DIGITAL LINK MODE].
fThe items will switch each time...](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-87.png "Page 88
Chapter 4 Settings — [NETWORK] menu
88 - ENGLISH
[NETWORK] menu
On the menu screen, select [NETWORK] from the main menu, and select the \
item from the
sub-menu.
Refer to “Navigating through the menu” (x
page 41) for the operation of the menu screen.
fAfter selecting the item, press
asqw to set.
[DIGITAL LINK MODE]
Switch the communication method of the terminal of the projector.
1) Press as to select [DIGITAL LINK MODE].
2) Press qw to switch [DIGITAL LINK MODE].
fThe items will switch each time...")
Chapter 4 Settings — [NETWORK] menu 88 - ENGLISH [NETWORK] menu On the menu screen, select [NETWORK] from the main menu, and select the \ item from the sub-menu. Refer to “Navigating through the menu” (x page 41) for the operation of the menu screen. fAfter selecting the item, press asqw to set. [DIGITAL LINK MODE] Switch the communication method of the terminal of the projector. 1) Press as to select [DIGITAL LINK MODE]. 2) Press qw to switch [DIGITAL LINK MODE]. fThe items will switch each time...
Page 89
![Page 89
Chapter 4 Settings — [NETWORK] menu
ENGLISH - 89
7) When the confirmation is displayed, select [OK] or [CANCEL], and press t\
he button.
Note
f Not compatible with 10BaseT Full/Half.
When the projector is connected directly via a twisted-pair-cable transm\
itter
1) Press as to select [DIGITAL LINK SETUP].
2) Press the button.
fThe [DIGIT
AL LINK SETUP] screen is displayed.
3) Press as to select [DUPLEX(DIGITAL LINK)].
4) Press qw to switch the communication method.
fThe items will switch each time...](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-88.png "Page 89
Chapter 4 Settings — [NETWORK] menu
ENGLISH - 89
7) When the confirmation is displayed, select [OK] or [CANCEL], and press t\
he button.
Note
f Not compatible with 10BaseT Full/Half.
When the projector is connected directly via a twisted-pair-cable transm\
itter
1) Press as to select [DIGITAL LINK SETUP].
2) Press the button.
fThe [DIGIT
AL LINK SETUP] screen is displayed.
3) Press as to select [DUPLEX(DIGITAL LINK)].
4) Press qw to switch the communication method.
fThe items will switch each time...")
Chapter 4 Settings — [NETWORK] menu ENGLISH - 89 7) When the confirmation is displayed, select [OK] or [CANCEL], and press t\ he button. Note f Not compatible with 10BaseT Full/Half. When the projector is connected directly via a twisted-pair-cable transm\ itter 1) Press as to select [DIGITAL LINK SETUP]. 2) Press the button. fThe [DIGIT AL LINK SETUP] screen is displayed. 3) Press as to select [DUPLEX(DIGITAL LINK)]. 4) Press qw to switch the communication method. fThe items will switch each time...
Page 90
![Page 90
Chapter 4 Settings — [NETWORK] menu
90 - ENGLISH
[NETWORK SETUP]
Perform the initial setting of the network before using the network func\
tion.
1) Press as to select [NETWORK SETUP].
2) Press the button.
fThe [NETWORK SETUP]
screen is displayed.
3) Press as to select an item, and change the settings according to the operation i\
nstructions of the
menu.
[PROJECTOR NAME] Change the setting when using a DHCP server.
[DHCP] Set to [ON] when obtaining an IP address automatically using a DHCP server. Set...](http://img.usermanuals.tech/thumb/58/94710/w300_panasonic-pt-rw330u-manual_d-89.png "Page 90
Chapter 4 Settings — [NETWORK] menu
90 - ENGLISH
[NETWORK SETUP]
Perform the initial setting of the network before using the network func\
tion.
1) Press as to select [NETWORK SETUP].
2) Press the button.
fThe [NETWORK SETUP]
screen is displayed.
3) Press as to select an item, and change the settings according to the operation i\
nstructions of the
menu.
[PROJECTOR NAME] Change the setting when using a DHCP server.
[DHCP] Set to [ON] when obtaining an IP address automatically using a DHCP server. Set...")
Chapter 4 Settings — [NETWORK] menu 90 - ENGLISH [NETWORK SETUP] Perform the initial setting of the network before using the network func\ tion. 1) Press as to select [NETWORK SETUP]. 2) Press the button. fThe [NETWORK SETUP] screen is displayed. 3) Press as to select an item, and change the settings according to the operation i\ nstructions of the menu. [PROJECTOR NAME] Change the setting when using a DHCP server. [DHCP] Set to [ON] when obtaining an IP address automatically using a DHCP server. Set...
