Panasonic Projector Pt Rw330u Operating Instructions

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 71
Setting [AUTO POWER SAVE]
Set whether to enable the three functions [AMBIENT LIGHT DETECTION], [SIGNAL DETECTION], and [AV MUTE DETECTION].
1) Press as to select [ECO MANAGEMENT].
2) Press the  button.
 fThe [ECO MANAGEMENT]
 screen is displayed.
3) Press as to select [AUTO POWER SAVE].
4) Press qw to switch [AUTO POWER SAVE].
 fThe items will switch each time you press the button.
[ON]
Enables power-saving mode.
[OFF] Disables power-saving mode....

Chapter 4 Settings — [PROJECTOR SETUP] menu
72 - ENGLISH
4) Press qw to switch [STANDBY MODE].
 fThe items will switch each time you press the button.
[ECO]
Use this setting to reduce power consumption during standby.
[NORMAL] Use this setting to use the network function during standby.
Note
 fWhen set to [ECO], network functions are not available during standby.
Also, some RS-232C commands are not available. When set to
[NORMAL], network functions are available during standby.
 f If set to [ECO],...

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 73
3) Select and assign program to each day of week.
 fPress
as to select the day of week, and press
qw to select a program number.
 fYou can set the program from No.1 to No.7. “- - -” indicates that the program number has not been set yet.
How to set a program
You can set up to 16 commands to each program.
1) Press as to select [SCHEDULE].
2) Press qw to select [ON], and press the  button.
 fThe [SCHEDULE]
 screen is displayed.
3) Press as to...

Chapter 4 Settings — [PROJECTOR SETUP] menu
74 - ENGLISH
12) Press the  button.
 fThe command is fixed and ● is displayed at the left of the selected command.
 fAfter the command is fixed, press the  button or the  button to close the detailed setting menu.
13) Press as to select [STORE], and press the  button.
Note
 f When deleting commands that have already been set, press the  button on the screen displayed in step 5). fIf multiple commands have been set for the same time, they are executed \
in...

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 75
[DIGITAL LINK INPUT]
Can only be selected when [STARTUP INPUT SELECT] is set to [DIGITAL LINK].
1) Press as to select [DIGITAL LINK INPUT].
2) Press qw to switch [DIGITAL LINK INPUT].
 fThe items will switch each time you press the button.
[CURRENT]
Switches to DIGITAL LINK input.
[INPUT1]
Switches to DIGITAL LINK input, and that input switches to specified input when the Panasonic
twisted-pair-cable transmitter is connected.
[INPUT2]
[INPUT3]...

Chapter 4 Settings — [PROJECTOR SETUP] menu
76 - ENGLISH
Communicating using the  terminal
1) Press as to select [RS-232C].
2) Press the  button.
 fThe [RS-232C]
 screen is displayed.
3) Press as to select [INPUT SELECT].
4) Press qw to switch [DIGITAL LINK].
5) Press as to select [PARITY].
6) Press qw to switch [PARITY].
 fThe items will switch each time you press the button.
[NONE]
Select the parity condition.
[EVEN]
[ODD]
Using existing projector control commands
Set each item when controlling the...

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 77
Note
 fRefer to “ terminal” (
x page 1 18). fWhen [DIGITAL

 LINK] is selected, communication is only available using the serial terminal when the relevant device (such as an optional
digital interface box (Model No.: ET-YFB100G)) is connected to the  terminal.
 f When transferring logos via the optional digital interface box (Model No.: ET
-YFB100G), “NO SIGNAL SLEEP” of ET

-YFB100G must be set
to “OFF” to avoid cutting off communication.
 f...

Chapter 4 Settings — [PROJECTOR SETUP] menu
78 - ENGLISH
Setting the audio output during standby
1) Press as to select [AUDIO SETTING].
2) Press the  button.
 fThe [AUDIO SETTING]
 screen is displayed.
3) Press as to select [IN STANDBY MODE].
4) Press qw to switch [IN STANDBY MODE].
 fThe items will switch each time you press the button.
[OFF]
Turns off audio output during standby.
[ON] Turns on audio output during standby.
Note
 fWhen [STANDBY MODE] (
x page 71) of [ECO MANAGEMENT] is set to [ECO],...

Chapter 4 Settings — [PROJECTOR SETUP] menu
ENGLISH - 79
[STATUS]
Displays the status of the projector.
1) Press as to select [STATUS].
2) Press the  button.
 fThe [STATUS] screen is displayed.
3) Press qw to switch the pages.
 fThe page will change each time you press the button.
[INPUT]
Displays the input terminal currently selected.
[SIGNAL NAME] Displays the input signal name.
[SIGNAL FREQUENCY] Displays the frequency of the input signal.
[PROJECTOR RUNTIME] Displays the operation times of the...

Chapter 4 Settings — [PROJECTOR SETUP] menu
80 - ENGLISH
Setting the date and time automatically
1) Press as to select [DATE AND TIME].
2) Press the  button.
 fThe [DATE AND TIME] screen is displayed.
3) Press as to select [ADJUST CLOCK].
4) Press the  button.
 fThe [ADJUST CLOCK]
 screen is displayed.
5) Press as to select [NTP SYNCHRONIZATION], and press qw to change the setting to [ON].
 fThe items will switch each time you press the button.
[OFF]
Disables [NTP SYNCHRONIZATION].
[ON] Enables [NTP...
