Stiga TITAN TITAN 740 DC TITAN 740 DCR Instructions Manual

81
ENGLISHEN
Original instructions for use
3.4.3.2 Adjusting steering wheel height (1:C2)
Do not adjust the steering wheel during
operation.
The height of the steeri ng wheel is steplessly ad-
justable.
Undo the knob on the steering column and raise or
lower the steering wheel to the desired position.
Tighten.
3.4.3.3 Headlamp and horn (1:C3) (740DCR)The lever has the following functions:
Horn
Turn signal lamps (1:N)
Parking lights
Headlights (1:M)
See the symbols on the control for the relevant...

82
ENGLISHEN
Original instructions for use
3.4.4.2 Ignition lock (1:E2)The ignition lock is used for starting and stopping
the engine.
Four positions:Preheat position:  The cylinders are heat-
ed to facilitate starting. Hold in this posi-
tion as below at lower temperatures before
starting the engine.
Max 5 seconds
Stop position:  The engine is stopped. The
key can be removed.
Operating position:  Bypassed at start-up
and used when the engine is running.
Start position:  The electric starter motor...

83
ENGLISHEN
Original instructions for use
3.4.4.9 Switch (1:Aux2fr)The switch has two positions and indicates
which hydraulic output will be activated
by the control (1:Aux2s). Front mounted
hydraulic output (1:Aux2f) or rear mounted hy-
dralic output (1:Aux2r).  See also 3.4.4.5
3.4.5 Controls - other
3.4.5.1 Locking pins front (1:D1)The machine has front and rear sockets for differ-
ent implements. The relevant implement is locked
by two locking pins after installation.
To secure the implement on...

84
ENGLISHEN
Original instructions for use
3.5.3 Indicator for turn signal/hazard warning lamps (1:I3)
The indicator flashes at the same time as the turn
signal lamps/hazard  warning lamps flash.
3.5.4 Brake indicator (1:I4)
Never operate the machin e with the brake indi-
cator illuminated. Parking brake and emergen-
cy brake will be affected.
The brake indicator gives a warning that
the parking brake (1:C7) is activated.
See 3.4.3.6.
3.5.5 Battery charging indicator (1:I5)
Never run the engine with...

85
ENGLISHEN
Original instructions for use
3.5.10 Air filter indicator (5:I10)
The indicator warns of a blocked air filter. If the in-
dicator is red, the air filter must be replaced. Then
reset the indicator by pressing its button.
3.5.11 Hydraulic oil level indicator (7:I11)
The oil level must be visible through the transpar-
ent glass when the machine is level.
If the oil level is too high there is a risk of oil flow-
ing out through the bleed valve. If the oil level is
too low there is a risk of an...

86
ENGLISHEN
Original instructions for use
Never use oil additives.
The oil level must never  go below the lower mark-
ing. This can cause the engine to overheat. Drain
the oil to the correct level if the oil level exceeds
the mark. See 6.7.
Reinstall the oil filer cap once the oil level has
been adjusted.
5.4 LEVEL CHECK, COOLANT
The temperature indicator will not
work if there is no coolant. This results
in engine failure.
Check the coolant level ev ery time before use to
ensure it is correct....

87
ENGLISHEN
Original instructions for use
5.7.1 General safety checks
5.7.2 Electric safety checkThe safety system’s  function must
always be checked before use.
5.8 START1.  Check that PTO is disengaged.
2.  Do not keep your foot  on the accelerator pedal.
3.  Set the throttle control to ¼ throttle.
4.  Depress the brake pedal fully. The indicator  lamp (1:I4) should illuminate.
5.  For cold starts at lower temperatures, the engine  should be preheated before  starting. See 3.4.4.2.
Then return...

88
ENGLISHEN
Original instructions for use
Depending on the implement used,
counter weights might have to be
mounted on the machine. The axle
pressure  of a wheel axle may never
exceed 900 kg or 70% of the total
weight of the machine
5.11 STOPDisengage PTO. Apply the parking brake.
Allow the engine to idle 1 - 2 mins. Stop the engine
by turning off the starter key.If the machine is left unattended,
remove the ignition key.
The engine may be very hot
immediately after it is  shut off. Do not...

89
ENGLISHEN
Original instructions for use
6.4 WATER SEPARATORThere is a float in the water separator (9:C3) that
can be viewed through the transparent cup. The
float must be at the bottom. If the float has risen,
the water separator must be drained.
To drain the water unscrew the drain tap (9:C1) un-
til the water begins to run. Drain until the float sits
at the bottom again.
Clean the separator if the it  looks dirty or if it has
to be drained often. The se parator is cleaned as fol-
lows:
1....

90
ENGLISHEN
Original instructions for use
9. Fill with new oil through the 3/8” return for PTO, see fig. 1. Use a pump with 10 micron fil-
ter.
Oil: See 2.1.
Oil quantity when changing: See 2.1.
10.After filling the oil, st art the engine and run the
machine for a few minutes and check for oil
leakage.
11.Check the oil level. See 3.5.11.
6.9 CHANGING THE OIL IN THE  WHEEL MOTORS
Change the oil in the gear housing of the wheel
motors as follows:
1. Operate the machine at varying workload for 5-
10...
