NEAX2400 IPX Feature Programming ManualPage 948NDA-24297, Issue 1
M-39 Modem Pooling - CCIS
Programming (cont’d)
1-4Wire
SPEED: 0
ASYNC: 0
FCY: 0
STEP 2:AT R K- To program the PA-M20 MODEM POOLING Trunk Circuit Card, assign the LEN Number,
MODEM POOLING Route Number (919 - 926), Trunk Number, and Tenant Number. Levels 0, 2, 4 &
6, of the corresponding group number where the PA-M20 Circuit Card is mounted are used for the
MODEM POOLING trunks.
MBTK- Assign the Make Idle status to the MODEM POOLING Trunks.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 949
Multiple Call Forwarding - All Calls - CCIS M-40
M-40  Multiple Call Forwarding - All Calls - CCIS
General Description
This service feature permits all calls destined for a particular station in a CCIS network to be routed to another station
or to the attendant multiple times, regardless of the busy or idle status of the called station.
With CALL FORWARDING-ALL CALLS [C-5] (CF-A):
With MULTIPLE CALL FORWARDING-ALL CALLS [M-44] service:...

NEAX2400 IPX Feature Programming ManualPage 950NDA-24297, Issue 1
M-40 Multiple Call Forwarding - All Calls - CCIS
Service Conditions (cont’d)
3. When CALL FORWARDING is performed in a CCIS network, the following services are not available
at a forwarded-to station:
CALL FORWARDING-ALL CALLS-OUTSIDE [C-28]
CALL FORWARDING-BUSY LINE-OUTSIDE [C-60]
CALL FORWARDING-DON’T ANSWER-OUTSIDE [C-74]
4. When a call is forwarded to the calling party by CALL FORWARDING-ALL CALLS - CCIS [M-40], the
calling party hears...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 951
Multiple Call Forwarding - All Calls - CCIS M-40
Service Conditions (cont’d)
5. SERVICE DISPLAY - CCIS [S-53] is available at the terminating node. The type of forwarding to be
displayed is CF ALL.
6. When a call is terminated to an ATTENDANT CONSOLE [A-3] by MULTIPLE CALL FORWARDING-
ALL CALLS - CCIS [M-40], the call type is ATND.
7. The system data (ASYD, SYS1, INDEX 486, bit 0-2) decides the maximum number of times for activating
a...

NEAX2400 IPX Feature Programming ManualPage 952NDA-24297, Issue 1
M-40 Multiple Call Forwarding - All Calls - CCIS
Service Conditions (cont’d)
The Calling party hears busy tone when the forwarding destination number, assigned to the last
intermediate party (intermediate party 2 in the example below), and the calling party number sent from the
calling party are not identical.
10. When Call Forwarding is restricted because the number of times data or the service restriction data, the
call is terminated to...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 953
Multiple Call Forwarding - All Calls - CCIS M-40
Service Conditions (cont’d)
Example 2: Multiple Call Forwarding - CCIS service is restricted because the service is not effective at
the node.
11. Even if Call Forwarding is set from the forwarded station to the forwarding station, the Call Forwarding
service is effective, as shown in the example below:
When Office A selects the number of times for Call Forwarding for 5 times, five times of...

NEAX2400 IPX Feature Programming ManualPage 954NDA-24297, Issue 1
M-40 Multiple Call Forwarding - All Calls - CCIS
Service Conditions (cont’d)
13. The following services are activated within one node, therefore, the number of times for these services are
independent. The maximum number of times for activating this feature is the same as previous software
releases:
MULTIPLE CALL FORWARDING - ALL CALLS [M-44]: 5 times
MULTIPLE CALL FORWARDING - BUSY LINE [M-24]: 5 times
MULTIPLE CALL FORWARDING - DON’T...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 955
Multiple Call Forwarding - All Calls - CCIS M-40
Service Conditions (cont’d)
b.) The service is restricted because the service has already been activated the predetermined number
of times.
c.) When Office A is not available for the enhanced Call Forwarding feature, the number of times the
service is activated is decided by Office B (three times are effective in this example). Note that
Call Forwarding service from Office A to Office B is...

NEAX2400 IPX Feature Programming ManualPage 956NDA-24297, Issue 1
M-40 Multiple Call Forwarding - All Calls - CCIS
Service Conditions (cont’d)
d.) The Call Forwarding service is activated four times, because the call is forwarded from Office D
to Office E through FCCS link:
Note:Call Forwarding service activated through FCCS link (Call Forwarding*) is not included in the number of
times that the Multiple Call Forwarding - CCIS service is activated.
e.) When the trunk/station incoming call terminates...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 957
Multiple Call Forwarding - All Calls - CCIS M-40
Interactions
When a calling party sets the services shown below while the destination party is in busy status, the services are
performed to the first forwarded party.
1. In the case of Busy Verification - CCIS [B-9] or Executive Right-of-Way - CCIS [E-8], the service is
effective to Station B in Office B. The service is invalid to station D.
a.) When Station B is in busy status, Busy...
