NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 918NDA-24297, Issue 1
F-12 Flexible Numbering of Stations - CCIS
F-12  Flexible Numbering of Stations - CCIS
General Description
This feature allows voice and data station numbers to be assigned to any instrument in the CCIS network, based
solely on numbering plan limitations.
Operating Procedure
Refer to the NEAX2400 IPX Office Data Specification.
Service Conditions
1. Careful consideration should be given to the network numbering plan to avoid needless loss...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 919
Hands-free Answerback - Dterm- CCIS H-10D
H-10D  Hands-free Answerback - Dterm - CCIS
General Description
ThisfeatureallowsaDtermuser to respond to a VOICE CALL - CCIS [V-7] without lifting the handset.
Operating Procedure
To answer
1. Lift the handset and press the line key to answer the call.
2. Press feature key and“1”; the MIC LED lights.
3. Press feature key and“5”to select hands-free operation.
4. Replace the handset; respond to...

NEAX2400 IPX Feature Programming ManualPage 920NDA-24297, Issue 1
H-11 House Phone - CCIS
H-11  House Phone - CCIS
General Description
This feature allows selected stations to call an Attendant Console through the CCIS network, simply by going off-
hook.
Operating Procedure
To call the Attendant
1. The HOUSE PHONE - CCIS user lifts the handset.
2. The Attendant is automatically called.
Service Conditions
1. Attendant Console indications will appear as follows:
a.) ATND lamp flashes.
b.) Console buzzer...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 921
Hotline - CCIS H-12
H-12  Hotline - CCIS
General Description
This feature allows two stations at different nodes in the CCIS network to be associated with one another on an
automatic ringdown basis.
Operating Procedure
1. Station A lifts the handset.
2. Station B is rung.
3. Station B lifts the handset; the connection is established.
Service Conditions
1. If both phones in a HOTLINE - CCIS pair are equipped with dials, either one may...

NEAX2400 IPX Feature Programming ManualPage 922NDA-24297, Issue 1
H-12 Hotline - CCIS
Programming
STEP 1:ASDT- Assign the station as a TEC = 14 for Hotline.
STEP 2:AHLS- Assign the station number programmed above for the following parameters:
HOT TN: HOTLINE Tenant
STN: HOTLINE Station
TYP: 2
ADC: Abbreviated Digit Code
STEP 3:ASPD- Assign tenant, Abbreviated Digit Code (ADC) and Digit Code (DC).

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 923
Incoming Call Identification - CCIS I-16
I-16  Incoming Call Identification - CCIS
General Description
This feature allows an Attendant to visually identify the type of service and/or trunk route which is arriving or
waiting to be answered at the Attendant Console through CCIS.
Operating Procedure
No manual operation is required.
Service Conditions
1. A flashing lamp indicates a call waiting to be answered.
2. A steady lamp indicates an...

NEAX2400 IPX Feature Programming ManualPage 924NDA-24297, Issue 1
I-16 Incoming Call Identification - CCIS
Programming (cont’d)
Index 8
Bit 0-Listed Directory Number
Bit 1-Incoming Station Call
Bit 2-Attendant Recall
Bit 3-FX
Bit 4-WATS
Bit 5-CCSA (DID)
Bit 6-TIE Line
Bit7-CallForwardingBusyLine
Index 9
Bit0-CallForwardingDon’tAnswer
Bit 1-Call Forwarding Intercept
Bit 2-TF ASAT
Bit 3-Supervisory Call
Note:System Data 2, Index 8, Bits 6 & 7, and System Data 2, Index 9, Bit 0-3 can be assigned different...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 925
Individual Attendant Access - CCIS I-17
I-17  Individual Attendant Access - CCIS
General Description
This feature permits a user to call a particular Attendant Console in the CCIS network, via an individual Attendant
Identification Number.
Operating Procedure
1. The user dials an individual Attendant Identification Number.
2. The directed Attendant receives an INCOMING CALL IDENTIFICATION [I-16] indication and can
answer using the normal...

NEAX2400 IPX Feature Programming ManualPage 926NDA-24297, Issue 1
I-18 Inter-Position Transfer - CCIS
I-18  Inter-Position Transfer - CCIS
General Description
This feature allows calls to be transferred from one Attendant Console to another through the CCIS network.
Operating Procedure
To transfer from Console A to Console B
1. Attendant A presses the START key.
2. Attendant A dials the Attendant Console B Identification Number, or“0”for all Attendant Consoles.
3. The call is indicated at Attendant...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 927
Look Ahead Routing - CCIS L-25
L-25  Look Ahead Routing - CCIS
General Description
This feature allows a station to dial a Public Switched Telephone Network (PSTN) call and has the capability of
looking ahead to seven directly-connected nodes in the CCIS network for an idle trunk.
Operating Procedure
1. Lift the handset; receive dial tone.
2. Dial the access code; receive second dial tone.
3. Dial the PSTN number.
4. The system completes...
