NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 958NDA-24297, Issue 1
M-40 Multiple Call Forwarding - All Calls - CCIS
Interactions (cont’d)
3. InthecaseofCallBack-CCIS[C-44],serviceiseffectivetoStationBinOfficeB.Theserviceisinvalid
to station D.
4. In the case of Step Call - CCIS [S-59], the service is valid to Station B in Office B. The service is invalid
to station D.
Programming
STEP 1:ASYD- System Data 1, Index 69, Bit 1: Call Forward All Calls short tone service 0/1 = Not Required/
Required. Bit 7: (1)...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 959
Multiple Call Forwarding - All Calls - CCIS M-40
Programming (cont’d)
STEP 3:ASPA- Sets the access codes for Call Forwarding-All Calls.
For setting: CI = N (Normal), SRV = SSC (Service Code), SID = 8
For Cancel: CI = N (Normal), SRV = SSC (Service Code), SID = 9
STEP 4:AT N R- Assign the allowable data into the corresponding items of Tenant Restriction Index.

NEAX2400 IPX Feature Programming ManualPage 960NDA-24297, Issue 1
M-41 Multiple Call Forwarding - Busy Line - CCIS
M-41  Multiple Call Forwarding - Busy Line - CCIS
General Description
This service feature permits a call to a busy station to be forwarded in a CCIS network, multiple times, to a
predesignated idle station.
1. With existing CALL FORWARDING-BUSY LINE [C-2] (CF-B) service:
2. With MULTIPLE CALL FORWARDING-BUSY LINE [M-24] service:
Operating Procedure
1. Station A sets Call Forwarding-Busy...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 961
Multiple Call Forwarding - Busy Line - CCIS M-41
Service Conditions (cont’d)
3. When CALL FORWARDING is performed in a CCIS network, the following services are not available
at a forwarded-to-station:
CALL FORWARDING-ALL CALLS-OUTSIDE [C-28]
CALL FORWARDING-BUSY LINE-OUTSIDE [C-60]
CALL FORWARDING-DON’T ANSWER-OUTSIDE [C-74]
4. When a call is forwarded to the calling party by CALL FORWARDING-BUSY LINE - CCIS [M-41], the
calling party...

NEAX2400 IPX Feature Programming ManualPage 962NDA-24297, Issue 1
M-41 Multiple Call Forwarding - Busy Line - CCIS
Service Conditions (cont’d)
5. SERVICE DISPLAY - CCIS [S-53] is available at the terminating node. The type of forwarding to be
displayed is CF BUSY.
6. When a call is terminated to an ATTENDANT CONSOLE [A-3] by the MULTIPLE CALL
FORWARDING-BUSY LINE - CCIS [M-41], the call type is BUSY.
7. The system data (ASYD, SYS1, Index 486, bit 0-2) decides the maximum number of times for activating
a...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 963
Multiple Call Forwarding - Busy Line - CCIS M-41
Service Conditions (cont’d)
The Calling party hears busy tone when the forwarding destination number, assigned to the last
intermediate party (intermediate party 2 in the example below), and the calling party number sent from the
calling party are not identical.
10. When Call Forwarding is restricted because the number of times data or service restriction data, the caller
hears busy tone....

NEAX2400 IPX Feature Programming ManualPage 964NDA-24297, Issue 1
M-41 Multiple Call Forwarding - Busy Line - CCIS
Service Conditions (cont’d)
13. The following services are activated within one node. The maximum number of times for activating this
feature is the same as previous software releases:
MULTIPLE CALL FORWARDING - ALL CALLS [M-44]: 5 times
MULTIPLE CALL FORWARDING - BUSY LINE [M-24]: 5 times
MULTIPLE CALL FORWARDING - DON’T ANSWER [M-25]: unlimited
14. The following are detailed examples of...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 965
Multiple Call Forwarding - Busy Line - CCIS M-41
Service Conditions (cont’d)
b.) The service is restricted because the service has already been activated the predetermined number
of times.
c.) When Office A is not available for the enhanced Call Forwarding feature, the number of times the
service is activated is decided by Office B (three times are effective in this example). Note that
Call Forwarding service from Office A to Office B is...

NEAX2400 IPX Feature Programming ManualPage 966NDA-24297, Issue 1
M-41 Multiple Call Forwarding - Busy Line - CCIS
Service Conditions (cont’d)
d.) The Call Forwarding service is activated four times, because the call is forwarded from Office D
to Office E through FCCS link:
Note:Call Forwarding service activated through FCCS link (C.F.*) is not included in the number of times that
the Multiple Call Forwarding - CCIS service is activated.
e.) When the trunk/station incoming call terminates through FCCS...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 967
Multiple Call Forwarding - Busy Line - CCIS M-41
Service Conditions (cont’d)
f.) This service is restricted when a call from the CCIS line is forwarded to other lines except CCIS
(for example: C.O. line).
Interactions
When a calling party sets the services shown below while the destination party is in busy status, the services are
performed to the first forwarded party.
1. In the case of Busy Verification - CCIS [B-9] or Executive...
