NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 938NDA-24297, Issue 1
M-34D Message Reminder - Dterm- CCIS
Service Conditions
1. This feature is only available between two Dtermsets that both have the MESSAGE feature key. If a
messageisdirectedtoasinglelineoraDtermthat does not have the MESSAGE REMINDER feature, the
calling stations LCD displays:
2. Messages cannot be sent while engaged in calling or recall from CALL TRANSFER - ALL CALLS [C-
11] [C-50] or from CONSULTATION HOLD - ALL CALLS [C-17] [C-58].
3....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 939
Message Reminder - Dterm- CCIS M-34D
Programming (cont’d)
STEP 3:ASPA- Assign an access code to MESSAGE REMINDER; assign SRV = SSCA (Service Code
Appendix), SIDA = 42. Assign a Connection Index of Normal (N) and Busy (B).
STEP 4:ASFC- Assign to the single-line stations that will have MESSAGE REMINDER a Service Feature
Class that allows SFI 53.
 Note
STEP 5:AKYD- Assign the station according to the following parameters:
TN: 1
STN: Station...

NEAX2400 IPX Feature Programming ManualPage 940NDA-24297, Issue 1
M-35 Message Waiting Lamp Setting - Attendant - CCIS
M-35  Message Waiting Lamp Setting - Attendant -
CCIS
General Description
This service feature allows the MESSAGE WAITING (MW) lamp on the Dtermor telephone set, equipped with MW
lamp accommodated in the Satellite Offices, to be controlled from the Attendant Console in the CCIS network.
Operating Procedure
To set MW Indication
1. The Attendant in Node A presses an idle loop key.
2. The...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 941
Message Waiting Lamp Setting - Attendant - CCIS M-35
Programming
STEP 1:ANPD- Assign minimum necessary number of digits for the first number of the access code and
connection index for MW service.
STEP 2:ASPA- Assign the access code and connection index for MW service.
To Set: CI = N (Normal), SRV = SSCA (Service Code Appendix), SIDA = 54
To Cancel: CI = N (Normal), SRV = SSCA (Service Code Appendix), SIDA = 55
STEP 3:ASFC- Allow MW Lamp...

NEAX2400 IPX Feature Programming ManualPage 942NDA-24297, Issue 1
M-36 Message Waiting Lamp Setting - Station - CCIS
M-36  Message Waiting Lamp Setting - Station - CCIS
General Description
This feature allows any Dtermor single line telephone to set/cancel a MESSAGE WAITING indication or lamp at
any other station equipped with this feature in the CCIS network.
Operating Procedure
To set from a single line telephone
1. Lift the handset; receive dial tone.
2. Dial the MESSAGE WAITING LAMP SETTING (SET)...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 943
Message Waiting Lamp Setting - Station - CCIS M-36
Service Conditions (cont’d)
6. If a user attempts to set MESSAGE WAITING to a station where MESSAGE WAITING has already been
set, busy tone will be sent to the station, and the Dtermphones will display:
7. When a station is restricted from MESSAGE WAITING LAMP SETTING-STATION - CCIS or is an
unused telephone number, and another user attempts to set/cancel MESSAGE WAITING LAMP...

NEAX2400 IPX Feature Programming ManualPage 944NDA-24297, Issue 1
M-37 Miscellaneous Trunk Access - CCIS
M-37  Miscellaneous Trunk Access - CCIS
General Description
This feature provides access through the CCIS network to all types of external and customer provided equipment/
facilities, such as TIE LINE ACCESS [T-3], as well as DICTATION ACCESS [D-3], PAGING ACCESS - CCIS,
and CODE CALLING ACCESS [C-21].
Operating Procedure
MISCELLANEOUS TRUNK ACCESS - CCIS is programmed in system data via the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 945
Miscellaneous Trunk Restriction - CCIS M-38
M-38  Miscellaneous Trunk Restriction - CCIS
General Description
This feature allows certain stations and dial-repeating TIE Line trunks to be denied access through CCIS to certain
trunk routes, such as TIE LINE ACCESS [T-3], as well as the Exchange Network, DICTATION ACCESS [D-3],
or PAGING ACCESS - CCIS [P-28].
Operating Procedure
No manual operation is required. Restricted stations will...

NEAX2400 IPX Feature Programming ManualPage 946NDA-24297, Issue 1
M-39 Modem Pooling - CCIS
M-39  Modem Pooling - CCIS
General Description
This feature allows any terminal to have access to a data terminal in a different office through a concentration of
modem groups, set at different data speeds, using the Common Channel Inter-Office Signaling System.
A maximum of 8 Modem Groups are provided. One modem in the group is selected by the data station, at the time
of Modem Pool selection. Least Cost Routing...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 947
Modem Pooling - CCIS M-39
Service Conditions (cont’d)
8. Distinctive Ringing - Most modems recognize only a 2-second on, 1-second off ring. This consideration
must be taken into account when defining incoming trunk ringing.
9. The Reverse or Secondary Channel feature of modems is not implemented on the Modem Pool card.
10. Speed Select using pin 23 on the EIA RS232 connector is not implemented.
11. Intelligent or Auto Dial Modems must be...
