NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 898NDA-24297, Issue 1
D-73 Digital Display - Trunk - CCIS
Service Conditions (cont’d)
Example 2: Trunk
Interactions
1. For display purposes only, Route and Trunk numbers and Central Office Codes may be used
simultaneously in the same system and are applied on a per-route basis, via ARTD, CDN 25:R/L.
2. If System Data 1, Index 68 bit 2 is assigned for Individual Trunk Access to be the ACOC code, then all
trunks in all routes in the system must have the ACOC...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 899
Direct-In Termination - CCIS D-74
D-74  Direct-In Termination - CCIS
General Description
This service feature allows Inter-Office Direct-In Termination for a case where an incoming call addressed to a
station in a PBX from a C.O. line is to be terminated to a station belonging to a different PBX in the CCIS network.
Operating Procedure
1. A DIT call terminates to Node A.
2. The DIT call terminates to Node B through CCIS and rings station...

NEAX2400 IPX Feature Programming ManualPage 900NDA-24297, Issue 1
D-74 Direct-In Termination - CCIS
Service Conditions (cont’d)
c.) In case the call is terminated via tandem connection (the call is originated from ISDN line and
CCIS line is intermediate interface), the call is disconnected (the call is not forwarded to
Attendant Console irrespective of the system data).
4. If there is no answer at a station, the calling party will continue to receive Ring Back Tone. There is no
AUTOMATIC RECALL [A-8] to...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 901
Distinctive Ringing - CCIS D-75
D-75  Distinctive Ringing - CCIS
General Description
This service feature allows Inter-Office Distinctive Ringing for a call terminated from a different PBX in the CCIS
network.
Operating Procedure
1. Station (c) and the Attendant in Node A are engaging in a call.
2. The Attendant dials the number for Station (b); receives ringback tone. Station (c) receives Hold Tone,
and Station (b) is rung (Distinctive...

NEAX2400 IPX Feature Programming ManualPage 902NDA-24297, Issue 1
D-75 Distinctive Ringing - CCIS
Programming
STEP 1:ASYD- System 1, Index 72, Bit 6.
Distinctive ringing only for DIT and DID calls.
System 3, Index 0: Assign the timer value of the ringer used at the time of local line incoming. (ringer
pattern 0).
System 3, Index 1: Assign the timer values of the ringer used at the time of station call. (ringer pattern
1).
System 3, Index 3, Bit 0: 2 burst (0.4 sec-ON, 0.2 sec-OFF, 0.4 sec-ON) ON-Timer...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 903
Do Not Disturb - Dterm- CCIS D-76D
D-76D  Do Not Disturb - Dterm - CCIS
General Description
This feature allows a Dtermuser to temporarily establish a DO NOT DISTURB status, during which time incoming
CCIS calls will be denied access to the MY-Line of the Dterm.
Operating Procedure
To set
1. Press the DO NOT DISTURB (DND) key. The associated LED will light. The LCD displays:
To cancel
1. Press the DO NOT DISTURB (DND) key. The associated...

NEAX2400 IPX Feature Programming ManualPage 904NDA-24297, Issue 1
D-76D Do Not Disturb - Dterm- CCIS
Interactions
1. DATA INTERFACE-AUTOMATIC ANSWER - CCIS [D-65] may not be activated if the Dtermstation
is in the DND mode.
2. CALL FORWARDING-BUSY LINE - CCIS [C-45]: This feature can be activated to an idle station that
has set DO NOT DISTURB - CCIS.
Programming
STEP 1:AKYD- When assigning key data for the Dterm, assign the following:
TN: 1
STN: Station Number
TP: Type of D
term0/1:
RING:
0: No Ringing...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 905
Data Hotline - CCIS D-86
D-86  Data Hotline - CCIS
General Description
This feature allows data stations to access Data Terminal Equipment (DTE) in a satellite office of a CCIS network,
by automatically dialing a SPEED CALLING-SYSTEM [S-3] number.
Operating Procedure
1. Manual CALL Origination via a Data Adapter:
a.) Press the D
termDATA key
b.) The DATA lamp will flash and the calling Dtermwill display the following:
2. Manual Call...

NEAX2400 IPX Feature Programming ManualPage 906NDA-24297, Issue 1
D-86 Data Hotline - CCIS
Interactions (cont’d)
4. TOLL DIVERSION/TOLL DENIAL [T-6] and TOLL RESTRICTION-3/6 DIGIT [T-7] will not interact
with this feature if a station is allowed access to an ADC via Service Feature Class.
5. This feature designates the use of a SPEED CALLING-SYSTEM [S-3] number when the DATA key is
activated.
6. UNIVERSAL SENDER [U-3] must also be provided.
Programming
STEP 1:ASDT- Assign the Data Terminal Number.
STEP...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 907
Data Hotline - CCIS D-86
Programming (cont’d)
STN: Hotline Station Number
TYPE: Connection Type
2: ADC
ADC: Speed Calling Code (2 or 3 digits)
STEP 8:ADA2- Assign Terminal Attribute Data 2, HL = 1 Hotline terminal connection.
CDN: Counter Display Number
13: HL (Hotline Terminal)
HL: 0/1
1: Hotline
