NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 908NDA-24297, Issue 1
D-91 Dialed Number Display - Recall - CCIS
D-91  Dialed Number Display - Recall - CCIS
General Description
When the Attendant Console makes an outgoing call to a CCIS line by means of a tandem connection, and the
Attendant has left the call by pressing the RELEASE button before the called Party answers, the Attendant Console
will be recalled if the Called Party does not answer. This service feature changes the display, when the Recall is...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 909
Dialed Number Display - Recall - CCIS D-91
Operating Procedure (cont’d)
4. If, after a predetermined time has elapsed, Subscriber (a) is not connected with Station (b), the call is
recalled to the Attendant Console in Node A and it answers. Press the DEST key; the dialed number of
Station (b) is indicated. Station (b) continues to ring until the Attendant presses CANCEL Key.
Service Conditions
If the called party answers after the...

NEAX2400 IPX Feature Programming ManualPage 910NDA-24297, Issue 1
D-93D Dual Hold Dterm- CCIS
D-93D Dual Hold Dterm - CCIS
General Description
This feature allows two connected Dterms to simultaneously be placed on non-exclusive hold over a CCIS link. This
enables the held parties to answer or originate a call from a sub-line appearance or the idle Prime Line.
Operating Procedure
To place a call
1. When two Dterms are connected via CCIS, either Dtermuser can press the HOLD button and place the other...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 911
Executive Right-of-Way - CCIS E-8
E-8  Executive Right-of-Way - CCIS
General Description
This service feature allows Inter-Office Executive Right-of-Way when the bridging-in station and the bridged
station respectively, belong to a different PBX in the CCIS network.
Operating Procedure
1. While Stations A and B are engaging in a call, Station C goes off-hook and receives dial tone.
2. Station C dials the number for Station B and receives...

NEAX2400 IPX Feature Programming ManualPage 912NDA-24297, Issue 1
E-8 Executive Right-of-Way - CCIS
Operating Procedure (cont’d)
5. Station A hangs up; Stations C and B remain connected with each other until either or both go on-hook.
Service Conditions
1. Two burst tones are transmitted upon activation to alert connected parties that an EXECUTIVE override
connection is being made.
2. EXECUTIVE Right-of-Way may be denied if the busy station is:
a.) Dialing or in LINE LOCKOUT [L-3]
b.) Listening to a...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 913
Executive Right-of-Way - CCIS E-8
Programming (cont’d)
STEP 4:ASFC- Assigns Executive Right-of-Way Calling (SFI = 3) to the SFC of the station setting Executive
Right-of-Way. Also assigns Executive Right-of-Way-Called (SFI = 4) and Attendant Camp-On (SFI =
11) to the SFC of the station to which Executive Right-of-Way is set. At the remote node, assign SFI 3,
4 and 11 to SFC 0.
STEP 5:AT R K- Assigns the trunk for 3-Way Calling (assigned...

NEAX2400 IPX Feature Programming ManualPage 914NDA-24297, Issue 1
E-9 Elapsed Time Display - CCIS
E-9  Elapsed Time Display - CCIS
General Description
This feature provides an LCD display of the time elapsed while a Dtermis connected to any trunk through the CCIS
network.
Operating Procedure
No manual operation is required.
Service Conditions
1. The elapsed time is displayed in the eight left-side positions of the LCD display.
2. The elapsed time can reach a maximum of 9 hours, 59 minutes and 59 seconds,...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 915
E911 - ANI Unified Number of Digits - CCIS E-20
E-20  E911 - ANI Unified Number of Digits - CCIS
General Description
This feature allows a station or Attendant Console, called via CCIS, to perform E911-ANI service. This feature is
functionally identical to AUTOMATIC NUMBER IDENTIFICATION (ANI) [A-87].
Operating Procedure
The operating procedure is the same as that of a normal outgoing connection.
Service Conditions
1. This feature is...

NEAX2400 IPX Feature Programming ManualPage 916NDA-24297, Issue 1
E-20 E911 - ANI Unified Number of Digits - CCIS
Service Conditions (cont’d)
If OG call is from an ATTCON and Individual ATT Access Code is assigned, and also ANI
data is assigned:
KP-0
-N**-****-ST
If OG call is from an ATTCON and Individual ATT Access Code is unassigned, and ANI data
is assigned:
KP-0
-N**-****-ST
If OG call is from an ATTCON and ANI data is unassigned:
KP-1
-ST
b.) Outgoing call from station/Attendant Console of...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 917
E911 - ANI Unified Number of Digits - CCIS E-20
Service Conditions (cont’d)
The COC digit is 82; then assign ANI information.
Example 2:
Office number: 826
Station number: 34xxx, 4xxx
The COC digit is 826; then assign ANI information.
11. After digits have been sent out, DDD seizure tone is not sent.
12. Other interactions are the same as those of outgoing calls by MF signalling.
13. An 8RST-K circuit card is used for this service.
14....
