NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 488NDA-24297, Issue 1
M-23 Message Waiting Lamp Setting - Attendant
M-23  Message Waiting Lamp Setting - Attendant
General Description
This feature permits an ATTENDANT CONSOLE [A-3] to set or cancel a Message Waiting indication on a station
provided with this feature.
Operating Procedure
To set a Message Waiting indication
1. Press an idle loop key.
2. Dial the Message Waiting set code (up to 3 digits); receive special dial tone.
3. Dial the telephone number;...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 489
Message Waiting Lamp Setting - Attendant M-23
Service Conditions (cont’d)
7. When Call Indicator LampNoteis controlled by MESSAGE WAITING LAMP SETTING - STATION
[M-30], the tone and display indication of the Attendant Console and Call Indicator Lamp of the station
are as follows, depending on the status of the station.
Interactions
1. For MESSAGE WAITING LAMP SETTING-ATTENDANT, an 8DLC/16ELC card is required.
2. An external power source...

NEAX2400 IPX Feature Programming ManualPage 490NDA-24297, Issue 1
M-23 Message Waiting Lamp Setting - Attendant
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending
on the node.
STEP 1:ANPDL- Reserve a number level for feature access and cancel. Assign...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 491
Multiple Call Forwarding - Busy Line M-24
M-24  Multiple Call Forwarding - Busy Line
General Description
This feature permits a call to a busy station to be forwarded, a maximum of five times, to preprogrammed idle
stations.
Existing CALL FORWARDING - BUSY LINE [C-2] service
MULTIPLE CALL FORWARDING - BUSY LINE [M-24] service
Operating Procedure
To set from an individual station
1. Lift the handset; receive dial tone.
2. Dial the specific...

NEAX2400 IPX Feature Programming ManualPage 492NDA-24297, Issue 1
M-24 Multiple Call Forwarding - Busy Line
Operating Procedure (cont’d)
4. Dial the originating telephone number.
5. Dial the desired target telephone number; receive service set tone.
To cancel from the ATTENDANT CONSOLE [A-3]
1. Press an idle loop key.
2. Dial the CALL FORWARDING - BUSY LINE [C-2] cancel code; receive special dial tone.
3. Dial the TENANT [T-12] number (2 or 3 digits).
4. Dial the originating telephone number; receive...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 493
Multiple Call Forwarding - Busy Line M-24
Service Conditions (cont’d)
e.) If a forwarding destination is the originally called station, and if the originally called station
forwarded the call with CALL FORWARDING - BUSY LINE, the ultimate destination is the
originally called station.
f.) If the call is forwarded to a station where it has previously been forwarded to, the call will end at
that station.
6. CALL FORWARDING - ALL CALLS [C-5],...

NEAX2400 IPX Feature Programming ManualPage 494NDA-24297, Issue 1
M-24 Multiple Call Forwarding - Busy Line
Service Conditions (cont’d)
7. Forwarding to an Attendant Console:
a.) If an Attendant Console is designated as the destination of CALL FORWARDING - ALL
CALLS [C-5], the call is forwarded to the Attendant Console that handles the tenant to which the
calling station belongs.
b.) The Attendant Console key that lights when a call is forwarded to the console depends on the
forwarding status of the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 495
Multiple Call Forwarding - Busy Line M-24
Service Conditions (cont’d)
11. Busy Services such as EXECUTIVE OVERRIDE [E-1], CALL BACK [C-1], etc.:
a.) Busy service is provided to the busy line closest to the originally called station.
12. DIT, NIGHT CONNECTION - FIXED [N-1]:
a.) For CALL FORWARDING - ALL CALLS [C-5] and CALL FORWARDING - BUSY LINE [C-
2], a forward check is made up to 5 times by system data.
b.) In DIRECT-IN TERMINATION...

NEAX2400 IPX Feature Programming ManualPage 496NDA-24297, Issue 1
M-24 Multiple Call Forwarding - Busy Line
Interactions (cont’d)
5. If an Attendant attempts BUSY VERIFICATION [B-3] to Station A, which has CALL FORWARDING-
BUSY LINE [C-2] set to Station B and Station B is busy, BUSY VERIFICATION [B-3] proceeds against
Station B. If Station A has set CALL FORWARDING-BUSY LINE [C-2] to the Attendant Console,
BUSY VERIFICATION [B-3] is allowed at Station A, if Station A is busy.
6. When CALL FORWARDING-BUSY...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 497
Multiple Call Forwarding - Busy Line M-24
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending
on the node.
Note
STEP 1:ASYDN- These data must be set to the NCN.
System Data 1, Index 69, b7....
