NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 508NDA-24297, Issue 1
M-26 Message Center Interface
Interactions (cont’d)
b.) The MC, though provided outside the FCCS network, can also control the Message Waiting
Lamp for each station on the FCCS service link, as well as ON/OFF indication of the lamps for
stations on the CCIS link.
4. In case the Message Center exists only on the side of FCCS network:
a.) Message data will be transmitted to the offered MC (in the figure below, assumed to be connected
to node...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 509
Message Center Interface M-26
Programming
STEP 1:ASYD- System Data 1, Index 28, Bits 0-4. Assign a Miscellaneous Timer Counter (MTC) used to
calculate the message-sending Guard Timer for Message Center.
Timer = MTC x 128ms. Normally a Guard Timer is not required. If not required, assign data“0”to
these bits.
System Data 1, Index 28, Bit 5. Is Message Waiting Lamp setting from the Message Center to be used?
0/1: No/Yes.
System Data 1,...

NEAX2400 IPX Feature Programming ManualPage 510NDA-24297, Issue 1
M-26 Message Center Interface
FCCS Programming (cont’d)
STEP 2:AMWF- Assign FPC (Fusion Point Code) of the node for being controlled the MWL on the Dtermby
the MC.
Note 1
Note 1:
Assign this data to the node accommodating the MC.
Note 2:Assign this data to all the nodes to be provided MCI service.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 511
Message Waiting Lamp Setting - Station M-30
M-30  Message Waiting Lamp Setting - Station
General Description
This feature allows a station to set/cancel a Message Waiting indication or lamp. Any single line telephone or Dterm
can set/cancel Message Waiting indication to any single line telephone equipped with a 90v neon lamp, or a Dterm.
Note:Call Indicator Lamp on DtermSeries E is used as the Message Waiting Lamp.
Operating Procedure...

NEAX2400 IPX Feature Programming ManualPage 512NDA-24297, Issue 1
M-30 Message Waiting Lamp Setting - Station
Operating Procedure (cont’d)
To cancel a Message Waiting Indication from a Dterm or MY Line
1. Lift the handset or press the SPEAKER key; receive dial tone.
2. Press the Message Waiting Cancel line/feature key, receive special dial tone.
3. Dial the desired telephone number; the LCD displays, and service set tone is heard.:
4. Message Waiting indication is cancelled.
Service Conditions
1. Any...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 513
Message Waiting Lamp Setting - Station M-30
Service Conditions (cont’d)
7. The LCD on the DtermSeries E station displays the following messages:
Interactions
1. For MESSAGE WAITING LAMP SETTING-STATION, the 8DLC/16ELC card is required.
2. An external power source is required to light a single line telephone lamp. The non-display D
termsusean
80 VDC power source. NEC stocks Lorain Model HSA3H.
3. The use of the following features has no...

NEAX2400 IPX Feature Programming ManualPage 514NDA-24297, Issue 1
M-30 Message Waiting Lamp Setting - Station
Interactions (cont’d)
4. When an incoming call is answered by the sub-line appearance on another station, the following services
may be activated either by the answering station or by another station towards the answering station. These
services will not interfere with the answering station’s ability to leave a Message Waiting indication.
PRIVACY-D
term[P-14D]
CONSULTATION HOLD-ALL CALLS [C-17]...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 515
Multiple Call Forwarding - All Calls M-44
M-44  Multiple Call Forwarding - All Calls
General Description
This feature permits a call to a CALL FORWARDING - ALL CALLS station to be forwarded multiple times to a
predesignated idle station.
Operating Procedure
To set from an individual station
1. Lift the handset; receive dial tone.
2. Dial the specific CALL FORWARDING - ALL CALLS access code; receive special dial tone.
3. Dial the desired...

NEAX2400 IPX Feature Programming ManualPage 516NDA-24297, Issue 1
M-44 Multiple Call Forwarding - All Calls
Service Conditions (cont’d)
c.) If a sequence of CALL FORWARDING - ALL CALLS [C-5] and CALL FORWARDING -
BUSY LINE [C-2] forwards the call back to the originating station, the forward is not made and
the caller hears a busy tone.
d.) If a sequence of CALL FORWARDING - ALL CALLS [C-5] and CALL FORWARDING -
BUSY LINE [C-2] forwards the call back to the originally called station, and if that station...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 517
Multiple Call Forwarding - All Calls M-44
Service Conditions (cont’d)
b.) The Attendant Console key that lights when a call is forwarded to the console depends on the
forwarding status of the originally called station (except in paragraph c). The following table
shows the key that will light; e.g., the BUSY key will light, if the forwarding status of the
originally called station is CALL FORWARDING - BUSY LINE [C-2], and the call is from...
