NEAX2400 IPX Feature Programming ManualPage 498NDA-24297, Issue 1
M-25 Multiple Call Forwarding - Don’tAnswer
M-25  Multiple Call Forwarding - Don’t Answer
General Description
This feature permits a call to an unanswered station to be forwarded, multiple times, to preprogrammed idle stations
that do not have Call Forwarding set.
Operating Procedure
To set from an individual station
1. Lift the handset; receive dial tone.
2. Dial the specific CALL FORWARDING - DONT ANSWER [C-3] access code; receive...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 499
Multiple Call Forwarding - Don’tAnswer M-25
Service Conditions (cont’d)
d.) If the forwarding sequence, after a CALL FORWARDING - DONT ANSWER [C-3] goes
through several stations with CALL FORWARDING - ALL CALLS [C-5] set and ends up at the
original CALL FORWARDING - DONT ANSWER [C-3] station, CALL FORWARDING -
DONT ANSWER [C-3] is not activated.
e.) If the forwarding sequence, after a CALL FORWARDING - DONT ANSWER [C-3] goes
through...

NEAX2400 IPX Feature Programming ManualPage 500NDA-24297, Issue 1
M-25 Multiple Call Forwarding - Don’tAnswer
Service Conditions (cont’d)
b.) The Attendant Console key that lights when a call is forwarded to the console depends on the
forwarding status of the originally called station (except in case c). The following table shows the
key that will light (e.g., if the forwarding status of the originally called station is CALL
FORWARDING - BUSY LINE [C-2], and the call is from a station, then the BUSY key...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 501
Multiple Call Forwarding - Don’tAnswer M-25
Interactions
1. If access codes for CALL FORWARDING-BUSY LINE [C-2] and CALL FORWARDING-DON’T
ANSWER [C-3] are the same, only one key needs to be assigned in AKYD or ADSL, and only one access
code needs to be assigned in ASPA.
2. Any UCD station is allowed to activate CALL FORWARDING-DON’T ANSWER [C-3]. When this
station sets CALL FORWARDING-DON’T ANSWER [C-3], calls directed to this station...

NEAX2400 IPX Feature Programming ManualPage 502NDA-24297, Issue 1
M-25 Multiple Call Forwarding - Don’tAnswer
Programming (cont’d)
STEP 6:ADSL- Assign SN=1 (Originating; DT Connection) and FKY=22 (Call Forwarding - Don’tAnswer;
FDN).
This command is used for assigning the function to a soft key.
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 503
Message Center Interface M-26
M-26 Message Center Interface
General Description
This feature provides an interface to an external CPU for Message Center information when a specific UCD [U-1]
group or ATTENDANT CONSOLE [A-3] is called. This interface allows external control of Call Indicator Lamp
indications on equipped NEAX2400 IPX stations. This feature also provides a socket interface (LAN interface) for
connection to an external LAN....

NEAX2400 IPX Feature Programming ManualPage 504NDA-24297, Issue 1
M-26 Message Center Interface
Operating Procedure (cont’d)
4. The called station will be able to receive a message by dialing“0”, or by a computer terminal by entering
his/her identification number.
5. The external CPU, upon receiving retrieved message information, will transmit a data record requesting
the NEAX2400 IPX to extinguish the Call Indicator Lamp of the corresponding station.
Service Conditions
1. The call type is sent to the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 505
Message Center Interface M-26
Service Conditions (cont’d)
4. If the Host/CPU malfunctions and stops collecting call records, the NEAX2400 IPX can store up to 16/32
call records. If the maximum of 16/32 call records is stored and a 17th/33rd is generated, the system will
write over the oldest stored record, thus giving the stack the most recently generated call records.
5. MCI data will not be output when a hotline station is terminated to...

NEAX2400 IPX Feature Programming ManualPage 506NDA-24297, Issue 1
M-26 Message Center Interface
Service Conditions (cont’d)
6. When activating this feature via the FCCS network, a maximum of 32 nodes can be assigned as the remote
node. Stations accommodated in remote node are controlled by the Message Waiting Lamp by the MC.
Interactions
1. In case a Message Center exists on each side of the FCCS network and CCIS network:
a.) Message data will be transmitted to the MC on the side of the CCIS network (in...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 507
Message Center Interface M-26
Interactions (cont’d)
2. In case a Message Center is shared by both CCIS and FCCS networks:
a.) Message data will be transmitted to the shared MC (in the figure below, assumed to be connected
to the FCCS node A), given that a call from the CCIS node (in the figure, node D) terminates to
the ATTCON/UCD station of any of the FCCS network nodes (in the figure, node A, B, C).
b.) The shared Message Center also...
