NEAX2400 IPX Feature Programming ManualPage 518NDA-24297, Issue 1
M-44 Multiple Call Forwarding - All Calls
Service Conditions (cont’d)
b.) If a call is forwarded by CALL FORWARDING - BUSY LINE [C-2] to stations that are
members of hunting groups, a hunting check is performed on the busy line closest to the called
station, or on the busy line closest to the final forward destination. In the diagram below, a
hunting check is performed on Hunt Groups 1 or 4. A hunting check is never performed on
Groups 2...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 519
Multiple Call Forwarding - All Calls M-44
Interactions (cont’d)
4. When a station in a STATION HUNTING [S-7, 8, 9] group initiates MULTIPLE CALL FORWARDING-
ALL CALLS, calls normally destined for this station will not be received. The hunt group operates as if
the station were busy.
5. A noncontrolling UCD station is allowed to activate CALL FORWARDING [C-5]. With this station call
forwarded, only calls dialed directly to this station are...

NEAX2400 IPX Feature Programming ManualPage 520NDA-24297, Issue 1
M-44 Multiple Call Forwarding - All Calls
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending
on the node.
Note
STEP 1:ASYDN- These data must be set to the NCN.
System Data 1 Index 69, b7....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 521
Manual Signaling M-47
M-47 Manual Signaling
General Description
This feature permits Dtermusers to send a one-second ring to a predetermined station. The manual intercom SIGNAL
key (SIG key) is operational at all times. An Intercom call is not required. If the signalled station is ringing from
another call, the manual intercom signal will interrupt that ringing.
Operating Procedure
Press the SIG key; send a one-second ring to the...

NEAX2400 IPX Feature Programming ManualPage 522NDA-24297, Issue 1
M-47 Manual Signaling
Programming (cont’d)
TP: Type of Dterm0/1:
RING:
0: No Ringing
1: Ringing All Lines
2: Ringing on Prime Line Only
3: Flexible Ring Assignment, enables RG parameter.
PRI: Form of Line Preference (0-3)
KYN: Key Number (1-40)
KYI: Service Index
0: Key Not Used
1: Feature Key
2: Multi-line Key
KD: Kind of Line
0: Multi-line
1: Intercom Line
ICM: Kind of Intercom
0: Automatic Intercom
1: Manual Intercom
2: Dial Intercom
If...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 523
Multi Channel Recording - DAT M-48
M-48  Multi Channel Recording - DAT
General Description
This feature allows a user to record a message to multiple Digital Announcement Trunks (DATs) in a single
operation. The message recorded in a trunk is automatically copied to other trunks one after another.
Operating Procedure
1. Recording by designating RT and TK:
a.) Lift a handset; receive dial tone.
b.) Dial the MULTI CHANNEL RECORDING...

NEAX2400 IPX Feature Programming ManualPage 524NDA-24297, Issue 1
M-48 Multi Channel Recording - DAT
Operating Procedure (cont’d)
b.) Dial the MULTI CHANNEL RECORDING (REPLAY) access code from the station; receive
special dial tone.
c.) Enter Route Number and Trunk Number; the special dial tone stops.
d.) A recorded message of the designated trunk is automatically played back.
e.) Replace the handset to finish playback of the recorded message.
Note:Even though recording of a message has been finished,...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 525
Multi Channel Recording - DAT M-48
Operating Procedure (cont’d)
Hear service set tone when # is pressed. The service set tone continues for 3 seconds.
d.) Start your recording when the service set tone is stopped.
e.) Replace the handset to finish recording.
Note:The recording length is a multiple of 2 (= 2n sec).
4. Playback by designating RT
a.) Lift a handset; receive dial tone.
b.) Dial the MULTI CHANNEL RECORDING (REPLAY) access code...

NEAX2400 IPX Feature Programming ManualPage 526NDA-24297, Issue 1
M-48 Multi Channel Recording - DAT
Operating Procedure (cont’d)
e.) Replace the handset to finish playback of the recorded message.
Note:Even though the recording of a message has been finished, playback of the trunk cannot be accepted until
dubbing of the message to the remaining trunks is complete.
5. Recording of an announcement for a UCD group
a.) Lift a handset; receive dial tone.
b.) Dial the MULTI CHANNEL RECORDING (RECORDING)...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 527
Multi Channel Recording - DAT M-48
Operating Procedure (cont’d)
b.) Dial the MULTI CHANNEL RECORDING (REPLAY) access code from the station; receive
special dial tone.
c.) Press * and enter the UCD controlling telephone number; the special dial tone is stopped.
d.) A recorded message of the designated UCD group is automatically played back.
e.) Replace the handset to finish playback of the recorded message.
Note:Even though the recording...
