NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 528NDA-24297, Issue 1
M-48 Multi Channel Recording - DAT
Operating Procedure (cont’d)
c.) Press # and enter the message number that has been assigned in the AAST command; receive
service set tone. The service set tone continues for 3 seconds.
d.) Start your recording when the service set tone is stopped.
e.) Replace the handset to finish recording.
Note:The recording length is a multiple of 2 (= 2n sec).
8. Playback of a message for ACD
a.) Lift a handset;...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 529
Multi Channel Recording - DAT M-48
Operating Procedure (cont’d)
d.) A recorded message of the designated Message Number for ACD is automatically played back.
e.) Replace the handset to finish playback of the recorded message.
Note:Even though the recording of a message has been finished, playback of the trunk cannot be accepted until
dubbing of the message to the remaining trunks is complete.
Service Conditions
1. Any entry of RT, TK, UCD...

NEAX2400 IPX Feature Programming ManualPage 530NDA-24297, Issue 1
M-48 Multi Channel Recording - DAT
Service Conditions (cont’d)
8. When the system encounters a busy trunk in an attempt to make a dubbing of the message to the remaining
trunks, the trunk is retried after a 16 second interval. Each trunk is attempted a maximum of 16 times. If
the final attempt is rejected because of busy, no further dubbing attempts will be made.
9. Only the portion in which a message has been recorded is played back.
10....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 531
Multi Channel Recording - DAT M-48
Programming (cont’d)
STEP 7:APAD- Assign the PAD control data.
KIND
T (= Assignment of PAD data for dubbing)
S (= Assignment of PAD data for playback)

NEAX2400 IPX Feature Programming ManualPage 532NDA-24297, Issue 1
M-84 MF Signaling - DID
M-84  MF Signaling - DID
General Description
In the Associated Channel Interoffice Signaling system, this feature allows use of selective codes of Multifrequency
(MF) signals.
MF - (ANSI) codes: A total of 15 codes are available by combining two out of six frequencies.
(ANSI)
Operating Procedure
No manual operation is required.
Service Conditions
1. When using MF signaling system, Least Cost Routing (LCR) or...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 533
MF Signaling - DID M-84
Service Conditions (cont’d)
4. Connection patterns to which MF signaling system can be applied are as follows:
a.) Individual call origination by station
b.) Attendant-to-Attendant connection
c.) Individual call origination by Attendant
d.) Call origination by Attendant via station/trunk
e.) MF line connection from CONSULTATION HOLD [C-17]
f.) Call transfer to MF line via Call Forwarding.
5. Connection to the...

NEAX2400 IPX Feature Programming ManualPage 534NDA-24297, Issue 1
M-84 MF Signaling - DID
Programming (cont’d)
STEP 8:AFRS- Assign the number Pattern Code (NPC) and Outgoing route selection pattern (OPR) to the
dummy route.
STEP 9:AO PR- Assign the route number, including the alternative route to the outgoing route selection
pattern (OPR). Assigns the number of skipped digits and pattern number location (PNL) to each route.
STEP 10:ARSC- Release the dummy route and station connection restriction.
Release...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 535
Message Waiting Indication - DtermM-85D
M-85D  Message Waiting Indication - Dterm
General Description
This feature allows Message Waiting (MW) information to be displayed on the middle line (24 digits) of the LCD.
Operating Procedure
No manual operation is required.
Service Conditions
1. The LCD displays the following information, when MESSAGE WAITING INDICATION - Dtermis
activated:
2. When this service is assigned to a D
termwith a...

NEAX2400 IPX Feature Programming ManualPage 536NDA-24297, Issue 1
M-101 MF ANI to SMDR
M-101  MF ANI to SMDR
General Description
This feature allows an office receiving ANI information by means of MF signal to output the information to the
expanded SMDR area.
Operating Procedure
No manual operation is required.
Service Conditions
1. Output conditions are same as current conditions of MF ANI. (i.e., charging information for incoming
calls is output only).
2. About the expanded output format, refer to SMDR...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 537
MF ANI to SMDR M-101
Programming (cont’d)
System Data 1, Index 288, Bit 5. Expanded SMDR Output for SMDR A Apparatus. 0/1 = Out/In
Service.
System Data 1, Index 290, Bit 5. Expanded SMDR Output for SMDR B Apparatus. 0/1 = Out/In
Service.
System Data 1, Index 292, Bit 5. Expanded SMDR Output for SMDR C Apparatus. 0/1 = Out/In
Service.
System Data 1, Index 294, Bit 5. Expanded SMDR Output for SMDR D Apparatus. 0/1 = Out/In
Service.
System...
