NEAX2400 IPX Feature Programming ManualPage 538NDA-24297, Issue 1 M-101 MF ANI to SMDR FCCS Programming (cont’d) When Calling Number is output to SMDR, the following expanded format is used. System Data 1, Index 288, Bit 5. Expanded SMDR Output for SMDR A Apparatus. 0/1 = Out/In Service. System Data 1, Index 290, Bit 5. Expanded SMDR Output for SMDR B Apparatus. 0/1 = Out/In Service. System Data 1, Index 292, Bit 5. Expanded SMDR Output for SMDR C Apparatus. 0/1 = Out/In Service. System Data 1, Index...
Page 582
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 539 Night Connection - Fixed N-1 N-1 Night Connection - Fixed General Description This feature routes calls normally directed to the ATTENDANT CONSOLE [A-3] to a preselected common station within the system when the Night Mode has been entered. Operating Procedure To answer NIGHT CONNECTION calls 1. The incoming calls to the ATTENDANT CONSOLE [A-3] in the night mode are automatically transferred to a preselected NIGHT CONNECTION - FIXED...
Page 583
NEAX2400 IPX Feature Programming ManualPage 540NDA-24297, Issue 1 N-1 Night Connection - Fixed Interactions (cont’d) 5. When the NIGHT CONNECTION - FLEXIBLE [N-2] feature is provided, assignments can be made by the ATTENDANT CONSOLE [A-3] or NIGHT CONNECTION - FIXED station by use of the CALL FORWARDING - ALL CALLS [C-5] feature. 6. CALL FORWARDING - BUSY LINE/DONT ANSWER [C-2, 3]: A Night user can activate the CALL FORWARDING - BUSY LINE/DONT ANSWER [C-2, 3] feature if available to the user. A call...
Page 584
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 541 Night Connection - Fixed N-1 Programming STEP 1:ASYD- System Data 1, Index 147. DIT supervisory timer for a busy station. How often will the CPU look at the Idle/Busy status of the station for rerouting the DIT call to the destination? Always leave this index as 00H. For NIGHT CONNECTION-FIXED Only. STEP 2:ACS I- Assign Route Number, Trunk Number, Connection Service Index of“4”for NIGHT CONNECTION-FIXED, and the Tenant Number and Station...
Page 585
NEAX2400 IPX Feature Programming ManualPage 542NDA-24297, Issue 1 N-2 Night Connection - Flexible N-2 Night Connection - Flexible General Description This feature provides arrangements to route calls, usually directed to the ATTENDANT CONSOLE [A-3], instead to a preselected station on a flexible, assignable basis within the system, when the Night Mode has been entered. Operating Procedure 1. Answering the operation is the same as that for NIGHT CONNECTION - FIXED [N-1]. 2. Each evening, before placing...
Page 586
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 543 Non-delay Operation N-3 N-3 Non-delay Operation General Description This feature allows the ATTENDANT CONSOLE [A-3] to place any calling party on hold, dialing the call, and connecting the calling and called parties. Operating Procedure 1. The Attendant answers an operator call by pressing the ANSWER or ATND key. 2. Press the START key. 3. Dial the exchange network access code. 4. Dial the desired telephone number. 5. Press the RELEASE...
Page 587
NEAX2400 IPX Feature Programming ManualPage 544NDA-24297, Issue 1 N-3 Non-delay Operation FCCS Programming This data setting describes only the additional or replacement commands used to activate FCCS services. When used as an FCCS feature, these commands replace the non-network commands (for example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending on the node. STEP 1:ARSCN- Construct a Route Restriction Class (RSC) that will allow outgoing access to various...
Page 588
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 545 Non-exclusive Hold - DtermN-7D N-7D Non-exclusive Hold - Dterm General Description This feature allows a Dtermuser to place a call on Hold, from which it can be retrieved by any Dtermstation that displays the held line. Operating Procedure 1. While a call is in progress, press the HOLD key. 2. To retrieve a held call; press the held line. Service Conditions 1. Any Dtermstation displaying the held line can seize the held call. 2....
Page 589
NEAX2400 IPX Feature Programming ManualPage 546NDA-24297, Issue 1 N-7D Non-exclusive Hold - Dterm Service Conditions (cont’d) d.) when a station has a path to a station that has a station held by MUSIC ON HOLD [M-7] for CONSULTATION HOLD - ALL CALLS [C-17] or CONSULTATION HOLD - ALL CALLS D term[C-17D]: e.) whenastationhasapathtotwotrunksatonetimeforTHREE-WAYCALLING[T-2]or THREE-WAY CALLING - D term[T-2D]: f.) whenastationhasapathtoatrunkandastationatonetimeforTHREE-WAYCALLING[T-2] or THREE-WAY CALLING -...
Page 590
NEAX2400 IPX Feature Programming Manual NDA-24297, Issue 1Page 547 Non-square Line Assignment - DtermN-8D N-8D Non-square Line Assignment - Dterm General Description This service feature allows the line function buttons on the Dtermset to be freely assigned as line keys or as service feature keys. These assignments are done on a per-station basis. Operating Procedure Key designations are assigned via the Maintenance Administration Terminal (MAT) [M-18]. Service Conditions Programming one feature to more...
