NEAX2400 IPX Feature Programming ManualPage 548NDA-24297, Issue 1
N-17 Night Connection Outside - System
N-17  Night Connection Outside - System
General Description
This is a night transfer service on a system basis, enabling a ring-down or LDN call to be transferred to a preselected
station outside the NEAX2400 IPX when night mode has been set.
Operating Procedure
1. The Attendant sets night mode. (Night Key, PB, Handset Extraction, MB).
2. A ring-down or LDN call terminates from a trunk.
3. The call is...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 549
Name Display - System N-28
N-28  Name Display - System
General Description
This feature allows a Dtermwith LCD display to indicate the user information corresponding to the calling telephone
number while engaged in STATION-TO-STATION CALLING [S-11].
Operating Procedure
1. When originating a station-to-station call:
Note:The user information on the LCD flashes until the call is answered.
2. When a station call has been transferred to...

NEAX2400 IPX Feature Programming ManualPage 550NDA-24297, Issue 1
N-28 Name Display - System
Operating Procedure (cont’d)
Note:The user information on the LCD flashes until the call is answered.
3. When both the calling/called station are released from a station-to-station call, the LCD of the calling/
called station displays:
Service Conditions
1. This service is available when either of the calling/called station is a Dterm, with an LCD display.
2. By this service, ASCII character data can be...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 551
On-line Maintenance O-1
O-1 On-line Maintenance
General Description
This service feature permits maintenance routines to be performed on the NEAX2400 IPX without affecting normal
system operation.
Operating Procedure
Refer to the NEAX2400 IPX Office Data Specification.
Service Conditions
1. The following maintenance functions may be performed while the system is ON-LINE:
a.) Generic Program and Operating Memory testing
b.) Fault Contents...

NEAX2400 IPX Feature Programming ManualPage 552NDA-24297, Issue 1
O-2 Outgoing Trunk Queuing
O-2  Outgoing Trunk Queuing
General Description
This feature allows a user to dial a specified access code and enter a first-in, first-out queue, when encountering a
trunk busy signal. As soon as an OUTGOING TRUNK becomes available, stations in the queue will be called back
on a first-come, first-served basis.
Operating Procedure
When LEAST COST ROUTING - 3/6-DIGIT [L-5] is not provided
1. Dial the trunk access...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 553
Outgoing Trunk Queuing O-2
Service Conditions (cont’d)
13. If a user goes on-hook within 6-8 seconds after encountering all trunks busy, OUTGOING TRUNK
QUEUING can be set automatically to the station.
14. The station is set for OGQ for a minimum of 30 seconds to one hour, maximum. This time is adjustable
through the system data. After this time, OGQ will be cancelled automatically.
15. ACCOUNT CODE [A-18] and FORCED ACCOUNT CODE [F-7]...

NEAX2400 IPX Feature Programming ManualPage 554NDA-24297, Issue 1
O-2 Outgoing Trunk Queuing
Programming
STEP 1:ASYD- System Data 1, Index 68, Bit 3. Enables automatic cancel timer, as set in System Data 1,
Index 159. 0/1: -/Enable.
System Data 1, Index 159. OGQ release timer. Standard data of 00H for 30 minutes may be assigned.
(RAM data of 3C [Hex] provides for 30 minutes).
System Data 2, Index 4, Bit 0. Should the access code for CALL BACK and OGQ be the same? 0/1:
No/Yes. Usually assign data“1”....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 555
Outgoing Trunk Queuing O-2
FCCS Programming (cont’d)
CI: N = Normal
SID: 20 = OG Queuing-Cancel
STEP 3:ANPDN- These data must be assigned to the NCN.
TN: Tenant
1st DC: 1st Digit
CI: Normal (N), Hooking (H) and Busy (B)
NND: Number of Necessary Digits
BLF: Busy Lamp Field
STEP 4:ARTDN- These data must be assigned to the NCN.
LGRT: Logical Route Number
Assign CDN 9:TQ, Trunk Queuing Service = 1
Note 1:When using ASYDL or ASYDN to program...

NEAX2400 IPX Feature Programming ManualPage 556NDA-24297, Issue 1
O-2D Outgoing Trunk Queuing - Dterm
O-2D  Outgoing Trunk Queuing - Dterm
General Description
This service allows a Dtermuser, upon encountering a trunk busy signal, to enter a first-in, first-out queue.
Operating Procedure
Without LEAST COST ROUTING - 3/6-DIGIT [L-5]
1. Dial the trunk access code; receive busy tone.
2. Press the CALL BACK key, receive service set tone. The LCD displays:
3. Replace the handset.
4. When the trunk becomes...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 557
Outgoing Trunk Queuing - DtermO-2D
Service Conditions (cont’d)
4. Individual stations may only initiate one OUTGOING TRUNK QUEUE - Dtermat a time. Subsequent
attempts will produce a reorder tone.
5. Stations may be restricted from use of this feature via CLASS OF SERVICE - INDIVIDUAL [C-15].
6. The station is put in queuing condition for a maximum of 30 seconds to one hour (adjustable through
system data). After this timing, OG queuing...
