NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 568NDA-24297, Issue 1
O-13 Overflow - UCD
Programming (cont’d)
STEP 2:ANPD- Reserve a number level for feature access. Assign for Normal (N), Hooking (H), and Busy
(B) (if applicable to any feature in this level). Assign NND in accordance with a predetermined
numbering plan.
STEP 3:ASPA- Assign an access code to UNIFORM CALL DISTRIBUTION [U-1], SRV = SSCA (Service
Code Appendix), SIDA = 50 Busy Set, SRV = SSCA (Service Code Appendix), SIDA = 51 Busy
Cancel....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 569
Outgoing Trunk Queuing - Attendant O-16
O-16  Outgoing Trunk Queuing - Attendant
General Description
This feature allows an ATTENDANT CONSOLE [A-3], upon encountering a trunk busy condition, to remain Off-
Hook and automatically enter a first-in, first-out queue. As soon as an outgoing trunk becomes available, the switch
connects the next call to that trunk.
Operating Procedure
1. Dial the access code and the desired number.
2. When no...

NEAX2400 IPX Feature Programming ManualPage 570NDA-24297, Issue 1
O-16 Outgoing Trunk Queuing - Attendant
Service Conditions (cont’d)
11. If data has not been cleared after the NCN is recovered, the call in the queue will be called back when a
trunk becomes idle status. If data has been cleared, the call is cancelled automatically.
Programming
STEP 1:ASYD- System Data 2, Index 4, Bit 2: Off-Hook OGQ for attendant 0/1: Out/In Service.
STEP 2:ASFC- Assign 1 (= Allowed) in SFI 21 (= Off-HookOGQ) for SFC0....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 571
Outgoing Trunk Busy Announcements O-21
O-21  Outgoing Trunk Busy Announcements
General Description
This feature permits a station-originated call, upon encountering a trunk busy signal, to be automatically routed to
a recorded announcement informing the caller that all outgoing trunks are busy.
Operating Procedure
No manual operation is required after this feature has been programmed in system data.
Service Conditions
1. This service...

NEAX2400 IPX Feature Programming ManualPage 572NDA-24297, Issue 1
O-37D Off-Hook Line Number Display - Dterm
O-37D  Off-Hook Line Number Display - Dterm
General Description
This feature permits the DtermLCD to display the calling telephone number/trunk number when the Dtermuser
originates a call by pressing a line key or using TRUNK LINE APPEARANCE [T-23] service.
Operating Procedure
1. When a call is originated by pressing the line key:
In the on-hook status; the LCD displays:
In the idle status and no...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 573
Off-Hook Line Number Display - DtermO-37D
Service Conditions
1. This service is provided when off-hook. In the preselect status, this is not provided.
2. This service is not provided when a call is originated by using HOT LINE [H-1] service.
3. In case a call is originated by using TRUNK LINE APPEARANCE service, the connected trunk number
is displayed.
4. If the trunk number is not assigned, the LCD doesn’tdisplay.
5. The maximum digits...

NEAX2400 IPX Feature Programming ManualPage 574NDA-24297, Issue 1
P-1 Paging Access
P-1 Paging Access
General Description
This feature provides both ATTENDANT CONSOLE [A-3] and users dial access to PAGING equipment.
Operating Procedure
1. Go off-hook; receive dial tone.
2. Dial the Paging access code; receive ringback tone for several seconds.
3. Connection to Paging equipment is established.
Service Conditions
1. Amplifiers and speakers must be customer provided.
2. One trunk circuit is required for...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 575
Paging Access P-1
Interactions (cont’d)
5. For simple PAGING ACCESS [P-1], assignments in ASFC are not required. Refer directly to the other
Paging features, such as PAGING TRANSFER[P-10].
6. The Attendant can dial the PRIORITY PAGING [P-30] access code and release a station.
7. When disconnecting from a Paging trunk, the trunk becomes idle immediately.
8. Paging is possible from a CONSULTATION HOLD [C-17]. Station A places Party B on...

NEAX2400 IPX Feature Programming ManualPage 576NDA-24297, Issue 1
P-2 Passing Dial Tone
P-2  Passing Dial Tone
General Description
This feature allows the Attendant to PASS DIAL TONE to a restricted user, enabling that user to place a call that
would normally be restricted.
Operating Procedure
1. Restricted user dials Attendant.
2. Attendant presses ANSWER or ATND key; tenant number, trunk route restriction class and telephone
number are displayed.
3. Obtain call details.
4. Dial central office access...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 577
Passing Dial Tone P-2
Interactions (cont’d)
2. The associated programming that should be examined is ATTENDANT CONSOLE [A-3], TOLL
DENIAL/TOLL DIVERSION [T-7], TOLL RESTRICTION-3/6 DIGIT [T-8], LEAST-COST
ROUTING-3/6 DIGIT [L-5], CLASS OF SERVICE-INDIVIDUAL [C-17], and the various trunk access
features.
3. NIGHT CONNECTION FIXED/FLEXIBLE [N-1, 2]: The NIGHT CONNECTION FIXED/FLEXIBLE
stations cannot pass dial tone to another station.
4....
