NEAX2400 IPX Feature Programming ManualPage 558NDA-24297, Issue 1
O-2D Outgoing Trunk Queuing - Dterm
Interactions
1. Dial pad operation for Dtermsets may be exercised. A FLASH BUTTON [F-3D] must be programmed to
a programmable line/feature key.
2. OGQ-AUTOMATIC may operate with either same or separate access codes. If the Automatic option is
chosen, service set tone will be sent when encountering an all trunks busy situation. No dial pad operation
will be required.
3. When testing OGQ, at least one...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 559
Outgoing Trunk Queuing - DtermO-2D
FCCS Programming (cont’d)
System Data 1, Index 41: Designate the Trunk Queuing Override Timer
Index 68, b3: Enables automatic cancel timer
0/1: -/Automatic cancel timer is Available
Index 159: Designate Automatic Cancel Timer
STEP 2:ASPAN- These data must be assigned to the NCN.
TN: Tenant Number
ACC: Access number
CI: B = Busy (for Entry), N = Normal (for Cancel)
SRV: SSC
SID: 19 = OG Queuing-Entry
SID:...

NEAX2400 IPX Feature Programming ManualPage 560NDA-24297, Issue 1
O-6 Off-Hook Alarm
O-6 Off-Hook Alarm
General Description
This feature allows a user to call the Attendant or a predetermined station by simply staying OFF-HOOK. The
calling number is automatically displayed at the ATTENDANT CONSOLE [A-3] or a Dtermseries with a display.
Operating Procedure
1. Lift the handset and stay off-hook.
2. After a predetermined time elapses (2 to 30 sec.), the call will terminate at the ATTENDANT CONSOLE
[A-3] or...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 561
Off-Hook Alarm O-6
Service Conditions (cont’d)
13. If a station belongs to the node that has an Attendant Console, the station is connected with the Attendant
Console. If a station belongs to the node that does not have an Attendant Console, the station is connected
with the specified Attendant Console in the remote node according to the system data assigned. See the
figure below.
Interactions
1. A total of seven OFF-HOOK ALARM Groups per...

NEAX2400 IPX Feature Programming ManualPage 562NDA-24297, Issue 1
O-6 Off-Hook Alarm
Programming (cont’d)
S: Station
A: Attendant Console
SSTN: Special Station Number
STEP 3:ASGD- This command defines what stations belong to the Special Incoming Group. Assign the
following:
TN: Tenant Number
STN: Station Number
F: Function Number (0-7)
0: Off-Hook Alarm
GN: Group Number (1-7)
STEP 4:ASFC- Assign a Service Feature Class that allows SFI 30 to stations that will have OFF-HOOK
ALARM.
STEP 5:AAKP- Assign the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 563
Off-Hook Queuing O-7
O-7 Off-Hook Queuing
General Description
This service allows a user, upon encountering a trunk-busy condition, to remain off-hook and automatically enter a
first-in, first-out queue. As soon as an outgoing trunk becomes available, the switch connects the next call to this
trunk.
Operating Procedure
1. Lift the handset; receive a dial tone.
2. Dial the Outgoing Call access code and the desired number (LCR access).
3....

NEAX2400 IPX Feature Programming ManualPage 564NDA-24297, Issue 1
O-7 Off-Hook Queuing
Service Conditions (cont’d)
10. The maximum of number of the OGQ stations is 1,024 within the FCCS network (NCN can manage a
maximum of 1,024 calls).
11. OGQ data is transmitted to and stored in the Network Control Node (NCN). Therefore, all the OGQ data
will be cleared by the system initialization of the NCN.
12. When the access to the NCN is impossible (system down, cable disconnection or trouble has occurred),
the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 565
Off-Hook Queuing O-7
FCCS Programming (cont’d)
CI: B = Busy (for Entry), N = Normal (for Cancel)
SRV: SSC
SID: 19 - OG Queuing - Entry
CI: N = Normal
SID: 20 = OG Queuing - Cancel
Note 1:When using ASYDL or ASYDN to program an FCCS feature, the basic programming of ASYD is required
in addition to ASYDL or ASYDN.
Note 2:The current data should also be set in addition the above-mentioned commands.
The command to be set to the node...

NEAX2400 IPX Feature Programming ManualPage 566NDA-24297, Issue 1
O-13 Overflow - UCD
O-13  Overflow - UCD
General Description
1. When a call has terminated to UCD [U-1] Group A, and the incoming call has encountered all stations
busy in Group A, the call is transferred to UCD [U-1] Group B, if Group B is registered as the
OVERFLOW-UCD destination.
2. If all stations are busy in Group B, then the call is placed in queue for the originally called UCD [U-1]
group (Group A).
Operating Procedure
No manual...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 567
Overflow - UCD O-13
Service Conditions (cont’d)
5. A call can be overflowed 4 times at the maximum by using this feature. If overflowing destinations are all
busy, the call is queued into original group (depending on system data). For details, refer to the figure
below.
Note:The call cannot be overflow more than 5 times.
6. UCD OVERFLOW data can be programmed in Local Data Memory (LDM).
7. The overflowing destination which can be assigned...
