NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 588NDA-24297, Issue 1
P-9 Priority Call
Interactions (cont’d)
3. If the destination of a Priority Call is the Attendant Console, the Priority Call does not transfer to the
ATTENDANT NIGHT TRANSFER [A-19] station when the system goes into Night mode.
4. A PRIORITY CALL will not be forwarded to outside.
Programming
STEP 1:ASYD- System Data 1, Index 168, Bit 6. Where will Priority Call terminate? 0/1: Attendant Console/
Station. If Attendant Console (0), go to...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 589
Priority Call P-9
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending
on the node.
 Note
STEP 1:ASPAL- This data must be set to the node calling the attendant.
Assign the FPC of the node...

NEAX2400 IPX Feature Programming ManualPage 590NDA-24297, Issue 1
P-10 Paging Transfer
P-10 Paging Transfer
General Description
This feature allows a user to transfer a paged call to a party that has been placed on hold.
Operating Procedure
While a user is engaged in a call
1. Switch hook flash or press TRANSFER key (on Dtermphone); receive special dial tone.
2. Dial the Paging Access Code; receive continuous ringback tone for approximately one second.
3. Page the desired party.
There are three paging...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 591
Paging Transfer P-10
Service Conditions (cont’d)
7. When using this feature via the FCCS network, PAGING ACCESS [P-1], PAGING TRANSFER [P-10]
and RADIO PAGING [R-16] are provided to the paging station and the paged station in FCCS nodes.
8. When using this feature via the FCCS network, when PAGING ACCESS [P-1]/PAGING TRANSFER [P-
10]/RADIO PAGING [R-16] service is set to a station in the remote node or the PAGING ACCESS [P-
1]/PAGING...

NEAX2400 IPX Feature Programming ManualPage 592NDA-24297, Issue 1
P-10 Paging Transfer
Programming (cont’d)
System Data 1, Index 74, Bits 0 & 3. Assign the cancel timer for unanswered page. Assign data 00H
for 30 seconds.
(0-F + 1) x 30 = Cancel Timer.
System Data 2, Index 1, Bits 0 & 1. Consultation Hold allowed or denied. 00: Denied; 01: Originating
and Terminating Calls allowed; Tandem Call Denied; 11: All calls allowed.
STEP 2:ARTD- Assign the paging route as shown below:
RT: 1
1-OSGS :2 2-ONSG :3...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 593
Paging Transfer P-10
FCCS Programming (cont’d)
Note 1:When using ASYDL or ASYDN to program an FCCS feature, the basic programming of ASYD is required
in addition to ASYDL or ASYDN.
Note 2:The current command data shown is set to all nodes using the service: ASTD, ARTD, ATRK, ASFC

NEAX2400 IPX Feature Programming ManualPage 594NDA-24297, Issue 1
P-11 Periodic Time Indication Tone
P-11  Periodic Time Indication Tone
General Description
This feature provides a tone every 180 seconds, if required, to the user who has made an outgoing call.
Operating Procedure
No manual operation is required.
Service Conditions
1. This feature is programmed on a per-trunk route basis using the MAINTENANCE ADMINISTRATION
TERMINAL (MAT) [M-18].
2. The PERIODIC TIME INDICATION TONE is 80 ms in duration...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 595
Periodic Time Indication Tone P-11
Programming
STEP 1:ASYD- System Data 1, Index 137. This timer sets the interval when the first tone will be sent to the
station. Assign 00H for 3 minutes.
System Data 1, Index 138. This timer sets the period between the first and second tones and all other
subsequent tones. Assign 00H for 3 minutes.
STEP 2:ARTD- Assign CDN 29:TELP. Flag the routes with which the tone will operate.
STEP 3:ASFC- Assign to...

NEAX2400 IPX Feature Programming ManualPage 596NDA-24297, Issue 1
P-13D Prime Line Pickup - Dterm
P-13D  Prime Line Pickup - Dterm
General Description
This feature allows a Dtermuser to originate or answer a call from the line designated as the Primary Line by going
off-hook. It is unnecessary to press the associated line key.
Operating Procedure
Lift the handset or press the SPEAKER key; receive dial tone.
Service Conditions
1. One Prime Line per station is allowed.
2. Unless otherwise programmed, the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 597
Prime Line Pickup - DtermP-13D
Programming (cont’d)
2: Multi-line Key
KD: 0
TN: Tenant
STN: Station Number
RG: Ringing Assignment per multi-line appearance
0: No Ringing.
1: Ringing in Day Mode Only.
2: Ringing in Night Mode Only.
3: Ringing in Day and Night Mode.
