NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 598NDA-24297, Issue 1
P-14D Privacy - Dterm
P-14D Privacy - Dterm
General Description
This feature allows a Dtermto establish privacy so that no station can interrupt a call via EXECUTIVE RIGHT-OF-
WAY [E-1].
Operating Procedure
1. Go off-hook; receive dial tone. Press the DO NOT DISTURB (DND) key. The associated LED will flash.
The LCD displays:
2. Dial the desired number.
3. When the call is completed, Privacy is cancelled by going on-hook.
Service...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 599
Privacy - DtermP-14D
Programming (cont’d)
KYN: Key Number (1-40)
KYI: Service Index
0: Key Not Used
1: Feature Key
2: Multi-line Key
KD: Not assigned for Feature Key
FKY: Feature Key Number
FKY = 50, DO NOT DISTURB
STEP 2:ADSL- Assign DND key; SN=1, 2, 3, 4, 5, 6, 7, 15 and FKY=50 (Do Not Disturb).
This command is required for assigning a function to each soft key.

NEAX2400 IPX Feature Programming ManualPage 600NDA-24297, Issue 1
P-15D Privacy On All Lines - Dterm
P-15D  Privacy On All Lines - Dterm
General Description
This feature restricts Dtermusers from pressing a busy line button and entering a conversation, which can occur with
1A2 key telephones without exclusion circuits.
Operating Procedure
No manual operation is required.
Service Conditions
1. A Dtermuser cannot seize the Prime Line if it is busy.
2. LINE PRESELECTION [L-9D] is denied if the selected line...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 601
Privacy Release P-18
P-18 Privacy Release
General Description
This feature allows multiple stations (maximum 6) accommodated in the same multi-line group to override a Dterm
already engaged in communication. Also, by key operation of the Dtermalready engaged in communication
(maximum of 8-party communication), overriding from other stations in the same multi-line group can be restricted.
Operating Procedure
To establish a 4-party call...

NEAX2400 IPX Feature Programming ManualPage 602NDA-24297, Issue 1
P-18 Privacy Release
Operating Procedure (cont’d)
3. Station A lifts handset or presses SPEAKER key. The LCD displays:
4. Station C presses PRIVACY key again.
5. Station A receives ringback tone, and the LCD displays:
6. A 4-party call is established. The line appearance will flash, indicating I-USE [I-8], and the LED of
PRIVACY key will be turned off. The LCDs of the associated D
termsdisplay:
By following the operations described above,...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 603
Privacy Release P-18
Service Conditions (cont’d)
10. When a station tries to bridge into a call and presses the line appearance, and when PRIVACY RELEASE
is not available because of the lack of an 8-party conference trunk, the LCD displays as follows, indicating
that PRIVACY RELEASE is not available:
11. PRIVACY RELEASE is not available when another station is in the process of entering a multiple-party
call (when receiving ringback...

NEAX2400 IPX Feature Programming ManualPage 604NDA-24297, Issue 1
P-18 Privacy Release
Service Conditions (cont’d)
f.) While engaged in a multiple-party call, the user presses the line appearance of a busy station.
g.) While engaged in calling a station by INTERCOM [I-9] call or Intercom Bridge call, the station
presses the line appearance of busy station.
h.) After placing a call on CONSULTATION HOLD [H-17], the station originates a call to a station
or trunk and then presses the line appearance of a...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 605
Privacy Release P-18
Programming
STEP 1:ASYD- System Data 1, Index 17, Bit 2. Is PRIVACY RELEASE service to be enabled? 0/1: No/Yes.
Assign data 1.
System Data 1, Index 17, Bit 3. Is an Interrupt tone for PRIVACY RELEASE to be enabled? 0/1: No/
Yes.
System Data 1, Index 17, Bit 6. Is Line Privacy Expansion service to be enabled? 0/1: No/Yes. Assign
data 1.
System Data 1, Index 17, Bit 7, Bridge Call 0/1: Privacy/Non-Privacy Operation....

NEAX2400 IPX Feature Programming ManualPage 606NDA-24297, Issue 1
P-30 Priority Paging
P-30 Priority Paging
General Description
This feature allows a station or an ATTENDANT CONSOLE [A-3] to make a PRIORITY PAGING [P-30] access
when a paging call cannot normally be originated because another paging call is in progress or is waiting for an
answer.
Operating Procedure
Paging Access from a station
1. The Paging station goes off-hook; hears dial tone.
2. The station dials the PRIORITY PAGING [P-30] access...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 607
Priority Paging P-30
Service Conditions (cont’d)
12. Forced release of a Paging Trunk is processed so that the station connected with that specific Paging Trunk
is regarded as having released. Therefore, after the forced release of the paging trunk, the state of the
stationisasfollows:
a.) if there is a call on hold: Dial Tone Connection
b.) if there is no call on hold: Recall (Calling Only)
(Answering - Non-Delay)
Dial Tone Connection...
