NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 608NDA-24297, Issue 1
P-57 Pad Lock
P-57 Pad Lock
General Description
This feature temporarily restricts telephones from making unauthorized calls by dialing a special access code when
users are away from their seats.
Operating Procedure
To set PAD LOCK from the station
1. Lift the handset and receive dial tone.
2. Dial PAD LOCK access code and receive special dial tone.
3. Dial Authorization Code and receive service set tone.
4. Restore the handset.
To cancel...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 609
Pad Lock P-57
Programming (cont’d)
STEP 5:AATC- Assign the TN, Digit Code (DC), the Authorization Code Restriction (ACR) as data“1”,and
Service Feature Class (SFC) and Route Restriction Class (RSC).

NEAX2400 IPX Feature Programming ManualPage 610NDA-24297, Issue 1
P-59 Personal Ringer
P-59 Personal Ringer
General Description
This feature provides another ringer pattern for the call terminating to the personal number and allows the user to
distinguish the called number upon hearing ringing.
Ringing patterns are as follows:
Ringing Pattern A: used for an incoming call from Central Office to the individual number.
Ringer pattern B: used for an incoming call from a station or TIE Line trunk to the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 611
Personal Ringer P-59
Programming
STEP 1:ASYD- System Data 1, Index 417, Bit 0: Recall Ringer Pattern for CALL BACK [C-1], CALL
WAITING - ORIGINATING [C-31], and OUTGOING TRUNK QUEUING [O-2]. 0/1 = Ringer
Pattern 5/Ringer Pattern 1.
System Data 3, Index 0. Timer Value for Ringer used for Ringer Pattern 0.
System Data 3, Index 1. Timer Value for Ringer used for Ringer Pattern 1.
System Data 3, Index 3.
Bit 0: 2 Burst (0.4 sec.-ON, 0.2...

NEAX2400 IPX Feature Programming ManualPage 612NDA-24297, Issue 1
R-2 Remote Access to System
R-2  Remote Access to System
General Description
This feature allows a user outside the NEAX2400 IPX to access the system via an exchange network connection
without Attendant or station assistance. The outside user may originate calls over any or all of the PBX facilities,
such as WATS, FX, TIE Line or CCSA.
When a wrong code is received from a station/trunk, detailed information on the unauthorized user is...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 613
Remote Access to System R-2
Interactions
1. The Authorization Code used in conjunction with REMOTE ACCESS TO SYSTEM will not be recorded
in SMDR. System Data 2, Index 3, bit 5 is the only difference between Forced Account Code and
Authorization code. This Bit determines where the dialed code will appear in SMDR. When assigned as
Authorization code, those digits will not appear in SMDR.
2. The additional step of the ARAC command, for DID...

NEAX2400 IPX Feature Programming ManualPage 614NDA-24297, Issue 1
R-2 Remote Access to System
Programming (cont’d)
STEP 6:MBTK- Assign the Make Idle status to the REMOTE ACCESS TO SYSTEM trunks.
STEP 7:ACS I- Assign Route Number, Trunk Number, and Connection Service Index (CSI) = 5, REMOTE
ACCESS TO SYSTEM, Incoming DDD Ring down trunks are automatically connected as a Remote
Access trunk. They do not use ARAC access codes.
STEP 8:ARAC- This command is used when a TIE Line or DID line will serve as a...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 615
Reserve Power R-3
R-3 Reserve Power
General Description
This feature provides a system with a backup power supply, functioning from a battery source, in the event of a
commercial power failure.
Operating Procedure
Power is automatically supplied to the NEAX2400 IPX in the event of a commercial power failure.
Service Conditions
1. Batteries should be installed separate from the NEAX2400 IPX.
2. Batteries and chargers are not NEC supplied....

NEAX2400 IPX Feature Programming ManualPage 616NDA-24297, Issue 1
R-4 Restriction from Outgoing Calls
R-4  Restriction from Outgoing Calls
General Description
This feature automatically denies preselected station lines within the NEAX2400 IPX system the ability to place
outgoing calls and/or certain miscellaneous trunk calls without Attendant assistance.
Operating Procedure
Operation is fully automatic that the restricted stations will receive reorder tone upon attempting to place a restricted
call....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 617
Restriction from Outgoing Calls R-4
Interactions (cont’d)
3. CONSULTATION HOLD [C-17]: Station A may consult with station B when Route 1 is on Soft Hold.
4. THREE-WAY CALLING [T-2]: Station A cannot include restricted Station B in a Tree-Way Calling
connection with Route 1.
5. DAY/NIGHT CLASS OF SERVICE [D-15]: Restricted Station B may be allowed access to Route 1 when
the system is placed in the NIGHT mode. See DAY/NIGHT CLASS OF...
