NEAX2400 IPX Feature Programming ManualPage 618NDA-24297, Issue 1
R-4 Restriction from Outgoing Calls
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending
on the node.
Note
STEP 1:ARSCN- Sixteen different Route Restriction Classes may be constructed to either...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 619
Rotary Dial Calling R-5
R-5  Rotary Dial Calling
General Description
This feature permits users to originate calls over rotary or push-button lines using Rotary Dial telephones.
Operating Procedure
Users dial rotary telephones in the normal fashion.
Service Conditions
1. Rotary dial telephones installed should be industry standard 10pps instruments.
2. Pushbutton instruments may be used in conjunction with ROTARY DIAL CALLING.
3. It is...

NEAX2400 IPX Feature Programming ManualPage 620NDA-24297, Issue 1
R-5 Rotary Dial Calling
Programming (cont’d)
902 - ORT 913 - TCFT for ATT
903 - IRT 915 - Night ATT
905 - Sender 916 - MFCR
909 - DCFT 917 - MFCS
919 to 926 - Modem
TK: Trunk Number
TN: Tenant number
RSC: Route Restriction Class
SFC: Service Feature Class
STEP 4:ARTD- Routes must be assigned as either PB, DP, or DP/PB. Flag CDN 2:ONSG as data“1”,DP,or
data“3”,DP/PB.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 621
Route Advance R-6
R-6 Route Advance
General Description
This feature automatically routes outgoing calls over alternate facilities when the first-choice trunk group is busy.
User selects the first-choice route by dialing the corresponding access code, and the equipment then advances
through alternate trunk groups only if the first choice is busy.
Operating Procedure
No manual operation is required.
Service Conditions
1. No indication is...

NEAX2400 IPX Feature Programming ManualPage 622NDA-24297, Issue 1
R-6 Route Advance
Interactions (cont’d)
2. TOLL RESTRICTION - 3/6 DIGIT [T-6] may be used in conjunction with ROUTE ADVANCE. Only
routes of the same type may be used in ROUTE ADVANCE. Two differently labeled C.O. trunks, such
as, DDD and WATS may be in the same group.
3. There is no digit translation available for this feature. The dialed digits must be usable by whatever route
is available.
4. This feature is available for a station...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 623
Remote Maintenance R-7
R-7 Remote Maintenance
General Description
This feature allows office data changes or reassignments to be performed without a site visit by service personnel,
and can be used to detect fault tendencies before they affect service. One REMOTE MAINTENANCE center can
service an unlimited amount of systems, thus reducing the amount of personnel needed to maintain each site.
Operating Procedure
The operation of this...

NEAX2400 IPX Feature Programming ManualPage 624NDA-24297, Issue 1
R-7 Remote Maintenance
Programming
STEP 1:Initialization of the system will automatically provide for Maintenance Administration Terminal
capabilities in System Data 1, Index 116 for Port 0.
STEP 2:AIOC- Assign the function and attribute data of each I/O port to be used.
STEP 3:Assign Terminal Configuration data (Serial Settings/TCPIP Settings) in the PBX Administration
menu.
STEP 4:AUIDN- This command must be assigned to allow password...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 625
Radio Paging R-16
R-16 Radio Paging
General Description
This feature allows users dialing access to customer-owned RADIO PAGING equipment and to selectively tone or
voice/tone alert individuals carrying pocket RADIO PAGING receivers. The paged party may be connected to the
paging party by going to the nearest telephone and dialing a unique answer-back code.
Operating Procedure
To page
1. Paging user dials the RADIO PAGING access code;...

NEAX2400 IPX Feature Programming ManualPage 626NDA-24297, Issue 1
R-16 Radio Paging
Service Conditions (cont’d)
8. If the paging user has failed to hang up within a predetermined, programmable time interval (after
activation), the paging connection is forcibly released.
9. If the paged party does not answer within 30 seconds, the NEAX2400 IPX will automatically page that
party again. If the paged party does not answer the second page within 30 seconds, the paging request will
be cancelled from memory....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 627
Radio Paging R-16
Programming (cont’d)
(N+1)x30=TimeOut
N = a hexadecimal value set in Bits 4-7.
If the paged party doesn’t respond by the same period of time after the second page, the page is
cancelled.
System Data 1, Index 244, bit 0. Answer by Radio Paging answer code. 0/1: Out/In Service. Note that
this bit is valid when System Data 1, Index 73, bit 4 is 1 (Station Number/Individual ATT Number is
automatically sent).
STEP 2:ARTD-...
