NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 638NDA-24297, Issue 1
R-54 Remote Call Forwarding Control
Service Conditions (cont’d)
5. Each target station must be a PB (DTMF) telephone.
6. This feature is restricted when:
A wrong ID code is dialed from the target station.
The forwarding features from the designated station are restricted by Service Feature Class.
7. Normally, a maximum of 12 digits can be dialed as a Call Forwarding destination number. However, the
maximum number of digits assigned by...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 639
Remote Call Forwarding Control R-54
Programming (cont’d)
STEP 5:ARAC- Assign the Remote Call Forwarding Control access code.
ICTN: Tenant Number of Incoming Trunk
ACC: Access Code (Max. 5 digits)
R/M: M (Remote Call Forwarding Control)
STEP 6:ASFC- Assign a Service Feature Class that allows the following SFIs to the stations that will activate
Remote Call Forwarding Control.
SFI: 7 (Call Forwarding - All Calls/Split Call Forwarding - All...

NEAX2400 IPX Feature Programming ManualPage 640NDA-24297, Issue 1
S-1 Single-Digit Station Calling
S-1 Single-Digit Station Calling
General Description
This feature allows the assignment of single digits for station numbers.
Operating Procedure
1. Lift the handset; receive dial tone.
2. Dial the Single-digit (preprogrammed) telephone number.
3. The desired service station will be rung.
Service Conditions
1. The single-digit number must be different from the first digit of trunk access codes, service...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 641
Special Dial Tone S-2
S-2  Special Dial Tone
General Description
This feature provides a distinctive dial tone to a user after the switch hook has been pressed, enabling the user to
activate a specific service feature.
Operating Procedure
1. While connected with the first party, user presses the switch hook; receives SPECIAL DIAL TONE.
2. User may activate a service feature, such as:
CALL HOLD [C-6]
CALL TRANSFER-ALL CALLS [C-11]
Service...

NEAX2400 IPX Feature Programming ManualPage 642NDA-24297, Issue 1
S-3 Speed Calling - System
S-3  Speed Calling - System
General Description
This feature allows a user or ATTENDANT CONSOLE [A-3] to call frequently dialed numbers using fewer digits
(abbreviated call codes) than would normally be required.
Operating Procedure
1. Lift handset; receive dial tone,
2. Dial SPEED CALLING - SYSTEM access code (maximum three digits), or press D
termSpeed Calling
key.
3. Dial abbreviated call code (maximum four...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 643
Speed Calling - System S-3
Programming
STEP 1:ASYD- System Data 2, Index 1, bit 7. Does TOLL RESTRICTION [T-7] apply to SPEED
CALLING-SYSTEM? 0/1: No/Yes.
STEP 2:ANPD- Reserve a number level for feature access. Assign Connection Indexes of Normal (N),
Hooking (H), and Busy (B). Assign NND in accordance with a predetermined numbering plan.
STEP 3:ASPA- Assigning an access code to SPEED CALLING-SYSTEM, assign SRV = SSC (Service
Code), SID =...

NEAX2400 IPX Feature Programming ManualPage 644NDA-24297, Issue 1
S-3D Speed Calling - System - Dterm
S-3D  Speed Calling - System - Dterm
General Description
ThisfeatureallowsaDtermuser to call frequently dialed numbers using fewer digits (abbreviated call codes) than
would normally be required.
Operating Procedure
Originating a call from a Dterm
1. Press the SPEED CALLING-SYSTEM (SPEED-SYS) key.
2. Dial the abbreviated call code (maximum of four digits). The LCD displays:
3. The call is completed.
4....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 645
Speed Calling - System - DtermS-3D
Programming
STEP 1:ASYD- System Data 2, Index 1, bit 7. Does TOLL RESTRICTION [T-7] apply to SPEED
CALLING-SYSTEM? 0/1: No/Yes.
STEP 2:ANPD- Reserve a number level for feature access. Assign Connection Indexes of Normal (N),
Hooking (H), and Busy (B). Assign NND in accordance with a predetermined numbering plan.
STEP 3:ASPA- Assigning an access code to SPEED CALLING-SYSTEM, assign SRV = SSC (Service...

NEAX2400 IPX Feature Programming ManualPage 646NDA-24297, Issue 1
S-4 Splitting
S-4 Splitting
General Description
This feature allows the ATTENDANT CONSOLE [A-3] to speak privately with one party on an Attendant-handled
connection without the other party overhearing.
Operating Procedure
To speak with the called party only
1. Dial the desired telephone number.
2. Station class/telephone number is displayed.
3. Wait for the party to answer.
To speak with the calling party only
1. Press the SRC key.
2....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 647
Splitting S-4
Programming
No programming is required.
