NEAX2400 IPX Feature Programming ManualPage 628NDA-24297, Issue 1
R-16 Radio Paging
FCCS Programming (cont’d)
Note 1:When using ASYDL or ASYDN to program an FCCS feature, the basic programming of ASYD is required
in addition to ASYDL or ASYDN.
Note 2:The current command data shown is set to all nodes using the service: ASTD, ARTD, ATRK, ASFC

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 629
Route Restriction - Announcement R-27
R-27  Route Restriction - Announcement
General Description
This feature permits a station-originated call, dialed to a restricted outgoing number, to be automatically routed to a
recorded announcement informing the caller that the dialed number is restricted. (TOLL RESTRICTION [T-7])
Operating Procedure
No manual operation is required after this feature has been programmed in system data.
Service...

NEAX2400 IPX Feature Programming ManualPage 630NDA-24297, Issue 1
R-37 RS-464A PAD
R-37 RS-464A PAD
General Description
This service is for changing the current PAD control system for the lines and external trunks to a PAD control system
which conforms to the RS-464A specification.
The following table outlines the comparison between the current PAD control and the RS-464A PAD control.
Note:ONS: Line interface to On-Premises Line (General Telephone)
OPS: Line interface to Off-Premises Line (Log Line...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 631
RS-464A PAD R-37
General Description (cont’d)
PAD PATTERN 2 PAD PATTERN 2 PAD PATTERN 2
24 DTR WITH SFI 50 = 0 24 DTR WITH SFI 50 = 1 24DTR WITH APAD SETTING
ARTD
PAD
SETTINGTRANSMIT
PADRECEIVE
PADARTD
PAD 2TRANSMIT
PADRECEIVE
PADAPAD
SETTINGTRANSMIT
PADRECEIVE
PAD
0 -9db -3db 0ARTD,
PADARTD,
PAD1 -3db +3db
1 -3db +3db 1 -3db +3db 2 -3db -3db
2 -3db -3db 2 -3db -3db 3 -6db 0db
3 -6db 0db 3 -6db 0db 4 -9db -3db
4 -9db -3db 4 -9db...

NEAX2400 IPX Feature Programming ManualPage 632NDA-24297, Issue 1
R-37 RS-464A PAD
General Description (cont’d)
In 4 Wire E+M Mode, the 8TLTR can set PAD values using switch settings and ARTD and APAD values.
In the following table, P0 and P1 are assigned by setting ARTD to a value of 0, CDN 30:PAD and setting values by
usingSwitch1(P0)andSwitch2(P1).P2andP3areassignedbysettingARTD/APADtoavalueof5,andPAD
values are set by using Switch 3 positions 1, 2, 3 and 4 (P2) and positions 5, 6, 7 and 8 (P3)....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 633
RS-464A PAD R-37
Service Conditions (cont’d)
3. An Attendant Console is regarded as an ONS. The Attendant Console will follow the PAD values assigned
in ARTD.
4. If PAD data is assigned by APAD command, this data overrides other PAD data assigned by ARTD,
except when switch settings on the 24DTR are set to ARTD fixed.
5. PAD settings for the 8TLTR can be set using ARTD/APAD or a combination of switch settings and
ARTD/APAD.
6. This...

NEAX2400 IPX Feature Programming ManualPage 634NDA-24297, Issue 1
R-49 Ringer Mute
R-49 Ringer Mute
General Description
This feature allows a user to stop ringing by pressing the associated feature key on the Dterm.
Operating Procedure
1. The Dtermuser presses the RINGER MUTE key; the ringing is muted and the LED of the key lights. RING
OFF is displayed for three seconds.
2. The D
termuser presses the RINGER MUTE key again; the ringing is recovered and the LED of the key is
turned off. RING ON is...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 635
RouteNameDisplay R-51
R-51  Route Name Display
General Description
This feature allows a user to assign a desired trunk type for a route by the system data. The assigned trunk type
(maximum of 4 or 8 digits) is displayed on the upper line of DtermLCD.
4-digit display
TK No.
8-digit display
Note:Trunk type, which can be changed by system data.
Operating Procedure
No manual operation is required.
Service Conditions
1. Trunk types are...

NEAX2400 IPX Feature Programming ManualPage 636NDA-24297, Issue 1
R-51 RouteNameDisplay
Service Conditions (cont’d)
8-digit display
8. This feature is available when the D
termuser presses the call terminating sub line. This feature is also
available when the user presses the held sub line after holding a call using the HOLD key.
9. For data assignment to each of NDM (Network Data Memory) and LDM (Local Data Memory), different
commands can be used. However, the data in NDM has a priority. The logical...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 637
Remote Call Forwarding Control R-54
R-54  Remote Call Forwarding Control
General Description
This feature allows a station user to set/cancel the following forwarding features from the target station by dialing
the identification (ID) code preset for the forwarding station.
CALL FORWARDING - ALL CALLS [C-5]
CALL FORWARDING - BUSY LINE [C-2]
CALL FORWARDING - DON’T ANSWER [C-3]
SPLITCALLFORWARDING [S-99]
These forwarding features can also...
