NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 658NDA-24297, Issue 1
S-7 Station Hunting - Circular
FCCS Programming (cont’d)
STEP 2:ASHCN- This data must be assigned to the NCN.
Assign the Circular Hunt Group using Telephone Number.
UGN: User Group Number
TELN: Telephone Number in the Circular Hunt Group
First TELN: First assigned Telephone Number
SECRETARY TELN: Secretary Telephone Number
STEP 3:APHNN- Assign Phantom Telephone Number (PHTELN) to each Circular Hunt Station
UGN: User Group Number
TELN:...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 659
Station Hunting - Secretarial S-8
S-8  Station Hunting - Secretarial
General Description
This feature allows calls to a Hunt group to forward to a secretarial station when all the stations in the group are busy.
Operating Procedure
No manual operation is required.
Service Conditions
1. When all stations within a Hunt group are busy, the incoming call is routed to the station programmed as
the Secretarial Station.
2. If the Secretarial...

NEAX2400 IPX Feature Programming ManualPage 660NDA-24297, Issue 1
S-8 Station Hunting - Secretarial
Programming
See STATION HUNTING-CIRCULAR[S-7]and STATION HUNTING-TERMINAL[S-9].These
two types of station hunting use secretaries.
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 661
Station Hunting - Terminal S-9
S-9  Station Hunting - Terminal
General Description
This feature enables calls placed to busy stations, other than Pilot stations of a Hunt group, to receive a busy tone
rather than proceed through the normal hunting process. However, if the call is placed to the busy Pilot station of a
Hunt group, station hunting will proceed as usual.
Operating Procedure
No manual operation is required.
Service Conditions...

NEAX2400 IPX Feature Programming ManualPage 662NDA-24297, Issue 1
S-9 Station Hunting - Terminal
Service Conditions (cont’d)
d.) A station can belong to one hunting group only; it cannot belong to another group including that
for STATION HUNTING - CIRCULAR [S-7] or UNIFORM CALL DISTRIBUTION (UCD)
[U-1].
e.) When all stations to be hunted are busy, the incoming call is forwarded finally to the Secretarial
Station. However, when the station is not assigned or is also busy, busy tone is provided to the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 663
Station Hunting - Terminal S-9
Service Conditions (cont’d)
b.) When stations belonging to different nodes are assigned to a Hunt group, the station hunt may not
be activated in assigned order if the stations are not assigned in continuous order within a node.
First, the call is shifted to the station within the node of the Pilot station even though it is not in
consecutive order (in the node, station hunt is activated in assigned order)....

NEAX2400 IPX Feature Programming ManualPage 664NDA-24297, Issue 1
S-9 Station Hunting - Terminal
Service Conditions (cont’d)
27. STATION HUNTING - TERMINAL can be programmed on a node basis even in the use of telephone
numbers. In other words, the feature became available via the data written on the Local Data Memory
(LDM), not only on the Data Memory (DM) or the Network Data Memory (NDM). If this is the case,
conditions are as follows:
a.) The feature is to be programmed by using the telephone number...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 665
Station Hunting - Terminal S-9
Interactions (cont’d)
c.) When hunting occurs, if Station A is the only idle station in the hunting pattern, a busy tone is
returned to the calling party.
d.) During a Call Forward-Override call from Station B to Station A, if station A is idle, Station A
will ring. If Station A is busy, the call will not hunt.
e.) If the Pilot sets CALL FORWARDING-ALL CALLS [C-5] to Station B: During a Call Forward-...

NEAX2400 IPX Feature Programming ManualPage 666NDA-24297, Issue 1
S-9 Station Hunting - Terminal
Interactions (cont’d)
e.) If the Pilot sets CALL FORWARDING-BUSY LINE [C-2] to Station B: During a Call Forward-
Override call from Station B to the Pilot, if the Pilot station is idle, the Pilot will ring. If the Pilot
station is busy, the call will hunt.
6. STATION MESSAGE DETAIL RECORDING [S-10]: The number recorded is the telephone number
where the call actually terminates.
7. STATION HUNTING-CIRCULAR...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 667
Station Hunting - Terminal S-9
Interactions (cont’d)
When PH = 0: Station hunt starts by dialing the pilot station number (telephone number) only. The
feature is not provided when the PHTELN is dialed.
9. The lead station is the first station programmed in the ASHP command.
10. When Programmed on LDM:
a.) When activating this feature via FCCS, when CALL FORWARDING - ALL CALLS [C-5] is in
service at a pilot station, a call directed to the...
