NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 678NDA-24297, Issue 1
S-10 Station Message Detail Recording (SMDR)
Service Conditions (cont’d)
4. Assign Fusion Point Code (FPC) of new-Center Node to all node including ex-Center Node by using
ASYDL command System Data 1 Index 577.
Interactions
1. If LCR(S) is provided, the LCR(S) access code is listed in ARNP. If an outgoing route is not used in
LCR(S), then list the OGCA access code in ARNP.
2. To test SMDR output, it is recommended that a serial printer or...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 679
Station Message Detail Recording (SMDR) S-10
Programming (cont’d)
System Data 1, Index 32, Bit 6. Is the number sent or number dialed recorded in SMDR? 0/1: Number
Sent/Number Dialed.
System Data 1, Index 33. Assign this index for Split Billing. If Split Billing is used, assign 00H. If
Total Billing is used, Bits 3 & 4 represent the following: 00: Telephone called first. 01: Telephone
called last. 10: Telephone receiving call from an...

NEAX2400 IPX Feature Programming ManualPage 680NDA-24297, Issue 1
S-10 Station Message Detail Recording (SMDR)
Programming (cont’d)
Provided that“1”is flagging in Bit 0 of Index 576 (System Data 1), let every Local Node recognize its
belonging Center Node for centralized billing-Fusion. Assign data on Center Node FPC at each Local
Node. Given this data, the Local Nodes can acknowledge the SMDR polling only from the Center
Node specified here (the polling from other parties will be ignored).
At the Center...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 681
Station Message Detail Recording (SMDR) S-10
Programming
After the Center Node (multiple CN: possible on a network) is assigned for centralized billing-Fusion,
let the Center Node recognize its polling destination (specified by the FPC), referring to the table
below. In the table, each bit represents Fusion Point Code ranging from 1 to 253. When“1”is set, the
FPC is specified as the polling destination.
INDEXB7B6B5B4B3B2B1B0
608
7654321...

NEAX2400 IPX Feature Programming ManualPage 682NDA-24297, Issue 1
S-10 Station Message Detail Recording (SMDR)
Programming (cont’d)
System Data 1, Index 641, Bit 0. Type of the station number for the ICS text format.
0/1=Physical Station Number/Telephone Number.
System Data 1, Index 641, Bit 3. Kind of the route number for the ICS text format.
0/1=Physical Route Number/Logical Route Number.
STEP 3:SOCKET Interface (Lan Interface) Programming
System Data 1, Index 529: Assign the methods of parity check...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 683
Station Message Detail Recording (SMDR) S-10
Programming (cont’d)
STEP 7:ASFC- Assign data“1”to SFI 14 of a Service Feature Class, the traffic of which is to be registered on
SMDR (Trunk Basis). Assign data“1”to SFI 58 of a Service Feature Class the traffic of which is to be
registered on SMDR (STN to STN Basis).
Note:When SMDR for station-to-station calling is not used, both stations in communication must be restricted at
the SFI 58....

NEAX2400 IPX Feature Programming ManualPage 684NDA-24297, Issue 1
S-11 Station-to-Station Calling
S-11 Station-to-Station Calling
General Description
This feature permits any user to directly dial another station within the NEAX2400 IPX system without operator
assistance.
Operating Procedure
1. Lift the handset; receive dial tone.
2. Dial the desired telephone number.
Service Conditions
1. If the called station is off-hook, the originating station receives a busy tone. Otherwise, the called station
will...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 685
Station-to-Station Calling S-11
Programming (cont’d)
STEP 2:AT N R- Assign for Tenant Restriction Index (TRI) 0. This index allows for station-to-station calling
between the same tenant and between different tenants.
DAY/NIGHT: Day/Night Mode
D: Day Mode
N: Night Mode
OGTN: Originating Tenant
TMTN: Terminating Tenant
TRI: Tenant Restriction Index (0-15)
RES: Restriction Data
0: Restricted
1: Allowed
TRI: Tenant Restriction Index
0: Allows...

NEAX2400 IPX Feature Programming ManualPage 686NDA-24297, Issue 1
S-12 Station-to-Station Calling - Operator Assistance
S-12  Station-to-Station Calling - Operator Assistance
General Description
This feature allows a user to call another station within the PBX, with the assistance of the ATTENDANT
CONSOLE [A-3] operator.
Operating Procedure
1. Lift the handset; receive dial tone.
2. Dial the operator access code (normally“0”).
3. Relay the desired telephone number to the Attendant.
4. The Attendant dials...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 687
Station-to-Station Calling - Operator Assistance S-12
Programming (cont’d)
TRI: Tenant Restriction Index (0-15)
RES: Restriction Data
0: Restricted
1: Allowed
FCCS Programming
No unique programming is required for the FCCS network.
