NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 708NDA-24297, Issue 1
S-33 Software Line Appearance
S-33 Software Line Appearance
General Description
This feature permits ports that do not physically exist to be used as sub-lines on Dtermstations. Ports normally
reserved on a Dtermfor data stations only, can be assigned as a SOFTWARE LINE APPEARANCE. Additionally,
64 software ports have been added to a Port Interface Module. The 64 software-assigned ports can be assigned as
virtual line appearances on D...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 709
Software Line Appearance S-33
Programming
STEP 1:ASDT- Assign the station as a TEC = 18 for a Virtual Circuit. The Line Equipment Number (LEN) of
a SOFTWARE LINE APPEARANCE will exist in Groups 24-31.
STEP 2:AKYD- This command assigns for D
terms the SOFTWARE LINE APPEARANCE to a programmable
Line/Feature key.
TN: 1
STN: Station Number
TP: Type of D
term0/1:
RING: Assign ringing to the entire phone.
0: No Ringing
1: Ringing All Lines
2:...

NEAX2400 IPX Feature Programming ManualPage 710NDA-24297, Issue 1
S-61 Speed Calling Override - System
S-61  Speed Calling Override - System
General Description
This feature allows numbers programmed for SPEED CALLING to be available to stations on a system-wide basis,
determined by Service Feature Class (SFC). For example, SPEED CALLING-SYSTEM [S-3] numbers, available
to stations that are not restricted, can be made available to stations that are restricted.
Operating Procedure
To operate
1. Lift the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 711
Speed Calling Override - System S-61
Programming
STEP 1:ASYD- System Data 2, Index 1, Bit 6. Is SPEED CALLING OVERRIDE-SYSTEM to be enabled? 0/
1: No/Yes. System Data 2, Index 1, Bit 7. Toll Restriction for SPEED CALLING-SYSTEM [S-3].
Assign data“0”.
STEP 2:ANPD- Reserve a number level for feature access. Assign for Normal (N), Hooking (H), and Busy
(B). Assign NND in accordance with a predetermined numbering plan.
STEP 3:ASPA- Assigning...

NEAX2400 IPX Feature Programming ManualPage 712NDA-24297, Issue 1
S-62 Station 5db PAD
S-62 Station 5db PAD
General Description
This feature allows a single-line user to be affected by the 5db loss through the system on station-to-station calls.
Operating Procedure
No manual operation is required for this software control feature.
Service Conditions
1. STATION 5db PAD [S-62] is inserted only for intra-office, two-way, station-to-station connections.
2. STATION 5db PAD is inserted into the called party...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 713
Serial Call - Loop Release S-64
S-64  Serial Call - Loop Release
General Description
This feature allows an ATTENDANT CONSOLE loop key to become available after setting SERIAL CALL [S-15].
Operating Procedure
1. The Attendant answers an incoming Central Office call.
2. The Attendant extends the call to the desired station, and the desired station answers.
3. The Attendant presses the SC key. The loop is now available for another call.
4....

NEAX2400 IPX Feature Programming ManualPage 714NDA-24297, Issue 1
S-64 Serial Call - Loop Release
FCCS Programming
No unique programming is required for the FCCS network.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 715
Split Call Forwarding S-99
S-99  Split Call Forwarding
General Description
This feature allows a station to set two different target stations for CALL FORWARDING-ALL CALLS
(FORWARD)/BUSY LINE (FORWARD-BY)/DON’T ANSWER (FORWARD-DA), depending on whether the
incoming call is from an internal station or an outside party (C.O. TIE, DID, etc.).
Operating Procedure
1. Station A sets or is set for CALL FORWARDING-ALL CALLS/BUSY LINE/DON’T...

NEAX2400 IPX Feature Programming ManualPage 716NDA-24297, Issue 1
S-99 Split Call Forwarding
Operating Procedure (cont’d)
To set SPLIT CALL FORWARDING using Dterm feature key
To set Call Forwarding from an individual station (D
term)
1. Setting Call Forwarding for an incoming call from a station:
a.) Confirm that the PAGE* (One-touch changeover) lamp is on; if the lamp is off, turn the lamp on
by pressing the PAGE key.
b.) Lift the handset or press the SPEAKER key; receive dial tone.
c.) Press the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 717
Split Call Forwarding S-99
Operating Procedure (cont’d)
When the destination is an outside trunk, the Dtermdisplays:
To cancel Call Forwarding from an individual station (Dterm)
1. Cancelling Call Forwarding for an incoming call from a station:
a.) Confirm that the PAGE (One-Touch Changeover) lamp is on; if the lamp is off, turn the lamp on
by pressing the PAGE key.
b.) Lift the handset or press the SPEAKER key; receive service set tone....
