NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 698NDA-24297, Issue 1
S-23 Speed Calling - Group
Service Conditions (cont’d)
11. SPEED CALLING-GROUP data remains, even if the system is re-initialized or there is a power failure.
12. A pause may be programmed using the“
*”button of a PB pad. This will take one of the 24 digits
available. Rotary type phones cannot store a pause. A pause lasts 2.8 seconds.
13. Stations can be added or removed from a group only via MAINTENANCE ADMINISTRATION
TERMINALS (MAT) -...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 699
Speed Calling - Group S-23
Programming (cont’d)
STEP 5:AISA- Program the tenant, station, type of station, and the number of Speed Calling blocks to be
assigned to the Primary station.
TN: Tenant Number
STN: Station Number
MST/SLV: Primary/Secondary
M: Primary Station
S: Secondary Station
BLOCK: Number of Blocks
STN: When assigning Secondary Station, assign the Primary Station number.
STEP 6:AKYD- Assign Type:Function:SPEED...

NEAX2400 IPX Feature Programming ManualPage 700NDA-24297, Issue 1
S-24D Save And Repeat - Dterm
S-24D  Save And Repeat - Dterm
General Description
This feature allows for a Dtermset to save a specific dialed number and then redial that number later.
Operating Procedure
1. Go off-hook, seize any idle line, and dial a number.
2. When the number has been dialed, press the SAVE AND REPEAT (S&R) feature key. The dialed number
is stored for future use. The associated LED lights. The LCD displays:
Note:Dialed...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 701
Save And Repeat - DtermS-24D
Interactions
AKYD is assigned after ASDT is assigned. Assign a LEN as TEC 12.
Programming
STEP 1:AKYD-AssigntheDtermaccording to the following parameters:
TN: 1
STN: Station Number
TP: Type of D
term0/1:
RING:
0: No Ringing
1: Ringing All Lines
2: Ringing on Prime Line Only
3: Flexible Ring Assignment, enables RG parameter.
KYN: Key Number (1-40)
KYI: Service Index
0: Key Not Used
1: Feature Key
2: Multi-line...

NEAX2400 IPX Feature Programming ManualPage 702NDA-24297, Issue 1
S-25D Service Display - Dterm
S-25D  Service Display - Dterm
General Description
This feature generates LCD displays corresponding to the various features as they are initiated.
Operating Procedure
Each display is automatically generated when a feature is initiated.
Service Conditions
1. Each display is controlled by system data and is produced accordingly. The service display may be
allowed or denied in system data on a per-system...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 703
Speed Calling - One Touch - DtermS-26D
S-26D  Speed Calling - One Touch - Dterm
General Description
This feature allows Dtermusers to dial telephone numbers by pressing a single key. Up to 12/24 numbers may be
programmed by the Dtermuser.
Operating Procedure
To program
1. Press the FEATURE key.
2. Press the SPEED CALLING-ONE TOUCH button.
3. Dial the desired number.
4. Press the FEATURE key again.
5. Display will show SPEED SET.
Note:The...

NEAX2400 IPX Feature Programming ManualPage 704NDA-24297, Issue 1
S-26D Speed Calling - One Touch - Dterm
Service Conditions (cont’d)
10. FLASH ENTRY and VOICE CALL features may be combined on a SPEED CALLING-ONE TOUCH
key to activate an automatic voice-announce transfer. To program, press the SPEED CALLING-ONE
TOUCH key, press the RECALL key, dial the number, press the TRANSFER key, then press the SPEED
CALLING-ONE TOUCH key.
11. A PAGE CHANGEOVER key must be assigned to a programmable Line/Feature key...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 705
Service Feature Peg Count S-27
S-27  Service Feature Peg Count
General Description
This feature provides a statistical usage report on various features, generated at the MAINTENANCE
ADMINISTRATION TERMINAL (MAT) [M-18]. This report will provide the Communications Manager with
detailed users’habits and planning data for the communications system.
Operating Procedure
Refer to NEAX2400 IPX System Operations and Maintenance Manual.
Service...

NEAX2400 IPX Feature Programming ManualPage 706NDA-24297, Issue 1
S-27 Service Feature Peg Count
Service Conditions (cont’d)
17. SPEED CALLING ACCESS-GROUP [S-23] count: Number of times a variable abbreviated number is
registered by stations for which the feature is allowed.
18. TRUNK ANSWER FROM ANY STATION (TAS) [T-8] count: Number of times the TAS Answer code
is dialed by stations for which the feature is allowed.
19. OFF-HOOK QUEUING [O-7] count: Number of times an extension accesses an outgoing...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 707
Service Feature Peg Count S-27
Programming (cont’d)
10: UCD Station Peg Count
11: CCIS Traffic Count
STEP 3:TYPEs not listed, are not used.
Display of Traffic Data 1 (DTF1)
TYPE: Type of Traffic Measurement
1: Terminal Traffic
2: Route Traffic
3: Station Peg Count
4: ATT Peg Count
5: Route Peg Count
Display of Traffic Data 2 (DTF2)
TYPE: Type of Traffic Measurement
6: Service Peg Count
7: Terminal Peg Count
Display of Traffic Data 3...
