NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 718NDA-24297, Issue 1
S-99 Split Call Forwarding
Operating Procedure (cont’d)
When the destination is an ATTENDANT CONSOLE, the Dtermdisplays:
When the destination is an outside trunk, the D
termdisplays:
2. To monitor the assigned data for station-to-station calls:
a.) Confirm that the PAGE key LED on the D
termis illuminated. (If it is not illuminated, press the
PAGE key to turn it on.)
b.) While the D
termis in the idle state (on-hook), press the CALL...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 719
Split Call Forwarding S-99
Operating Procedure (cont’d)
To cancel Call Forwarding from the Attendant Console
1. Cancelling Call Forwarding for an incoming call from a station:
a.) Press an idle loop key and dial the cancel code for FORWARD, FORWARD-BY, or
FORWARD-DA for an incoming call from a station; receive special dial tone.
b.) Dial the Tenant Number (2 digits) of the originating station and the originating telephone number.
c.)...

NEAX2400 IPX Feature Programming ManualPage 720NDA-24297, Issue 1
S-99 Split Call Forwarding
Service Conditions (cont’d)
10. In the UCD procedure, if SPLIT CALL FORWARDING - ALL CALLS (either for station-to-station or
incoming trunk) is set on a station in the group, that station is skipped.
11. If SPLIT CALL FORWARDING is set on a station in the hunting group (STATION HUNTING -
CIRCULAR [C-7], - TERMINAL [S-9], that station is skipped in hunting. However, if the station has set
SPLIT CALL FORWARDING for...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 721
Split Call Forwarding S-99
Programming (cont’d)
SN=1, FKY=2: Call Forwarding - All Calls (FDA)
SN=1, FKY=22: Call Forwarding - Don’tAnswer(FDN)
SN=1, FKY=55: Call Forwarding - One - Touch Changeover (PAGE)
This command is used for assigning a function to each soft key.
STEP 6:ASFC- Allows Call Forwarding-All Calls (SFI = 7), Call Forwarding-Busy Line (SFI = 9), or Call
Forwarding-Don’t Answer (SFI = 8) to the SFC of the Station.
STEP...

NEAX2400 IPX Feature Programming ManualPage 722NDA-24297, Issue 1
S-106 Slumber Time - Do Not Disturb
S-106  Slumber Time - Do Not Disturb
General Description
This service allows a slumber time for up to four times per day on a Station group basis. During the slumber time,
all stations in the group concerned are placed into Do Not Disturb mode, and incoming calls (Station/DID/DIT) will
be routed to the Attendant or an announcement machine.
Operating Procedure
No manual operation is required.
Service...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 723
Slumber Time - Do Not Disturb S-106
Service Conditions (cont’d)
16. CALL BACK [C-1] and CALL WAITING-ORIGINATING [C-31] can be set from a Slumber Time
station.
17. Each of the following services is restricted to a Slumber Time station:
CALL WAITING-ORIGINATING [C-31]
CALL BACK [C-1]
EXECUTIVE RIGHT-OF-WAY [E-1]
18. Each of the following terminals can access to a Slumber Time station during a Slumber Time. (Slumber
Time Override Service):...

NEAX2400 IPX Feature Programming ManualPage 724NDA-24297, Issue 1
S-106 Slumber Time - Do Not Disturb
Programming (cont’d)
Assignment of Slumber Time Data
ASLU2-
G= [x] Slumber Time Group Number (1-7)
CNT = [x] Count of Assigned Transfer Destination/Time Data
TFR 1/2: Transfer to attendant/announcement machine
FROM = [x] Slumber Time Start Time
TO = [x] Slumber Time End Time
Note
Note:
If the Slumber service is required 24 hours a day, enter the same time data in to both the“From Hour/From...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 725
Serial Call - DtermS-127
S-127  Serial Call - Dterm
General Description
This feature allows the Dtermuser to set SERIAL CALL to the central office line/tie line call and extend the call to
the desired station/trunk. When the communication with the desired party ends, the announcement instructing the
caller to dial the next desired party number is sent out. The caller, by following the instructions, can be connected
to a number of...

NEAX2400 IPX Feature Programming ManualPage 726NDA-24297, Issue 1
S-127 Serial Call - Dterm
Service Conditions (cont’d)
10. Whether to send the announcement can be determined on a system basis. If the announcement is not sent,
the caller receives dial tone. Both the first and the second announcement is connected in single connection,
and the caller receives no tone until the announcement is sent.
11. When Serial Call is attempted, and the caller encounters all announcement trunks busy or when there is
no...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 727
Serial Call - DtermS-127
Service Conditions (cont’d)
when the outgoing trunks are all busy (if Tandem Trunk Queuing service is set, the service is
activated).
20. After the second announcement is sent out, whether to allow dialing of the next number or to release the
call automatically can be selected on a system basis.
21. The announcement can be either 16, 32, or 60 seconds, depending on the key setting of the announcement
trunk...
