NEAX2400 IPX Feature Programming ManualPage 728NDA-24297, Issue 1
S-129 SMDR Output Expansion - ANI/CPN
S-129  SMDR Output Expansion - ANI/CPN
General Description
This feature expands SMDR information output, by which calling numbers from Central Office may be output to
the expanded area.
Operating Procedure
No manual operation is required.
Service Conditions
1. When the expanded area information is used, SMDR equipment must corresponds to the expanded output
format.
2. Users may assign 24 kinds of...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 729
SMDR Output Expansion - ANI/CPN S-129
Service Conditions (cont’d)
4. Regarding the ANI information identifier, the numbers 0, 2, 3, 4 and 5 are output only when the
information is sent from Central Office.
Note:Meanings of ANI information identifier numbers:
0 = Not output
1=Display
2 = Not display
3 = Not provide service
4 = Outgoing C.O. call
5 = Service Condition
5. When an office receiving a calling number from Central Office extends...

NEAX2400 IPX Feature Programming ManualPage 730NDA-24297, Issue 1
S-129 SMDR Output Expansion - ANI/CPN
Programming (cont’d)
When Calling Number is output to SMDR, the following expanded format is used:
System Data 1, Index 288, Bit 5. Expanded SMDR Output for SMDR A Apparatus. 0/1 = Out/In
Service.
System Data 1, Index 290, Bit 5. Expanded SMDR Output for SMDR B Apparatus. 0/1 = Out/In
Service.
System Data 1, Index 292, Bit 5. Expanded SMDR Output for SMDR C Apparatus. 0/1 = Out/In
Service.
System Data...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 731
SMDR Output Expansion - ANI/CPN S-129
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending
on the node.
 Note
STEP 1:ASYDL- System Data 1, Index 241, Bit 6. 0/1 = When the length of Caller ID...

NEAX2400 IPX Feature Programming ManualPage 732NDA-24297, Issue 1
S-129 SMDR Output Expansion - ANI/CPN
FCCS Programming (cont’d)
Note:When using ASYDL or ASYDN to program an FCCS feature, the basic programming of ASYD is required
in addition to ASYDL or ASYDN.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 733
Tandem Switching of TIE Trunks - 2/4-Wire T-1
T-1  Tandem Switching of TIE Trunks - 2/4-Wire
General Description
This feature allows trunk-to-trunk connections through the switching system, without the need for any Attendant
assistance or control. The major use of this feature is in association with the Dial Tandem TIE Line Network to allow
TIE Line connections and incoming TIE Line calls automatic access to, and completion of, local...

NEAX2400 IPX Feature Programming ManualPage 734NDA-24297, Issue 1
T-1 Tandem Switching of TIE Trunks - 2/4-Wire
Interactions (cont’d)
f.) CCSA trunk
4. STATION MESSAGE DETAIL RECORDING (SMDR) [S-10]: On Tandem Connections, the incoming
TIE Trunk group route number and outgoing trunk number are recorded.
5. Two outgoing trunk group restriction tables are provided per system. The Direct Dial Access table is
indexed when a distant user dials the trunk group access code, and the ATTENDANT CONSOLE [A-3]
table...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 735
Tandem Switching of TIE Trunks - 2/4-Wire T-1
FCCS Programming (cont’d)
STEP 4:ARRCN- Assign to the system trunk-to-trunk connection. Use Alternative Route Index (ARI-D-RES)
for Direct Connection. Three possible Restrictions may be assigned; data“0”, Connection is
Restricted; data“1”, Connection is Allowed; or data“2”, Toll Restriction is required. For TANDEM
SWITCHING OF TIE TRUNKS-2/4 WIRE, TOLL RESTRICTION is not required.
STEP...

NEAX2400 IPX Feature Programming ManualPage 736NDA-24297, Issue 1
T-2 Three-Way Calling
T-2 Three-Way Calling
General Description
This feature enables any user to add another party to an existing connection, establishing a three-way conference.
Even if the additional D
termuser holds the call, THREE-WAY CALLING may be established. (This service is called
Consultation Hold.)
Operating Procedure
Procedure 1
1. Press switch hook; first party is placed on Consultation Hold; receive special dial tone.
2. Dial...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 737
Three-Way Calling T-2
Interactions
1. A station in an established three-way connection cannot flash the switch hook to activate a feature. The
flash disconnects the last party connected.
2. All three-way calls are protected by privacy. No more than three ports can be bridged together at one time,
unless PRIVACY RELEASE [P-18] is being used.
3. If a three-way call includes two trunks and the station hangs up, the trunks will release,...
