NEAX2400 IPX Feature Programming ManualPage 748NDA-24297, Issue 1
T-7 Toll Restriction - 3/6-Digit
T-7  Toll Restriction - 3/6-Digit
General Description
This feature allows the NEAX2400 IPX to be programmed to restrict outgoing calls according to specific area and/
or central office codes. This restriction is controlled on the basis of a three-digit area code or a six-digit combination
area and office code numbering plan.
Operating Procedure
No manual operation is required.
Service Conditions
1. The...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 749
Toll Restriction - 3/6-Digit T-7
Programming
Note:The digits underlined are to be listed in the DC (Digit Code) parameter.
Overseas or Operator-assisted calls should be listed with an MND equal to the calculated number of
required digits.
Special dialing sequences, such as,“911”with an MND = 4 should also be listed.
N = 2-9, P = 0 or 1, X = 0-9
STEP 1:AT D P- This command is used with the AARP command. It designates the digit codes that...

NEAX2400 IPX Feature Programming ManualPage 750NDA-24297, Issue 1
T-7 Toll Restriction - 3/6-Digit
Programming (cont’d)
System Data 2, Index 1, Bit 3. Does TOLL RESTRICTION apply to SPEED CALLING-STATION
[S-21]? 0/1: Yes/No.
System Data 2, Index 1, Bits 4 & 5. If TOLL DENIAL (busy tone) is required, assign these Bits as data
“00”. If TOLL DIVERSION (to Attendant) is required, assign these Bits as“01”.
System Data 2, Index 1, Bit 7. Does TOLL RESTRICTION apply to SPEED CALLING-SYSTEM [S-
3]? 0/1: Yes/No....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 751
Toll Restriction - 3/6-Digit T-7
Programming (cont’d)
Toll Restriction Examples
Several examples of the use of TOLL RESTRICTION are listed below:
RSC 1: Allow local only.
RSC 2: Allow local plus Area Codes 718, 212, 201, and 914.
RSC 3: Allow local plus Area Codes 718, 212, and 201; and office codes 239, 465, and 798 only
within Area Code 914.
RSC 4: Allow local plus all Area Codes except 808, 213, 408, and 714.
RSC 5: Allow local plus...

NEAX2400 IPX Feature Programming ManualPage 752NDA-24297, Issue 1
T-7 Toll Restriction - 3/6-Digit
Programming (cont’d)
DAY/NIGHT:D (Day)
OGRT: 1 RSC: 3
DC: 92 TDI: 1(Connection is Allowed)
Repeat these same assignments for Digit Codes“93”through“99”to allow all local office codes.
To allow Area Codes 718, 212, and 201, repeat the ATDP command for the following Digit Codes:
DC: 91718 TDI: 1 (Connection is Allowed)
DC: 91212 TDI: 1 (Connection is Allowed)
DC: 91201 TDI: 1 (Connection is Allowed)
To allow...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 753
Toll Restriction - 3/6-Digit T-7
Programming (cont’d)
DC: 914798 RES: 1 (Connection is Allowed)
OGRT: 1 RSC: 3 FLAG: 2
DC: 718623 RES: 1 (Connection is Allowed)
DC: 718567 RES: 1 (Connection is Allowed)
This allows just these office codes within these particular Area Codes. All other area codes beginning
with“7”or“9”are also restricted. At this point, if allowing Area code 714 is desired, assign AARP as
follows:
AARP Command-
OGRT: 1 RSC:...

NEAX2400 IPX Feature Programming ManualPage 754NDA-24297, Issue 1
T-7 Toll Restriction - 3/6-Digit
Programming (cont’d)
ATDP Command-
TDM/OG: O (Outgoing Connection)
DAY/NIGHT: D (Day)
OGRT: 1 RSC: 5
DC: 92 TDI: 1 (Connection is Allowed)
Repeat these same assignments for Digit Codes“93”through“99”to allow all local office codes.
TDM/OG: O (Outgoing Connection)
DAY/NIGHT: D (Day)
OGRT: 1 RSC: 5
DC: 912 TDI: 2 (Go to AARP Command)
NND: 6
DC: 913 TDI: 2 NND: 6
(GotoAARPCommand)
DC: 914 TDI: 2 NND: 6...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 755
Toll Restriction - 3/6-Digit T-7
Programming (cont’d)
Example 6 - Trunk-to-Trunk Connection
Allow all Local Calls
ATDP Command-
TDM/OG: T (Tandem Connection)
ICRT: Route 2 OGRT: 1
DC: 92 TDI: 1 (Connection is Allowed)
Repeat these same assignments for Digit Codes“93”through“99”to allow all local office codes.
Notice that assignments for digit codes“90”and“91”, which cover operator calls and all 1 + Area
Code calls, are not assigned. Digit...

NEAX2400 IPX Feature Programming ManualPage 756NDA-24297, Issue 1
T-8 Trunk Answer from Any Station (TAS)
T-8  Trunk Answer from Any Station (TAS)
General Description
This feature allows any station (except one with incoming restrictions) to answer incoming calls when the system is
in Night Mode. Incoming exchange network calls will activate a common alert (TAS) signal at the customer’s
premises. By dialing a specified code, any station may answer the call and then extend it to any other station using...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 757
Trunk Answer from Any Station (TAS) T-8
Interactions (cont’d)
4. CALL TRANSFER-ALL CALLS [C-11]: A station answering a call via the TAS feature will have access
to the transfer feature.
5. CENTRALIZED ATTENDANT SERVICE (CAS) [C-20]: TAS may be installed at either the Main site
only or at both the Main and Satellite sites. Operations at either site are the same as TAS installed in a non-
CAS system. The Satellite system must have a means...
