NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 738NDA-24297, Issue 1
T-2D Three-Way Calling - Dterm
T-2D  Three-Way Calling - Dterm
General Description
This feature enables a Dtermuser to establish a three-way conference by connecting an additional party to an already
existing conversation.
Even if the additional D
termuser holds the call (Consultation Hold), THREE-WAY CALLING may be established.
Operating Procedure
Procedure 1
1. Press the TRANSFER key; receive special dial tone; the original party is...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 739
Three-Way Calling - DtermT-2D
Service Conditions (cont’d)
5. When the additional station answers the held call, the decision to send Override Tone depends on the
originating station service restriction class.
6. The Conference Trunk (CFT) function is required for the node which accommodates the station operating
a three-way conference within the FCCS network.
7. Three-Way Calling can also be established when using the trunk belonging to...

NEAX2400 IPX Feature Programming ManualPage 740NDA-24297, Issue 1
T-2D Three-Way Calling - Dterm
FCCS Programming (cont’d)
Note:When using ASYDL or ASYDN to program an FCCS feature, the basic programming of ASYD is required
in addition to ASYDL or ASYDN.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 741
TIE Line Access T-3
T-3 TIE Line Access
General Description
This feature allows any user dial access to a TIE Line.
Operating Procedure
1. Lift the handset; receive dial tone.
2. Dial the TIE LINE ACCESS code; receive dial tone from the distant PBX.
3. Dial the desired extension number.
Service Conditions
1. TIE LINE ACCESS may be denied to individual stations via CLASS OF SERVICE-INDIVIDUAL [C-
15].
2. The PBX system is equipped with...

NEAX2400 IPX Feature Programming ManualPage 742NDA-24297, Issue 1
T-3 TIE Line Access
Programming
STEP 1:ARTD- Assign the TIE Line routes as shown below:
BOTHWAY LINES:
RT: 1
1-OSGS :2/7 2-ONSG :3 3-ISGS :2/7 4-INSG :3 5-TF :3
6-TCL :4 7-L/T :1 8-RLP :2 13-AC :1 15-LSG :5
28-ANS :1 30-PAD :7
STEP 2:AT R K- Assign the LENs, TIE Line Route Number, Trunk Number, and Tenant Number.
STEP 3:MBTK- Assign the Make Idle status to the TIE Line trunks.
STEP 4:ANPD- Assign a number level for trunk access. Assign...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 743
TIE Line Connection With Pad Control T-5
T-5  TIE Line Connection With Pad Control
General Description
This feature provides a switchable transmission pad on TIE trunks that allows tandem connections. Necessary pad
control is activated to protect against echo.
Operating Procedure
No manual operation is required.
Service Conditions
1. Pad Control (2dB) will automatically be switched in for the following connections:
a.) TIE...

NEAX2400 IPX Feature Programming ManualPage 744NDA-24297, Issue 1
T-5 TIE Line Connection With Pad Control
Programming (cont’d)
T: Tandem Connection
ICRT: Incoming Route Number
OGRT: Outgoing Route Number
SFC: Service Feature Class [Not Used]
IC PAD: Incoming PAD Data (1-15)
OG PAD: Outgoing PAD Data (1-15)
RT: Route Number [Not Used]
PAD DATA:
TLT (4W E&M)
DTI
0-8dB Pad On
1-2dB Pad On 1-2dB Pad On
2-4dB Pad On 2-4dB Pad On
3-6dB Pad On 3-6dB Pad On
4-8dB Pad On 4-8dB Pad On
15-PAD OFF 7-PAD OFF
FCCS...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 745
Toll Denial/Toll Diversion T-6
T-6 Toll Denial/Toll Diversion
General Description
This feature prohibits users from placing long distance calls over a specific group of trunks. Restricted calls are
routed to either an ATTENDANT CONSOLE [A-3] (diversion) or to an intercept tone (denial).
Operating Procedure
No manual operation is required after this feature is programmed into system data.
Service Conditions
1. TOLL DENIAL/TOLL DIVERSION...

NEAX2400 IPX Feature Programming ManualPage 746NDA-24297, Issue 1
T-6 Toll Denial/Toll Diversion
Programming (cont’d)
Bit 3- Develop ATDP command for Day/Night?
System Data 2, Index 1, bits 4 & 5. If TOLL DENIAL is required, assign these bits as data“00”.If
TOLL DIVERSION is required, assign these bits as“01”. Calls are then diverted to the Attendant
Console. Assigned on a per-tenant basis.
STEP 2:ARSC- Assign Route Restriction Classes. When these are assigned to stations, classes will determine
whether...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 747
Toll Denial/Toll Diversion T-6
FCCS Programming (cont’d)
RES: Restriction Data
0: Connection is Restricted
1: Connection is Allowed
2: Connection is Toll Restricted (See TOLL RESTRICTION-3/6-DIGIT[T-7])
STEP 3:ASDTN- When assigning the data to specific stations, assign the proper RSC to each station.
Note:When using ASYDL or ASYDN to program an FCCS feature, the basic programming of ASYD is required
in addition to ASYDL or ASYDN.
