NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 758NDA-24297, Issue 1
T-8 Trunk Answer from Any Station (TAS)
Programming (cont’d)
STEP 5:ACFR- Allow a Transfer Service Feature Index of 5, TAS to the listed types of incoming calls to be
answered by TAS. The Call Class Indexes (CCI) will correspond to ARTD, CDN 6:TCL; Trunk Class
parameter.
CCI: 1-LDN
2-DDD2
3-DDD3
4-TIE LINE
5-DDD4
STEP 6:ATA S- Assign the TAS circuit to the TN, MG, PIM, and the circuit number: 0/1; based on the circuit
location. TAS CKT # =...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 759
Trunk Group Busy Lamp T-9
T-9  Trunk Group Busy Lamp
General Description
This feature provides the ATTENDANT CONSOLE [A-3] with a visual indication when all trunks in a particular
trunk group are busy (LDN, WATS, FX, DOD, CCSA, TIE or Special Trunks). Assignment of the TGBLs is made
using the MAINTENANCE ADMINISTRATION TERMINAL (MAT) [M-18].
Operating Procedure
No manual operation is required.
Service Conditions
1. The ATTENDANT CONSOLE...

NEAX2400 IPX Feature Programming ManualPage 760NDA-24297, Issue 1
T-9 Trunk Group Busy Lamp
Programming (cont’d)
TGBL data can be collected/transmitted from/to all LMGs by the circuit card DLMX (PA-PC94) via
DLKC circuit cards in the IPX-U. For more detailed information, see the NEAX2400 IPX Office Data
Specification and the NEAX2400 IPX Circuit Card Manual.
For the DLMX (PA-PC94) Circuit Card
STEP 1:ASYD- SYS1 Index 15, b0-3: In hexadecimal, assign how many TGBLs are to be used out of a total
of 10...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 761
Trunk-to-Trunk Connection T-10
T-10 Trunk-to-Trunk Connection
General Description
This feature provides any user with the ability to conference together either two Central Office calls or a Central
Office and TIE Line call.
Operating Procedure
1. Place incoming caller on hold.
2. Receive special dial tone.
3. Dial the desired Central Office or TIE access code.
4. Receive second dial tone.
5. Dial the desired number; receive answer.
6....

NEAX2400 IPX Feature Programming ManualPage 762NDA-24297, Issue 1
T-10 Trunk-to-Trunk Connection
Programming (cont’d)
System Data 2, Index 1, Bits 0 & 1. CONSULTATION HOLD. Assign data“11”for
CONSULTATION HOLD service on Originating, Terminating, and Tandem calls.
System Data 2, Index 6, Bit 2. This Bit remains as data“0”. CALL TRANSFER-ALL CALLS [C-11].
System Data 2, Index 6, Bit 3. Enable add-on station. This Bit remains as data“0”for THREE-WAY
CALLING [T-2].
System Data 3, Index 2. Assign data 91H...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 763
Trunk-to-Trunk Connection T-10
FCCS Programming (cont’d)
STEP 2:ARRCN- Routes that will be allowed TRUNK-TO-TRUNK CONNECTION must be allowed here
for ARI-A-RES.
ICRT: Incoming Route Number
OGRT: Outgoing Route Number
ARI-A-RES: This allows/restricts trunk-to-trunk (tandem) connection via the Attendant Console
and stations.
ARI-D-RES: This allows/restricts trunk-to-trunk (tandem) connections via Direct Dial access from
a station and...

NEAX2400 IPX Feature Programming ManualPage 764NDA-24297, Issue 1
T-12 Tenant Service
T-12 Tenant Service
General Description
This feature provides for more than one organization (tenant) to share the same PBX. Through system programming,
each organization may be restricted to its own Central Office trunks, ATTENDANT CONSOLEs [A-3], and
extension links. In addition, incoming calls are directed to the specific organization (tenant).
Operating Procedure
No manual operation is required.
Service Conditions...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 765
Tenant Service T-12
Interactions (cont’d)
6. CLASS OF SERVICE-INDIVIDUAL [C-15]: Refer to the programming section. This feature affects the
construction of all classes of service.
Programming
STEP 1:ASYD- System Data 1, Index 8. Assign the number of tenants that the system will serve, in
hexadecimal format.
System Data 1, Indexes 92, 93, & 94. The Bits of these indexes allow for either common or separate
tenant assignments for other...

NEAX2400 IPX Feature Programming ManualPage 766NDA-24297, Issue 1
T-12 Tenant Service
Programming (cont’d)
2: Not used.
3: Allows the CALL FORWARDING-ALL CALLS, DON’T ANSWER, and
BUSY LINE on an intra and inter-tenant basis as when set by the Attendant
Console.
4: Allows or restricts incoming calls to the Attendant Console on a per-tenant
basis. Thus, an Attendant Console may handle calls only for a specific tenant.
5: Day/Night Mode Change Restriction is not used in North America.
6: Not Used.
7: Not...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 767
Time Display - DtermT-18D
T-18D  Time Display - Dterm
General Description
This feature provides a digital time display on a Dterm’sLCD.
Operating Procedure
No manual operation is required.
Service Conditions
1. The time is displayed according to the clock in the PBX and is set via the MAINTENANCE
ADMINISTRATION TERMINAL (MAT) [M-18].
2. Time is displayed automatically:
3. Time is constantly displayed on the center line of the LCD.
4. The...
