NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 768NDA-24297, Issue 1
T-23 Trunk Line Appearance
T-23  Trunk Line Appearance
General Description
ThisfeatureallowsaDtermuser to directly access a Central Office trunk or TIE Line without dialing an access code.
Incoming calls can also be answered at the TRUNK LINE APPEARANCE [T-23].
Operating Procedure
To access an outgoing trunk
1. Press the TRUNK LINE APPEARANCE line/feature key.
2. Lift the handset or press the SPEAKER key. Central Office or distant PBX dial...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 769
Trunk Line Appearance T-23
Interactions (cont’d)
4. TRUNK LINE APPEARANCE and HOTLINE-OUTSIDE [H-9] are mutually exclusive. Both features
require the AHLS command, and the same station cannot be provided with two Hotline features.
Programming
STEP 1:ASDT- Assign the station with the TRUNK LINE APPEARANCE as a virtual line (TEC = 18).
TN: Tenant Number
STN: Station Number
LENS: Line Equipment Number (6 digits)
TEC: Telephone Class (1-31)...

NEAX2400 IPX Feature Programming ManualPage 770NDA-24297, Issue 1
T-28 Trunk-to-Trunk Third-Party Cancellation
T-28  Trunk-to-Trunk Third-Party Cancellation
General Description
This feature allows a station to cancel an active trunk-to-trunk connection (during a three-way-connection) and
return to the original call.
Operating Procedure
If a station is presently engaged in a call with another station or with a trunk party
1. Switch hook flash; receive special dial tone.
2. Dial a trunk access code and the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 771
Trunk-to-Trunk Third-Party Cancellation T-28
Programming (cont’d)
System Data 3, Index 2, Bits 4-7. Switch hook flash ends timer. To calculate this value: (1 ~ FH) x 120
msec = Timer. For both beginning and ending timers, assign 91H for 120 - 1080 msec.
FCCS Programming
No unique programming is required for the FCCS network.
Note:System timers may be set on a network basis in ASYDN.
f (t) Bit 0-3 Bit 4-7
0 ms
No Detection120 ms 1080 ms...

NEAX2400 IPX Feature Programming ManualPage 772NDA-24297, Issue 1
T-62 Timed Reminder
T-62 Timed Reminder
General Description
This feature allows a user to set a Timed Reminder call from the station. The system calls up the station at the
designated time. When the station answers the call, the user hears a message or Music-On-Hold.
Operating Procedure
To set a Timed Reminder call
1. Lift a handset; receive dial tone.
2. Dial the Timed Reminder (SET) access code.
3. Designate your desired time by dialing...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 773
Timed Reminder T-62
Service Conditions (cont’d)
10. When the Timed Reminder cancel code is dialed, the user hears Service Set Tone or the announcement
even when the service is not set.
Programming
STEP 1:ASYD- System Data 1, Index 162, bits 6 and 7 tone type when a Timed Reminder call is answered.
b7
b6b7b6
0 0 = Music-On-Hold 0 1 = Announcement
Note:When Music-On-Hold is selected, STEPs 5 through 8 are not required.
System Data 1, Index...

NEAX2400 IPX Feature Programming ManualPage 774NDA-24297, Issue 1
T-63 Tone Block
T-63 Tone Block
General Description
This feature allows the user of a station (via analog adapter) or an analog station (PB) to restrict any call. This
prevents interruption of data transmission, before the connection.
Operating Procedure
To set the service
1. Lift the handset: receive the dial tone.
2. Dial the access code of“Data Privacy on Demand; Entry”.
3. Hear the special dial tone or the dial tone (depending on the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 775
Tone Block T-63
Programming
STEP 1:ANPD- Reserve a number level for feature access and cancel. Assign for Normal, (N) and Hooking
(H). Assign NND in accordance with a predetermined numbering plan.
STEP 2:ASPA- Assign the access code for Tone Block as shown below:
CI = H, SRV=SSCA, SIDA=48 (Data Privacy on Demand; Entry)
CI = H, SRV=SSCA, SIDA=49 (Data Privacy on Demand; Cancel)
CI = N, SRV=SSCA, SIDA=48 (Data Privacy on Demand; Entry)...

NEAX2400 IPX Feature Programming ManualPage 776NDA-24297, Issue 1
U-1 Uniform Call Distribution (UCD)
U-1  Uniform Call Distribution (UCD)
General Description
This feature distributes incoming calls to a UCD group of up to 100 stations. Calls are distributed to idle stations in
a circular pattern, in the order in which they arrive.
Operating Procedure
To transfer a call to a busy UCD group
1. All the stations in a UCD group are busy.
2. A user not in the group answers an incoming call (trunk or...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 777
Uniform Call Distribution (UCD) U-1
Service Conditions (cont’d)
11. Each UCD group has a controlling station. Only the controlling station or the Attendant can activate or
deactivate CALL FORWARDING-ALL CALLS [C-5] when the UCD group number is not a phantom
number.
12. If CALL FORWARDING-ALL CALLS [C-5] is set on a controlling station and the destination station is
idle, a call to the UCD group is transferred. If the designated station is...
