NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 778NDA-24297, Issue 1
U-1 Uniform Call Distribution (UCD)
Service Conditions (cont’d)
Example:
c.) UCD station peg count:
Count of incoming calls to each station in each group
Count of answered calls
Count of other calls (abandoned, restricted, blocked)
Example:
22. UCD Peg counts are available for calls transferred to the UCD group by the Attendant and for calls
transferred to the UCD group from a station.
23. The total numbers of incoming calls for which...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 779
Uniform Call Distribution (UCD) U-1
Service Conditions (cont’d)
31. The UCD group can be programmed to the Local Data Memory (LDM). The conditions are as shown
below.
a.) Only Telephone Number and PS Number can be used when programming UCD group to LDM.
b.)“UCD group assigned by ASHU command”,“UCD group assigned by ASHUL command”and
“UCD group assigned by ASHUN command”cannot be used together in the system. If assigning
different kind of...

NEAX2400 IPX Feature Programming ManualPage 780NDA-24297, Issue 1
U-1 Uniform Call Distribution (UCD)
Service Conditions (cont’d)
36. When activating this feature via the FCCS network, the maximum number of the UCD groups in a node
is 63.
37. When activating this feature via the FCCS network, the station assigned by using the Physical Station
Number and the station assigned by using the telephone number cannot be accommodated in the same
group and the same node.
38. When activating this feature via the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 781
Uniform Call Distribution (UCD) U-1
Service Conditions (cont’d)
b.) When stations belonging to different nodes are assigned to a UCD group, the station hunt is not
activated in assigned order if the stations are not assigned in continuous order within a node.
First, the call is shifted to the stations within the node of the UCD controlling station, even though
it is not in consecutive order (in the node, station hunt is activated in...

NEAX2400 IPX Feature Programming ManualPage 782NDA-24297, Issue 1
U-1 Uniform Call Distribution (UCD)
Service Conditions (cont’d)
c.) When the CCIS line is used as the alternative routing, SERVICE DISPLAY is not activated and
the hunting function is completed at the terminated station.
49. When using a Phantom Telephone Number (PHTELN) for a UCD controlling station via FCCS, consider
the following:
a.) Whether to use the PHTELN to start the UCD hunt or not can be selected by the command
APHNN. When using...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 783
Uniform Call Distribution (UCD) U-1
Interactions (cont’d)
13. The DND key functions in the same manner as the BUSY OUT key for UCD calls. However, while the
BUSY OUT key allows non-controlling UCD stations to receive calls dialed directly, use of the DND key
restricts all incoming calls.
14. If OVERFLOW-UCD [O-13] is in service, overflow will take place if all the stations in the first group are
busy or in the Busy Out state.
15. If the...

NEAX2400 IPX Feature Programming ManualPage 784NDA-24297, Issue 1
U-1 Uniform Call Distribution (UCD)
Programming (cont’d)
STEP 7:ADSL-AssignUCDBOkey;AssignSN=0(Idle),3(CalledStationBusy)andFKY=19(UCDBusy
Out).
This command is used for assigning a function to each soft key.
STEP 8:AT R F- Assign Traffic Measurement Order.
TYPE: Type of Traffic Measurement
INTERVAL: Output Interval must be assigned in units of ten minutes (range is from 30-120 minutes),
or data“0”must be assigned, which is the instruction...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 785
Universal Sender U-3
U-3 Universal Sender
General Description
This feature permits dialed numbers to be transmitted via a sender, a device that will automatically add or delete the
necessary number of digits or perform any necessary conversions.
Operating Procedure
No manual operation is required.
Service Conditions
1. For incoming connections, digits may be deleted according to the route involved. A maximum of 4 digits
may be added...

NEAX2400 IPX Feature Programming ManualPage 786NDA-24297, Issue 1
U-3 Universal Sender
Programming (cont’d)
STEP 2:MBTK- Assign the Make Idle status to the sender trunks.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 787
Variable Timing Parameters V-1
V-1  Variable Timing Parameters
General Description
The Variable Timing Parameters feature gives the PBX the versatility to change timing parameters, using the
MAINTENANCE ADMINISTRATION TERMINAL (MAT) [M-18]. All timing parameters for a specific timing
sequence are set initially within the generic program. These timing parameters can be changed to accommodate user
requirements.
Operating Procedure
No manual...
