NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 788NDA-24297, Issue 1
V-1 Variable Timing Parameters
Interactions
1. To calculate VARIABLE TIMING PARAMETERS, multiply the Timer Class by the Miscellaneous
Timer Class, TC x MTC = VARIABLE TIMING PARAMETER. TC is a set value. MTC is any value
from 1-15, assigned in hexadecimal. For the PERIODIC TIME INDICATION TONE Timer, a TC of 3
equaling 2 seconds is not available, but a TC of 4 equaling 30 seconds is available.
Timer Index:
TC values for Indexes 136, 147,...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 789
Variable Timing Parameters V-1
Interactions (cont’d)
TC values for Indexes 142, 143, 144
TC 0 = -
1=-
2=-
3 = 2 seconds
4 = 30 seconds
7 = 8 seconds.
TC values for Indexes 135
TC 0 = -
1=64msec.
TC values for Indexes 149
TC 0 = -
1=-
2=-
3 = 2 seconds
4 = 30 seconds.
TC values for Indexes 145
TC 0 = -
1 = 2 seconds.
Programming
ASYD- System Data 1. All VARIABLE TIMING PARAMETERS are located between Indexes 128
and 159, with the exception...

NEAX2400 IPX Feature Programming ManualPage 790NDA-24297, Issue 1
V-2 Voice Call
V-2 Voice Call
General Description
This feature enables a single line telephone to make a VOICE CALL [V-2] when the called party is a Dtermset. This
path exists from the calling party to the called partys built-in speaker. If the called partys MIC is on, the called party
can converse hands-free.
Operating Procedure
From a single line station to a Dterm
1. Dial the telephone number of the desired Dtermstation and receive...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 791
Voice Call V-2
Programming (cont’d)
For a Dterm
STEP 1:AKYD- Assign the station according to the following parameters:
TN: 1
STN: Station Number
TP: Type of D
term0/1:
RING:
0: No Ringing
1: Ringing All Lines
2: Ringing on Prime Line Only
3: Flexible Ring Assignment, enables RG parameter.
KYN: Key Number (1-40)
KYI: Service Index
0: Key Not Used
1: Feature Key
2: Multi-line Key
KD: Not assigned for Feature Key
FKY: Feature Key Number
FKY...

NEAX2400 IPX Feature Programming ManualPage 792NDA-24297, Issue 1
V-2D Voice Call - Dterm
V-2D  Voice Call - Dterm
General Description
This feature provides a voice path between two Dtermsets. This path exits from the calling party to the called party’s
built-in speaker. If the called party’s MIC key is on, the called party can converse hands-free.
Operating Procedure
From one Dterm to another Dterm
1. The originating Dtermuser dials the desired telephone number and receives a ringback tone.
2. The...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 793
Voice Call - DtermV-2D
Interactions
A Voice Call cannot be sent to a single-line station.
Programming
Operating with the feature key
STEP 1:AKYD- Assign the station according to the following parameters:
TN: 1
STN: Station Number
TP: Type of D
term0/1:
RING:
0: No Ringing
1: Ringing All Lines
2: Ringing on Prime Line Only
3: Flexible Ring Assignment, enables RG parameter.
KYN: Key Number (1-40)
KYI: Service Index
0: Key Not Used
1:...

NEAX2400 IPX Feature Programming ManualPage 794NDA-24297, Issue 1
V-3D Volume Control - Dterm
V-3D  Volume Control - Dterm
General Description
This feature is used for controlling the volume of a Dtermset’s built-in speaker and receiver.
Operating Procedure
1. The Dtermset is equipped with a sliding volume control knob located in the front, beneath the dial pad.
Volume can be increased by moving the control to the right, and decreased by moving it to the left.
2. The ringing volume is controlled by a...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 795
WATS Access W-1
W-1 WATS Access
General Description
This feature permits any user direct-dial access to outgoing WATS lines.
Operating Procedure
1. Lift the handset; receive dial tone.
2. Dial the WATS ACCESS code.
3. Receive second dial tone.
4. Dial the desired number.
Service Conditions
Access to WATS lines may be denied to individual stations via CLASS OF SERVICE-INDIVIDUAL [C-15].
Interactions
1. WATS ACCESS will operate in...

NEAX2400 IPX Feature Programming ManualPage 796NDA-24297, Issue 1
W-1 WATS Access
Programming (cont’d)
STEP 5:ASPA- Assign the access code as assigned in ANPD above. Type of Service, SRV = OGC (Outgoing
Call) Outgoing Trunk. Assign the route number associated with this access code.
STEP 6:ARSC- The Route Restriction Class must be constructed to allow the station access to the involved
routes.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 797
Networking with NEAX2400 IPX and NEAX2000 IVS2
Networking with NEAX2400 IPX and NEAX2000 IVS2
General Description
The following explains connectivity issues between a NEAX2400 IPX and a NEAX2000IVS2. An FCCS Group
consists of a network where multiple NEAX2400 IPXs are connected via FCCS link.
Note:NEAX2400 IPX - NEAX2000 IVS2connection is available only if the NEAX2000 IVS2is the satellite office
(requires NEAX2000 IVS2Series 2000 or...
