NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 888NDA-24297, Issue 1
D-67 Data Line Privacy - CCIS
D-67  Data Line Privacy - CCIS
General Description
This feature automatically prevents interruptions from features such as ATTENDANT CAMP-ON WITH TONE
INDICATION - CCIS [A-45], BUSY VERIFICATION - CCIS [B-9], and EXECUTIVE RIGHT-OF-WAY - CCIS
[E-8] during data transmission through the CCIS network.
Operating Procedure
Data Connection (Dterm- Data Adapter/Data Module): No manual operation is required. When a...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 889
Data Privacy on Demand - CCIS D-68
D-68  Data Privacy on Demand - CCIS
General Description
This feature allows a station user to prevent interruptions by features such as ATTENDANT CAMP-ON - CCIS [A-
45], BUSY VERIFICATION - CCIS [B-9], and EXECUTIVE RIGHT-OF-WAY - CCIS [E-8] during data
transmission through the CCIS network by dialing a DATA PRIVACY feature code.
Operating Procedure
To activate DATA PRIVACY ON DEMAND from a single-line...

NEAX2400 IPX Feature Programming ManualPage 890NDA-24297, Issue 1
D-68 Data Privacy on Demand - CCIS
Programming
STEP 1:ANPD- Reserve a number level for feature access and cancel. Assign for Normal (N), Hooking (H)
and Busy (B). Assign NND in accordance with a predetermined numbering plan.
STEP 2:ASPA- Assign an access code to DATA PRIVACY ON DEMAND, SRV = SSCA (Service Code
Appendix), SIDA = 48, DATA PRIVACY cancel, with a Connection Status Index (CI) of Hooking
(H).

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 891
Data Transparency - CCIS D-69
D-69  Data Transparency - CCIS
General Description
This feature provides a DATA TRANSPARENCY path between nodes within the CCIS network for data
transmission using a Data Module or Dterm/ Data Adapter.
Operating Procedure
No manual operation is required.
Service Conditions
1. Upon data call origination or termination using a Data Module equipped DTE, certain character string
sequences relating to status are...

NEAX2400 IPX Feature Programming ManualPage 892NDA-24297, Issue 1
D-70 Deluxe Traveling Class Mark - CCIS
D-70  Deluxe Traveling Class Mark - CCIS
General Description
This feature provides call connection restrictions within the CCIS network. The following three types of restrictions
are allowed:
Deluxe Traveling Class Mark Restriction
Route Restriction
Numbering Restriction
Operating Procedure
Refer to the NEAX2400 IPX Office Data Specification.
Service Conditions
1. The Route Restriction Class...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 893
Dial Access to Attendant - CCIS D-71
D-71  Dial Access to Attendant - CCIS
General Description
This feature allows a user to access an Attendant Console through the CCIS network by dialing an Operator Call
Code.
Operating Procedure
To access an Attendant Console
1. Dial the Operator Call Code; receive ringback tone.
2. The ATND lamp on the Attendant Console flashes for INCOMING CALL IDENTIFICATION - CCIS.
3. The Attendant answers the...

NEAX2400 IPX Feature Programming ManualPage 894NDA-24297, Issue 1
D-71 Dial Access to Attendant - CCIS
Programming (cont’d)
STEP 3:AT N R- Allow tenant-to-tenant connection for Inter- and Intra-tenant connections. TRI=0 and TRI=4.

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 895
Digital Display - Station - CCIS D-72
D-72  Digital Display - Station - CCIS
General Description
This feature provides the Attendant Console with a visual display of the telephone number, the Trunk Route
Restriction CLASS OF SERVICE [C-15], and tenant number during Attendant-to-Station connection within the
CCIS network.
Operating Procedure
The DIGITAL DISPLAY is automatically activated whenever the Attendant Console answers an incoming...

NEAX2400 IPX Feature Programming ManualPage 896NDA-24297, Issue 1
D-72 Digital Display - Station - CCIS
Service Conditions (cont’d)
Example 3:When five-digit station numbering is used, only the station number is displayed:
Note:When the telephone number exceeds 6 digits, last 6 digits are displayed.
Interactions
1. CALL FORWARDING - CCIS [C-45, 46, 47]: Calls are forwarded from Station A to Station B. When the
Attendant extends a call to Station A, Station B’s number is indicated on the DIGITAL DISPLAY-...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 897
Digital Display - Trunk - CCIS D-73
D-73  Digital Display - Trunk - CCIS
General Description
This feature provides a visual indication at the Attendant Console of incoming and outgoing trunk calls through the
CCIS network. Trunk Identification number, Trunk Route number, and tenant number or Central Office trunk code,
are displayed on a six-digit digital display.
Operating Procedure
The digital display is automatically activated whenever...
