NEAX2400 IPX Feature Programming ManualPage 878NDA-24297, Issue 1
C-163 CCIS Networking via IP
Service Conditions (cont’d)
10. The table below shows CCIS service features to be provided beyond the nodes:
11. This feature does not support Broad Band Services H0/H1.
12. This feature can use Link Re-connection function. At this time, service conditions are the same as those
for the normal CCIS network.
13. PAD can be provided for“receive”control only.
14. IPTRK-related tandem connection is not provided....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 879
CCIS Networking via IP C-163
Programming
STEP 1:Referring to the NEAX2400 IPX No. 7 CCIS System Manual, assign the entire basic data (such as
ASYD, ARTD, ATRK, ADPC, ACSC, ACIC1, ACIC2, MBTK, etc.) necessary for the establishment
of a CCIS Tie Line.
Enter IPTRK = 1 for both D-channel and B-channel routes on the ARTI command.
For the port assignment (B-ch) of the IPTRK card, see the IPTRK Circuit Card System Manual.
The CCIS signal...

NEAX2400 IPX Feature Programming ManualPage 880NDA-24297, Issue 1
C-167 Centralized Maintenance - CCIS
C-167  Centralized Maintenance - CCIS
General Description
This FCCS service allows all nodes (NEAX2400 IPX systems) in the multiple FCCS groups (networks where
multiple NEAX2400 IPXs are connected via FCCS link) and NEAX2000 IVS2systems, connected via CCIS link,
to be maintained from a single MAT. The MAT used for this feature is called Centralized MAT.
Note:Requires NEAX2000 IVS2Series 2000 or later...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 881
Centralized Maintenance - CCIS C-167
FCCS Programming
This data setting describes only the additional or replacement commands used to activate FCCS
services. When used as an FCCS feature, these commands replace the non-network commands (for
example, AAED is replaced by AAEDN). Note that the data setting for FCCS service varies depending
on the node.
Assign the following data at the NCN in each FCCS group (FUG)
STEP 1:AFUGN- Assign the...

NEAX2400 IPX Feature Programming ManualPage 882NDA-24297, Issue 1
C-167 Centralized Maintenance - CCIS
FCCS Programming (cont’d)
To connect FUG and a NEAX2000 IVS2(refer to the manuals for the NEAX2000 IVS2for data
programming on the NEAX2000 IVS2side):
To connect a NEAX2400 IPX and a NEAX2400 IPX (NEAX2400 IPX stands for the FCCS node
working alone in an FCCS network):
Center FUGFPC 1
PC 1
FUG 1
FPC 3
PC 3
NCN
FPC 2
PC 2CCIS
-
-
- -
-
- -
-
--
-
-
NEAX2000
IVS2
Center FUGFPC 1
NCN
PC 4
FPC 4 PC 1...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 883
Data Communication - CCIS D-41
D-41  Data Communication - CCIS
General Description
This service allows Inter-Office data communication service where the Digital Interface (DTI) is used as the CCIS
Line over a T1 channel (Digital Link Channel).
With this service, the data communication line between synchronous and asynchronous terminals can be directly
connected to the DTI without using the MODEM Pooling or a DST card.
Operating Procedure...

NEAX2400 IPX Feature Programming ManualPage 884NDA-24297, Issue 1
D-41 Data Communication - CCIS
Operating Procedure (cont’d)
When cancelling the data connection
1. Press the DATA key on Dterm(a); the LCD of Dterm(a) restores the display of Time and Date.
Note:If the opposite DTE is released, the buzzer on the Data Module/Data Adapter sounds three times.
Enter Release command RLS RETURN from the keyboard of the DTE. RLS and RELEASED are displayed
on the monitor screen. The data connection has been...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 885
Data Interface - Automatic Answer - CCIS D-65
D-65  Data Interface - Automatic Answer - CCIS
General Description
This feature allows a data terminal to automatically answer an incoming CCIS call without manual operation,
therefore, providing the capability of receiving electronic mail.
Operating Procedure
AUTOMATIC ANSWER for terminating data calls, Automatic Answer Mode can be set by the following
methods
1. Set the Data Module DIP...

NEAX2400 IPX Feature Programming ManualPage 886NDA-24297, Issue 1
D-65 Data Interface - Automatic Answer - CCIS
Programming (cont’d)
KYI: Service Index
0: Key Not Used
1: Feature Key
2: Multi-line Key
KD: Not assigned for Feature Key
FKY: Feature Key Number
FKY = 30, AUTOMATIC ANSWER

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 887
Data Line Security - CCIS D-66
D-66  Data Line Security - CCIS
General Description
This feature allows line circuits used for data transmission to be protected from interruptions, such as,
ATTENDANT CAMP-ON WITH TONE INDICATION - CCIS [A-45], BUSY VERIFICATION - CCIS [B-9],
EXECUTIVE RIGHT-OF-WAY - CCIS [E-8], and ATTENDANT OVERRIDE [A-7].
Operating Procedure
No manual operation is required.
Service Conditions
1. If an Attendant or user...
