NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 808NDA-24297, Issue 1
A-71 Automatic Recall - CCIS
A-71  Automatic Recall - CCIS
General Description
This service feature works as a time reminder. When an attendant-handled call through CCIS remains on hold,
camped-on or ringing unanswered for a fixed interval, the attendant is automatically alerted.
Operating Procedure
No manual operation is required.
Service Conditions
1. AUTOMATIC RECALL timing is preset in system data at 30 seconds. See the VARIABLE...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 809
Automatic Recall - CCIS A-71
Interactions (cont’d)
5. The station will continue to ring, even as the call recalls to the Attendant Console. When conference is
allowed and a conference card is programmed and installed, if the station should answer at the same time
the Attendant answers the recalling call, a three-way conversation will then take place. The Attendant can
press the SRC, DEST, or TALK keys to achieve the desired conversation,...

NEAX2400 IPX Feature Programming ManualPage 810NDA-24297, Issue 1
A-87 Automatic Number Identification (ANI) - CCIS
A-87  Automatic Number Identification (ANI) - CCIS
General Description
This service is an enhancement from AUTOMATIC NUMBER IDENTIFICATION (ANI), which can be executed
only within the self office. This enhanced service allows ANI at the primary office, with respect to an
EMERGENCY CALL terminated from the secondary office via the CCIS line.
Operating Procedure
No manual operation is...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 811
Automatic Number Identification (ANI) - CCIS A-87
Service Conditions (cont’d)
If OG call is from an ATTCON and Individual ATT Access Code is assigned, and also ANI
data is assigned:
KP - 0
- N**-****-ST
If OG call is from an ATTCON and Individual ATT Access Code is unassigned, and ANI data
is assigned:
KP - 0
- N**-****-ST
If OG call is from an ATTCON and ANI data is unassigned:
KP - 1
-ST
b.) Outgoing call from station/Attendant of...

NEAX2400 IPX Feature Programming ManualPage 812NDA-24297, Issue 1
A-87 Automatic Number Identification (ANI) - CCIS
Service Conditions (cont’d)
Station number: 2xxx, 3xxx
The COC digits are 822 or 823; then assign ANI information.
Example 2:
Office number: 82, 826
Station number: 34xxx, 4xxx
The COC digits are 823 or 826; then assign ANI information.
10. After digits have been sent out, DDD seizure tone is not sent.
11. Other interactions are the same as those of outgoing call by MF signalling.
12. An...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 813
ANI-CCIS (16 Digit) A-126
A-126  ANI-CCIS (16 Digit)
General Description
This feature allows an office receiving ANI information from Central Office through an analog trunk (Caller ID or
MF) to extend to another office through CCIS when the tandem connection is established.
Operating Procedure
No manual operation is required.
Service Conditions
1. The maximum digits of ANI information sent to another office through CCIS are 16.
2. When...

NEAX2400 IPX Feature Programming ManualPage 814NDA-24297, Issue 1
A-126 ANI-CCIS (16 Digit)
Programming (cont’d)
System Data 1, Index 290, Bit 5. Expanded SMDR Output for SMDR B Apparatus. 0/1 = Out/In
Service.
System Data 1, Index 292, Bit 5. Expanded SMDR Output for SMDR C Apparatus. 0/1 = Out/In
Service.
System Data 1, Index 294, Bit 5. Expanded SMDR Output for SMDR D Apparatus. 0/1 = Out/In
Service.
System Data 1, Index 296, Bit 0. Output of Calling Number (ANI Information). 0/1 = Out/In Service....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 815
Busy Verification - CCIS B-9
B-9  Busy Verification - CCIS
General Description
This service feature allows Inter-Office Attendant BUSY VERIFICATION when the Attendant and the called party
respectively belong to a different PBX in the CCIS network.
Operating Procedure
1. Station (a) and (b) are in connection on a station-to-station call.
2. The Attendant in Node A presses the loop key; the loop lamp and DEST lamp on the Attendant Console...

NEAX2400 IPX Feature Programming ManualPage 816NDA-24297, Issue 1
B-9 Busy Verification - CCIS
Service Conditions (cont’d)
3. In a 3-way call in the mode where the conference button is pressed, the Attendant cannot perform BUSY
VERIFICATION.
4. BUSY VERIFICATION cannot be established to a BUSY station when the station is:
a.) Dialing
b.) Listening to a tone
c.) Being rung
d.) Protected by DATA LINE SECURITY [D-12] [D-66]
e.) Being connected to an BUSY VERIFICATION Loop
f.) Activating a conflicting...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 817
Busy Verification - CCIS B-9
Interactions (cont’d)
3. Trunks in a station-to-trunk, TRUNK-TO-TRUNK CONNECTION [T-10], and ATTENDANT-
CONTROLLED CONFERENCE [A-2] connection may be verified when busy.
4. ATTENDANT LOCKOUT [A-5]: The Attendant is prevented from verifying a busy station line that is
connected to a loop held at the Attendant Console. Since the LOCKOUT feature applies only to calls held
on an Attendant Console loop, BUSY...
