NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 818NDA-24297, Issue 1
B-9 Busy Verification - CCIS
Programming (cont’d)
System Data 2, Index 0, Bit 4. On a per-tenant basis, assign data“1”to enable BUSY
VERIFICATION.
STEP 2:ASFC- For stations that permit BUSY VERIFICATION, assign a Class of Service that allows SFI 4,
EXECUTIVE RIGHT-OF-WAY [E-1] and SFI 11, ATTENDANT CAMP-ON WITH TONE
INDICATION [A-45]. SFI: 3 must be allowed for the attendant’s Service Feature Class (normally
SFC: 0) at all locations...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 819
Brokerage Hotline - CCIS B-10
B-10  Brokerage Hotline - CCIS
General Description
This feature provides a hotline function between two stations at different nodes in the CCIS network, using a line/
feature key of a Dterm.
Operating Procedure
To access from a Dterm
1. Lift the handset or press the SPEAKER button.
2. Press the line/feature key associated with a predetermined station in another office. The destination station
is...

NEAX2400 IPX Feature Programming ManualPage 820NDA-24297, Issue 1
B-10 Brokerage Hotline - CCIS
Service Conditions (cont’d)
12. If the destination station is busy and is a pilot member of a UCD group, the UCD function will be activated.
If all stations in the UCD group are busy, ringback tone will be heard, or if programmed, DELAY
ANNOUNCEMENT-UCD [D-31] or OVERFLOW-UCD [O-13] will be invoked.
13. CALL FORWARDING-ALL CALLS [C-5] [C-45], CALL FORWARDING-BUSY LINE [C-2] [C-46],
and CALL FORWARDING-DON’T...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 821
Brokerage Hotline - CCIS B-10
Programming (cont’d)
KYN: Key Number (1-16)
KYI: Service Index
0: Key Not Used
1: Feature Key
2: Multi-line Key
KD: 0
RG: Ringing Assignment per Multi-line Appearance
0: No Ringing.
1: Ringing in Day Mode Only.
2: Ringing in Night Mode Only.
3: Ringing Day and Night.
STEP 4:ASPD- Assign the tenant Abbreviated Digit Code (ADC), and Digit Code (DC).
STEP 5:ASFC- Primary station and Hotline must be allowed...

NEAX2400 IPX Feature Programming ManualPage 822NDA-24297, Issue 1
C-44 Call Back - CCIS
C-44  Call Back - CCIS
General Description
This service feature allows an Inter-office Call Back when the calling station and the called station respectively
belong to a different PBX in the CCIS network.
Operating Procedure
To set from a Single-Line Telephone
1. Dial the desired telephone number; receive busy tone.
2. Switch hook flash; receive special dial tone.
3. Dial the CALL BACK - CCIS code; receive service...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 823
Call Back - CCIS C-44
Operating Procedure (cont’d)
3. The LCD will display:
Service Conditions
1. If CALL BACK is not answered within 30 seconds, or the timer interval in ASYD index 139, ringing will
stop and the CALL BACK will automatically be cancelled.
2. CALL BACK to a busy station cannot be established if the station is in the LINE LOCKOUT [L-3] mode.
3. There is no time limit for CALL BACK once activated. It will remain in status...

NEAX2400 IPX Feature Programming ManualPage 824NDA-24297, Issue 1
C-44 Call Back - CCIS
Interactions
1. OUTGOING TRUNK QUEUING [O-2] and CALL BACK - CCIS cannot be accessed simultaneously.
2. System Data 1, Index 139. No Answer Timer is also used for station-to-station call, DID, or TIE Line call
for CALL FORWARDING-DON’T ANSWER [C-47] and CALL HOLD [C-6].
3. CALL WAITING-ORIGINATE [C-31] automatic setting and CALL BACK - CCIS are mutually
exclusive.
4. CALL BACK - CCIS cannot be activated toward the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 825
Call Forwarding - All Calls - CCIS C-45
C-45  Call Forwarding - All Calls - CCIS
General Description
This service feature allows Inter-Office CALL FORWARDING-ALL CALLS when the transferring station and the
transferred station, respectively, belong to a different PBX in the CCIS network.
Operating Procedure
When setting Call Forwarding-All Calls Service
1. Station A goes off-hook; receives dial tone.
2. Station A dials the Access Code for...

NEAX2400 IPX Feature Programming ManualPage 826NDA-24297, Issue 1
C-45 Call Forwarding - All Calls - CCIS
Operating Procedure (cont’d)
5. Station A is called from Station C. The call is automatically transferred to Station B, which Station A has
designated as the call destination. Station C receives ringback tone; Station B is rung.
6. Station B answers; Stations B and C are connected with each other.
When cancelling Call Forwarding-All Calls Service
1. Station A goes off-hook; receives dial tone.
2....

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 827
Call Forwarding - All Calls - CCIS C-45
Service Conditions
1. Stations with this feature set may originate calls and access the CALL FORWARDING-ALL CALLS
Cancel Code.
2. There is no limitation to the number of stations which can set CALL FORWARDING-ALL CALLS
simultaneously.
3. When a call is directed to a FORWARDED station, a one-burst ringing signal will be sent to the station to
indicate that it is CALL FORWARDED.
4. Stations activating...
