NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 828NDA-24297, Issue 1
C-45 Call Forwarding - All Calls - CCIS
Service Conditions (cont’d)
b.) Station A calls Station B. Station B is set to CALL FORWARDING-ALL CALLS - CCIS to
Station C. Station C is set to CALL FORWARDING-ALL CALLS - CCIS to Station D. CALL
FORWARDING-ALL CALLS - CCIS does not occur to Station D. If Station C is idle, Station C
will ring.
c.) A Central Office call is directed to Station B. Station B is set to CALL FORWARDING-ALL
CALLS - CCIS...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 829
Call Forwarding - All Calls - CCIS C-45
Service Conditions (cont’d)
d.) A Central Office call is directed to Station B. Station B is set to CALL FORWARDING-ALL
CALLS - CCIS to Station C. Station C is set to CALL FORWARDING-ALL CALLS - CCIS to
Station D. CALL FORWARDING-ALL CALLS - CCIS does not occur to Station D. If Station C
is idle, Station C will ring.
8. CALL FORWARDING-ALL CALLS - CCIS can be set or cancelled by a user or an...

NEAX2400 IPX Feature Programming ManualPage 830NDA-24297, Issue 1
C-45 Call Forwarding - All Calls - CCIS
Service Conditions (cont’d)
17. When OUTGOING TRUNK QUEUING - CCIS [O-12] is provided, the forwarding station can use one
of the call forwarding features and OUTGOING TRUNK QUEUING - CCIS [O-12] at the same time.
Ringback tone is sent to the forwarding station and not to the forwarded-to station.
18. A call forwarded to a busy station that is allowed CALL WAITING [C-12] waits at the forwarded-to...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 831
Call Forwarding - All Calls - CCIS C-45
Programming
STEP 1:ASYD- System Data 1, Index 4, Bit 6. One burst of ringing at forwarding station when CALL
FORWARDING-ALL CALLS - CCIS is in service? 0/1: No/Yes.
System Data 1, Index 69, Bit 1. A burst of ringback tone to alert the person receiving a call that this is
a CALL FORWARDING-ALL CALLS - CCIS call. In service? 0/1: No/Yes. Normally assigned as
data“0”.
System Data 2, Index 6, Bit 4....

NEAX2400 IPX Feature Programming ManualPage 832NDA-24297, Issue 1
C-46 Call Forwarding - Busy Line - CCIS
C-46  Call Forwarding - Busy Line - CCIS
General Description
This service feature allows Inter-Office Call Forwarding-Busy Line for a case where the transferring station and the
transferred station respectively belong to a different PBX in the CCIS network.
Operating Procedure
When setting call Forwarding-Busy Line Service
1. Station A goes off-hook; receives dial tone.
2. Station A dials the Access...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 833
Call Forwarding - Busy Line - CCIS C-46
Operating Procedure (cont’d)
6. Station A is called from Station D through a CCIS line. The call is automatically transferred to Station B
which Station A has designated as the call destination. Station D receives ringback tone; Station B is rung.
7. When Station B answers, Stations B and D are connected with each other.
When cancelling CALL FORWARDING-BUSY LINE service
1. Station A goes off-hook;...

NEAX2400 IPX Feature Programming ManualPage 834NDA-24297, Issue 1
C-46 Call Forwarding - Busy Line - CCIS
Operating Procedure (cont’d)
2. Station A dials the Cancel Code of CALL FORWARDING-BUSY LINE; receives service set tone.
Service Conditions
1. When CALL FORWARDING-BUSY LINE - CCIS is used, the following conditions exist:
a.) Station A calls station B. Station B is call forwarded to Station C. Station C is call forwarded to
Station D. Call forwarding does occur to Station D. CALL BACK - CCIS [C-44],...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 835
Call Forwarding - Busy Line - CCIS C-46
Service Conditions (cont’d)
b.) Station A calls station B. Station B is call forwarded - CCIS to Station C. Station C is call
forwarded - CCIS to Station D. Call forwarding does not occur to Station D. If Station C is idle,
Station C will ring. If Station C is busy, busy tone is returned from Station C. CALL BACK -
CCIS [C-44], CALL WAITING-TERMINATING [C-12], or EXECUTIVE RIGHT-OF-WAY -
CCIS [E-8]...

NEAX2400 IPX Feature Programming ManualPage 836NDA-24297, Issue 1
C-46 Call Forwarding - Busy Line - CCIS
Service Conditions (cont’d)
d.) A Central Office call is directed to Station B. Station B is call forwarded to Station C. Station C is
call forwarded - CCIS to Station D. Call forwarding does not occur to Station D. If Station C is
idle, Station C will ring. If Station C is busy, busy tone is returned from Station C.
2. Registration memories for CALL FORWARDING-BUSY LINE and CALL FORWARDING-DON’T...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 837
Call Forwarding - Busy Line - CCIS C-46
Service Conditions (cont’d)
13. CALL FORWARDING-BUSY LINE - CCIS can be set by any number of stations to the same forwarded-
to station.
14. The display of the forwarded-to telephone number on the LCD panel of the forwarding D
termcan be
allowed or denied in system programming on a system-wide basis.
15. When calls are forwarded to the Attendant Console, INCOMING CALL IDENTIFICATION [I-2] allows
the...
