NEAX2400 IPX Feature Programming ManualPage 838NDA-24297, Issue 1
C-46 Call Forwarding - Busy Line - CCIS
Service Conditions (cont’d)
30. SPLIT CALL FORWARDING [S-99] is available only when the calling party is the station or the CCIS
line.
31. When a call terminates to a busy station setting CALL FORWARDING-BUSY LINE - CCIS, depending
on the calling station service restriction class, it can be selected to make the station busy (not to activate
Calling Forwarding-Busy Line) and to activate services as...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 839
Call Forwarding - Busy Line - CCIS C-46
Programming (cont’d)
STEP 3:ASPA- Assign an access code to CALL FORWARDING-BUSY LINE - CCIS entry, SID = 10 and to
CALL FORWARDING-BUSY LINE - CCIS cancel SID = 11. Assign Connection Status Index (CI)
for Normal (N) service.
STEP 4:ASFC- Assign a Service Feature Class that allows SFI = 9 to the stations receiving CALL
FORWARDING-BUSY LINE - CCIS.
STEP 5:AKYD-ForD
termsets, CALL FORWARDING-BUSY LINE...

NEAX2400 IPX Feature Programming ManualPage 840NDA-24297, Issue 1
C-47 Call Forwarding - Don’t Answer - CCIS
C-47  Call Forwarding - Don’t Answer - CCIS
General Description
This service feature allows Inter-Office Call Forwarding-Don’t Answer for a case where the transferring station and
the transferred station respectively belong to a different PBX in the CCIS network.
Operating Procedure
When setting
1. Station A goes off-hook; receives dial tone.
2. Station A dials the Access Code for CALL...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 841
Call Forwarding - Don’t Answer - CCIS C-47
Operating Procedure (cont’d)
5. Station A is called from Station C; Station C receives ringback tone; Station A is rung.
6. Station A does not answer the call within a predetermined amount of time. The ringing at Station A stops
and the call is automatically transferred to Station B, which A has designated as the transfer destination;
Station B is rung.
7. Station B answers the call; Stations B...

NEAX2400 IPX Feature Programming ManualPage 842NDA-24297, Issue 1
C-47 Call Forwarding - Don’t Answer - CCIS
Operating Procedure (cont’d)
When cancelling
1. Station A goes off-hook; receives dial tone.
2. Station A dials the Cancel Code of CALL FORWARDING-DON’T ANSWER; receives service set tone.
3. Station A hangs up.
Service Conditions
1. When CALL FORWARDING-DON’T ANSWER - CCIS is used, the following conditions exist:
a.) Station A calls Station B. Station B is call forwarded to Station C. Station C is...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 843
Call Forwarding - Don’t Answer - CCIS C-47
Service Conditions (cont’d)
b.) Station A calls Station B. Station B is call forwarded to Station C. Station C is call forwarded to
Station D. Call forwarding does not occur to Station D. If Station C is idle, it will ring beyond the
Don’tAnswertimer.
c.) A Central Office call is directed to Station B. Station B is call forwarded to Station C. Station C is
call forwarded to Station D. Call...

NEAX2400 IPX Feature Programming ManualPage 844NDA-24297, Issue 1
C-47 Call Forwarding - Don’t Answer - CCIS
Service Conditions (cont’d)
d.) A Central Office call is directed to Station B. Station B is call forwarded to Station C. Station C is
call forwarded to Station D. Call forwarding does not occur to Station D. If Station C is idle,
Station C will ring beyond the Don’t Answer timer.
2. CALL FORWARDING-DON’T ANSWER can be provided on either a system or an individual basis.
3. Individual CALL...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 845
Call Forwarding - Don’t Answer - CCIS C-47
Service Conditions (cont’d)
14. When an Attendant extends a call to a station in another node in the CCIS network, and that station has
set CALL FORWARDING-DON’T ANSWER - CCIS, the call will be forwarded if the called station does
not answer within a predetermined time period.
15. If separate access codes are programmed into system data for CALL FORWARDING-DON’T ANSWER
- CCIS and CALL...

NEAX2400 IPX Feature Programming ManualPage 846NDA-24297, Issue 1
C-47 Call Forwarding - Don’t Answer - CCIS
Programming
STEP 1:ASYD- System Data 1, Index 5, Bit 0. Access codes for CALL FORWARDING-BUSY LINE - CCIS
and CALL FORWARDING-DON’T ANSWER - CCIS are same or separate? 0/1: Same/Separate.
System Data 1, Index 69, Bit 2. Is there a short tone to alert person receiving the call that this is a
CALL FORWARDING-DON’T ANSWER - CCIS call? 0/1: No/Yes.
System Data 1, Index 139. Assign the No Answer time...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 847
Call Forwarding - Intercept - CCIS C-48
C-48  Call Forwarding - Intercept - CCIS
General Description
This feature allows calls to an inoperative number, through a CCIS trunk, to be intercepted and routed to a recorded
announcement. This announcement will inform the caller that an inoperative number was dialed and will give the
Listed Directory Number for information.
Operating Procedure
This feature is set in system programming and no...
