NEAX2400 IPX Feature Programming ManualPage 848NDA-24297, Issue 1
C-48 Call Forwarding - Intercept - CCIS
Programming (cont’d)
STEP 3:MBTK- Assign the Make Idle status to the Announcement Trunk.
Note:If supervision is required, use the first two circuits of the COT card. Move the switch on the COT card to
PGT.
STEP 4:ARRC- If TIE Line or REMOTE ACCESS TO PBX [R-2] connection to the Announcement Service
Trunk is required, allow trunk-to-trunk connection using ARI-D-RES, Direct Connection.
STEP 5:AAED-...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 849
Call Forwarding - Intercept - CCIS C-48
Programming (cont’d)
STEP 7:ARSC- Assign RSC 0 for the Attendant. Allow stations to access the announcement trunks.

NEAX2400 IPX Feature Programming ManualPage 850NDA-24297, Issue 1
C-49 Call Forwarding - Override - CCIS
C-49  Call Forwarding - Override - CCIS
General Description
This feature allows a forwarded-to station (Station A) to ring the station (Station B), which has set CALL
FORWARDING - ALL CALLS - CCIS [C-45] to it. If the called station (Station B) has set CALL FORWARDING
- BUSY LINE - CCIS [C-46] to the calling station (Station A), the calling station will receive busy tone and can
activate CALL BACK -...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 851
Call Transfer - All Calls - CCIS C-50
C-50  Call Transfer - All Calls - CCIS
General Description
This service feature allows Inter-Office CALL TRANSFER-ALL CALLS when the transferring station and the
transferred station respectively belong to a different PBX in the CCIS network.
Operating Procedure
1. Station A and C are in connection on a station-to-station call.
2. Station A switch hook flashes; receives special dial tone. Station C...

NEAX2400 IPX Feature Programming ManualPage 852NDA-24297, Issue 1
C-50 Call Transfer - All Calls - CCIS
Operating Procedure (cont’d)
3. Station A dials the number for B; receives ringback tone. Station B is rung. Note 1
Note 1:
The status of Station A can be restored to normal with a switch hook flash in one of the following cases:
When Station A has received busy tone.
When Station B is under a call restriction or when Station A cannot access Station B for some other reasons.
When Station B does not...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 853
Call Transfer - All Calls - CCIS C-50
Operating Procedure (cont’d)
5. Station A hangs upNote 3; Stations B and C are connected with each other.
Note 3:If Station A switch hook flashes instead of hanging up, a three-way connection is set up.
Service Conditions
1. When TRUNK-TO-TRUNK CONNECTION [T-10] is provided, an incoming or outgoing network or TIE
Line call may be transferred to an outgoing network trunk, provided that the trunk is...

NEAX2400 IPX Feature Programming ManualPage 854NDA-24297, Issue 1
C-50 Call Transfer - All Calls - CCIS
Service Conditions (cont’d)
2. The THREE-WAY CALLING [T-2] feature allows a maximum of three parties on one connection. The
three parties can be:
Three stations,
Two stations and one trunk, or
One station and two trunks.
3. The maximum number of simultaneous THREE-WAY CALLING [T-2] connections is dependent upon
the quantity of conference trunks (Route 909s) programmed in the system.
4. Reorder tone...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 855
Call Transfer - All Calls - CCIS C-50
Interactions (cont’d)
4. Upon establishing a CONSULTATION HOLD [C-58] connection and dialing a third party, if the user
receives busy or reorder tone instead of ringback tone, the user flashes once to disconnect the tone and
reconnect the second party.
5. Upon establishing a CONSULTATION HOLD [C-58] connection and dialing a MISCELLANEOUS
TRUNK ACCESS [M-2] code, if no dial tone is given (after the...

NEAX2400 IPX Feature Programming ManualPage 856NDA-24297, Issue 1
C-51 Called Station Status Display - CCIS
C-51  Called Station Status Display - CCIS
General Description
This feature provides for the status of a called station to appear on the LCD display of a calling Dtermusing CCIS.
Operating Procedure
Lift the handset or press the SPEAKER key and dial the desired station. The LCD display indicates the status of the
called station.
Service Conditions
1. If the called station is idle, the display...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 857
Calling/Called Number Display - CCIS C-52
C-52  Calling/Called Number Display - CCIS
General Description
This service feature allows an Inter-Office calling/called number display when the Attendant Console and the
calling/called party belong to different offices within the CCIS network.
If the Attendant dials a telephone number, the dialed telephone number is displayed on the Console (Calling Number
Display). If a station calls an...
