NEC Neax 2400 Ipx Feature Programming Manual

NEAX2400 IPX Feature Programming ManualPage 858NDA-24297, Issue 1
C-52 Calling/Called Number Display - CCIS
Operating Procedure (cont’d)
2. The Attendant presses the ANSWER key; Station B and the Attendant are connected. The number of
Station B is displayed on the Attendant Console.
Service Conditions
For the Attendant Console
1. At the time of call origination:
a.) The called number is displayed (last 6 digits) only when the called party has answered the call.
2. At the time of call termination:
a.) The...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 859
Call Processing Indication - CCIS C-53
C-53  Call Processing Indication - CCIS
General Description
This feature provides a visual indication at the ATTENDANT CONSOLE [A-3] of all CCIS calls being handled by
the ATTENDANT CONSOLE [A-3] through the CCIS network.
Operating Procedure
Refer to the operation guide of the Attendant Console.
Service Conditions
1. The status of calls being processed by the Attendant is indicated by the status...

NEAX2400 IPX Feature Programming ManualPage 860NDA-24297, Issue 1
C-54 Call Transfer - Attendant - CCIS
C-54  Call Transfer - Attendant - CCIS
General Description
This feature allows a user to transfer a call through the CCIS network to an Attendant Console located in a Main or
Satellite node, while connected to a CCIS network call.
Operating Procedure
To transfer a call to an Attendant Console
1. While engaged in a Central Office trunk call, switch hook flash; receive special dial tone.
2. Dial the...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 861
Call Transfer - Attendant - CCIS C-54
Interactions (cont’d)
4. A call transfer to a Dtermthat has DO NOT DISTURB [D-21D] set will receive reorder tone, or follow
CALL FORWARDING-BUSY LINE or ALL CALLS if set.
Programming
STEP 1:ASYD- System Data 2, Index 1, Bits 0 & 1. Assign data“11”to allow CONSULTATION HOLD [C-
58] for all types of connections.
STEP 2:AT N R- Allow tenant-to-tenant connection for Inter and Intra-tenant connections....

NEAX2400 IPX Feature Programming ManualPage 862NDA-24297, Issue 1
C-55 Centralized Billing - CCIS
C-55  Centralized Billing - CCIS
General Description
This service is used for collecting billing information from each office within the network and directing it to
associated offices, thus providing the billing information to the CENTRALIZED BILLING CENTER via an RS-
232C interface.
This feature may be provided through multiple FCCS groups (networks where multiple NEAX2000 IVS
2sare
connected via FCCS link)...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 863
Centralized Billing - CCIS C-55
Operating Procedure (cont’d)
2. Station C goes off-hook; Stations A and C are connected with each other in conversation.
3. Stations A and C go on-hook; SMDR information is sent out to the CENTRALIZED BILLING CENTER.
4. Station B dials Station C in Node C; Station B receives ringback tone and Station C is rung.
STN (c)
STN (a)
[Node A]
[Node B]STN (b)
CCIS CCIS[Node C]
Centralized Billing Center
[Node A...

NEAX2400 IPX Feature Programming ManualPage 864NDA-24297, Issue 1
C-55 Centralized Billing - CCIS
Operating Procedure (cont’d)
5. Station C goes off-hook; Stations B and C are connected in conversation.
6. Stations C and B go on-hook; SMDR information is sent to the Billing Center through the CCIS line.
Service Conditions
1. The maximum number of billing information output ports at the Center Office is 2.
2. Information storage capacity of the office should be 700 calls.
3. If billing information in...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 865
Centralized Billing - CCIS C-55
Programming
STEP 1:ASYD- System 1, Index 32, Bit 0: At the time of SMDR processor trouble, outgoing call is not
restricted/restricted = 0/1. Bit 1: Tenant information is recorded (1). Bit 2: Route information is
recorded (1). Bit 7: SMDR services are provided (1).
System 1, Index 33, Bits 3 & 4: Designation of a total of parties to be billed. Bit 5: Designation of
billing system for a transferred incoming...

NEAX2400 IPX Feature Programming ManualPage 866NDA-24297, Issue 1
C-56 Centralized Day/Night Mode Change - CCIS
C-56  Centralized Day/Night Mode Change - CCIS
General Description
This service feature switches the DAY/NIGHT mode of Satellite Nodes which are linked to the Main Node via
CCIS, in accordance with the DAY/NIGHT mode switching [A-3] at the Main Node.
Operating Procedure
Note:Node B - Node E are Satellite Nodes.
1. Press the NIGHT key on the Attendant Console for each Tenant; the NIGHT lamp...

NEAX2400 IPX Feature Programming Manual
NDA-24297, Issue 1Page 867
Centralized Day/Night Mode Change - CCIS C-56
Service Conditions (cont’d)
2. DAY/NIGHT mode changeover will be performed in one-minute increments. If consistency between the
DAY/NIGHT mode at the Main and Satellite Nodes is lost, the status is restored to that of the Main Node
within 16 minutes.
3. At the Main Node, from 1 to 15 tenants can use the system.
4. At a Satellite Node, only TN = 1 is possible.
5. When a Satellite Node is...
